1.6. Interior Light Supervision (green/white wire: w3-6)

If connected:
- The interior light will be turned on for 20 sec. when disarming unless the ignition is turned
on.
- The interior light will be turned on all the time whilst the alarm is sounding.
1.7. Program the Optional Features (default=1 chirp)
Follow the steps below to program the Optional Features:
For example: To program the feature #5 as 15sec.
- Turn the ignition on then off with the system disarmed.
- Within 10 sec., press the valet switch 3 times.
- The system enters the programming mode and the siren and LED will be on for 2 sec. to
confirm.
* To Reset to Factory Default:
Within 10 seconds press button #4 for 3 sec., all the optional features will be reset to the
factory default and the siren will sound for 2 sec. to confirm leaving the programming
mode.
- Within 10 sec., press the valet switch 5 times.
- 1 sec. later the siren will chirp 5 times to confirm.
- Press button #1 of the remote control 6 times to select 15 sec. and the siren will chirp 6
times to confirm the setting.
- Press the valet switch again (from 1 to 21) within 10 sec. to select the next feature for
programming.
* The system will leave the programming mode and the siren will sound for 2 sec. to confirm
if the ignition is turned off at any time during programming or if the valet switch or remote
control button #1 has not been pressed within 10 sec.

1.8. Optional Programmable Features

No Chirp Function
1 1 chirp Chirp Confirmation
2 2 chirp Door Lock with Passive Arming
3 3 chirp Ignition Lock
4 4 chirp Ignition Unlock
5 5 chirp Door Lock Time(sec.)
6 6 chirp Door Unlock Time(sec.)
7 7 chirp Door Unlock with Disarming
8 8 chirp Siren/Horn Output
9 9 chirp Alarm Condition Cycle Duration
10 10 chirp Interior Light Delay
11 11 chirp Auto. Rearming
12 12 chirp Auto. Engine Disable(AED)
13 13 chirp Door Open Alerts
14 14 chirp Total/Comfort Closure
15 15 chirp Disarm with Boot Release
16 16 chirp Anti-hijacking Countdown
17 17 chirp Activate Anti-hijacking Countdown
18 18 chirp Anti-hijacking by Remotes
19 19 chirp Anti-hijacking by Ignition+Door
20 20 chirp Override Code
21 21 chirp Hazard lights Output
Factory Default = 1 Chirp
Τ 1 Chirp Τ 2 Chirp Τ
On Off
Disable Enable
Disable Ignition
Disable Driver
1) 0.8 2) 3.6
5) 0.8+40
0.8 3.6
Driver All
Siren Horn
30 sec. 60 sec.
Disable 25 sec.
Disable Enable
Disable Enable
Disable Mode 1
Disable 15 sec.
Disable Enable
30sec. 60sec.
Normal Brake
Disable Enable
Disable Enable
Flash 1
Normal Pulse
-
3 Chirp Τ 4 Chirp
Brake
All
3) 0.8*2 4) 0.8+15
6) 15 7) 40
0.8*2
40 sec. 60 sec.
Mode 2
30 sec. 40 sec.
Flash 2~10
Continuous
