F A L C O N
WORLD CLASS SE CURITY
FALCON PREDATOR XL2
Vehicle Security System with Anti-Hijack
Owner's Manual
HELPLINE: 0906 700 10 20
(All calls charged at 50p/min)
Falcon Security Ltd. Unit 9 Tanning Court, Warrington, Cheshire, WA1 2HF, UK
Internet: http://www.falcon-security.com
Email: support@falcon-security.com
112005
Advertisement
Table of Contents
Related Manuals for Falcon PREDATOR XL2
Summary of Contents for Falcon PREDATOR XL2
- Page 1 WORLD CLASS SE CURITY FALCON PREDATOR XL2 Vehicle Security System with Anti-Hijack Owner’s Manual HELPLINE: 0906 700 10 20 (All calls charged at 50p/min) Falcon Security Ltd. Unit 9 Tanning Court, Warrington, Cheshire, WA1 2HF, UK Internet: http://www.falcon-security.com Email: support@falcon-security.com 112005...
-
Page 2: Table Of Contents
F A L C O N WORLD CLASS SE CURITY FALCON PREDATOR XL2 Vehicle Security System with Anti-Hijack Owner’s Manual 01. System Status Memory ..........3 02. Operation of the Remote Control......... 3 03. Basic Functions ............3 EMOTE .................. 3... -
Page 3: System Status Memory
01. System Status Memory The system will enter the same mode after powering on as when it was powered off. 02. Operation of the Remote Control BUTTON ARMED DISARMED IGNITION ON BTN#1 once DOOR LOCK BTN#2 once DISARM DISARM DOOR UNLOCK BTN#1 3sec. -
Page 4: Trigger And The System
Press button #2: When the system is triggered with the siren sounding and hazard lights flashing, press button #2 once, the siren and hazard lights will both stop and then: - The siren will chirp 4 times - The hazard lights will flash twice - The doors will unlock (if connected) - The LED will flash to indicate the triggered zone - The system will enter disarmed mode... -
Page 5: Emergency Override
Emergency Override Follow the steps as below to override the system: With the system armed or alarming Turn the ignition on (or off then on) After 2 sec. the LED will flash 10 times slowly Press the valet switch once after the LED flashes a number of times equal to the PIN The system will be overridden and enter disarm mode Repeat the steps from turning the ignition on if the previous operation is failed Wait for 3 minutes and operate the override procedure again after 3 times of incorrect operation... -
Page 6: Programming Option Features
05. Programming Optional Features Follow the steps as below to program the option features: Start with the system disarmed Turn the ignition on and then off Within 10 seconds press the valet switch 3 times The siren will sound for 2 seconds to confirm the system has entered the programming mode Within 10 seconds press button #1 the same number of times as the number of the feature you wish to program. -
Page 7: Option Features Table
06. Option Features Table: (*Factory Default=1 CHIRP - Button#1/#2/#3 = 1/2/3 CHIRP) ITEM CHIRP FUNCTION 1 CHIRP 2 CHIRP 3 CHIRP 1 CHIRP CHIRP ON/OFF 2 CHIRP SHOCK SENSOR BYPASS DISABLE FIRST BOTH 3 CHIRP DOOR LOCK TIME INSTALLER ONLY OPTION 4 CHIRP DOOR UNLOCK TIME INSTALLER ONLY OPTION... -
Page 8: Explanation Of Option Features
07. Explanation of Optional Features Chirp Confirmation When Set as On When arming the system the siren will chirp once. When disarming the system the siren will chirp twice. When Set as Off The siren will not chirp when arming or disarming the system but the siren will still chirp 3 times if a door or the bonnet is not closed properly when arming and the siren would chirp 4 times when disarming if the system has been triggered. - Page 9 #9 Automatic Engine Disable (AED) When Set as Enable After parking the car, turning the ignition off and opening and then closing the door the immobiliser will activate within 10 seconds. The immobiliser will not be active during the 10 second countdown. After 10 seconds the PIN will be required to disable this feature With this feature on the system will still be able to enter the arm mode by pressing the remote, via passive/last door arming or using Manual Arming...
- Page 10 #18 Bypass Input Wire Installer only option #19 Comfort Closure/Total Closure (CH3) Installer only option #20 Pager Output Installer only option #21 Anti-hijacking Delay When Set as 15-30-60sec. After activating the anti-hijacking feature the system will delay entering anti-hijacking mode for 15, 30 or 60 seconds depending on the selection.
- Page 11 #26 PIN - Personal Identification Number The factory default PIN is 1 press Follow the sec. 05. Programming Option Features to change the PIN Visual Deterrent As a visible deterrent in addition to the flashing dashboard LED your vehicle should have been fitted with the following warning stickers.
