Pacific Floormaster 18B Operating & Maintenance Instructions

Hide thumbs Also See for Floormaster 18B:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating and Maintenance Instructions
FLOORMASTER 18B
INTRODUCTION
This operator's book has important information for
the use and safe operation of this machine. Read
this book carefully before starting the machine.
Keep this book and tell all operators to read the book.
If you do not follow the instructions, you can cause
an injury or damage equipment, furniture or build-
ings.
For new books write to:
Pacific
2259 S. Sheridan
Muskegon, MI 49442-6252
Carefully inspect all components to ensure that there
is no concealed freight damage. If such damage is
discovered, file a "CONCEALED DAMAGE RE-
PORT" immediately with the delivering carrier.
OPERATING & MAINTENANCE
READ THIS BOOK
The contents of this manual are based on the latest
product information available at the time of publica-
tion. Pacific Steamex reserves the right to make
changes or improvements to its machines without
notice.
FOR YOUR CONVENIENCE, RECORD THE
FOLLOWING IMPORTANT INFORMATION:
MODEL
SERIAL NUMBER
PART NUMBER
DATE PURCHASED
INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Floormaster 18B and is the answer not in the manual?

Questions and answers

Related Manuals for Pacific Floormaster 18B

Summary of Contents for Pacific Floormaster 18B

  • Page 1 Pacific Steamex reserves the right to make Keep this book and tell all operators to read the book. changes or improvements to its machines without If you do not follow the instructions, you can cause notice.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ AND UNDERSTAND ALL INSTRUCTIONS AND WARNINGS BEFORE OPERATING THIS MACHINE! WARNING: To reduce the risk of fire, electric shock or injury: 1. You must have training in the operation of the machine before using it. READ THE INSTRUCTION BOOK.

  • Page 4: Symbols Used On The Machine

    SYMBOLS USED ON THE MACHINE Symbol for the water valve: Indicates the solenoid valve switch. Symbol indicating the raised or lowered position of the brush base: Indicates the lever for lifting the brush base. Symbol for the brush: Indicates the brush motor switch. Symbol for the vacuum motor: Indicates the vacuum motor switch.
  • Page 5 SYMBOLS USED ON THE MACHINE Indication of the maximum recommended temperature for the solution water (50°C or 122°F): It is located near the fill hole of the solution tank. Symbol indicating the adjustment lever for the handle bar height. Symbol for the key switch. Symbol for the coupling: Indicates the anchor points and the load direction.

  • Page 6: Machine Preparation

    MACHINE PREPARATION 1. UNPACKING THE MACHINE 1. Use a fork truck to move the machine when packaged. 2. Take off the outer package 3. The machine is fixed on the pallet with wooden wedges that block the wheels. 4. Take the wedges off. Using a ramp, pull the machine down from the pallet, pushing it in reverse motion.

  • Page 7: Connecting The Battery Charger

    MACHINE PREPARATION 6. Connect the batteries’ connector (2) to the machine’s connector (1). 7. Reassemble the recovery tank, vacuum plug and squeegee hose. 3. CONNECTING THE BATTERY CHARGER The battery chargers’ connector fits into the battery connector (2) located under the recovery tank.

  • Page 8: Connecting The Battery Connector

    MACHINE PREPARATION 5. CONNECTING THE BATTERY CONNECTOR After charging the batteries, reconnect the battery connector (2) to the connector of the machine (1). 6. BATTERY INDICATOR The battery indicator is a green signal light; it is constantly on when the batteries are sufficiently charged.

  • Page 9: Adjusting The Squeegee Height

    MACHINE PREPARATION 8. ADJUSTING THE SQUEEGEE HEIGHT The height from the floor to the squeegee should be adjusted based on the blade’s wear. Rotate the knob (2) counter-clockwise to lift the squeegee and clockwise to lower it. Note: Adjust the right and left knobs the same amount; the squeegee should be positioned parallel to the floor.

  • Page 10: Solution Tank

    MACHINE PREPARATION 12. SOLUTION TANK Unscrew the water inlet plug and confirm the solution filter, located on the bottom left side, is properly assembled. 13. SOLUTION WATER ° ° Fill the solution tank with clean water at a temperature not more than 50 C/122 Add the proper concentration of liquid detergent by following the manufacturer in- structions.

  • Page 11: Operation

    OPERATION OPERATING 1. Connect the machine connector (1) to the battery connector. 2. Turn the key (2) clockwise to ON. The green signal light will come on (3) indicating the batteries are charged (if blinking, the batteries need to be charged). 3.

  • Page 12: Device Too Full

    OPERATION Attention: If problems occur during operation, release the lever on the handle bar and immediately lower the brake lever located on the left side. This action will stop the machine’s movement. To restart the machine after the problem has been solved, release the parking brake lever and push the lever on the handle bar forward.

  • Page 13: Upon Completion Of The Work

    UPON COMPLETION OF THE WORK After finishing your work and before any type of maintenance is done, it is necessary to do the following: 1. Close the water valve through lever (1). 2. Lift the brush base with lever (2). 3.

  • Page 14: Daily Maintenance

    DAILY MAINTENANCE CLEANING THE RECOVERY TANK 1. Pull out the hose on the front of the recovery tank. 2. Unscrew the drain plug and empty the tank. Use gloves to protect yourself from contact with dangerous solutions 3. Lift the cover of the recovery tank. 4.

  • Page 15: Cleaning The Solution Tank Filter

    DAILY MAINTENANCE CLEANING THE SOLUTION TANK FILTER 1. Unscrew the plug on the solution tank. 2. Take out the filter by pulling up on the filter cap, then clean the filter thoroughly with water. 3. Reassemble by pushing the cap until it snaps into the filter body. CLEANING THE VACUUM FILTER 1.

  • Page 16: Disassembly Of The Brush

    DAILY MAINTENANCE DISASSEMBLY OF THE BRUSH To remove the brushes: 1. Lift the brush base (lever 1). 2. Set the brake (lever 2). 3. Clean the hopper as described on page 13. 4. Remove any strings or debris that may be preventing free brush rotation. 5.

  • Page 17: Weekly Maintenance

    WEEKLY MAINTENANCE CLEANING THE SQUEEGEE HOSE Weekly or whenever the suction is insufficient, make sure the squeegee hose is not obstructed. To clean: 1. Take off the hose from its coupling on the squeegee. 2. Take off the other end from the recovery tank. 3.

  • Page 18: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE INSUFFICIENT WATER ONTO THE BRUSH 1. Make sure the water valve is open (lever 1). 2. Confirm there is water in the solution tank. 3. Make sure that the solenoid valve switch is on (button furthest on right). THE MACHINE DOES NOT CLEAN SATISFACTORILY Check the condition of the brush and replace it if necessary.
  • Page 19 NOTES...

  • Page 20: Warranty Policy

    2. Upon compliance with the above warranty procedure, all warranted repairs will be completed at no additional charge or cost to the user. 3. Only Pacific or its authorized dealers and agents may make no charge warranty repairs on this product. All others do so at their own risk.
