Falcon Predator XL3 Installer Manual

Vehicle security system with anti-hijack
Hide thumbs Also See for Predator XL3:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
FALCON PREDATOR XL3
Vehicle Security System with Anti-Hijack

TABLE OF CONTENTS

1. SYSTEM INSTALLATION ............................................... 2
1.1. Power On ........................................................... 2
1.2. NO & NC Immobiliser Relay Wiring ......................... 2
1.3. Programming New Remote Controls ....................... 2
1.5. Start Output (pink wire: w3-9) .............................. 2
1.8. Optional Programmable Features ........................... 3
2. SYSTEM UPGRADE ...................................................... 8
3. Wiring Diagram .......................................................... 9
4. Wiring Notes............................................................ 10
5. Central Locking Wiring .............................................. 11
F A L C O N
WORLD CLASS SE CURITY
Installer's Manual
-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Predator XL3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Falcon Predator XL3

Summary of Contents for Falcon Predator XL3

  • Page 1: Table Of Contents

    F A L C O N WORLD CLASS SE CURITY FALCON PREDATOR XL3 Vehicle Security System with Anti-Hijack Installer’s Manual TABLE OF CONTENTS 1. SYSTEM INSTALLATION ..........2 1.1. Power On ............2 1.2. NO & NC Immobiliser Relay Wiring ......2 1.3.

  • Page 2: System Installation

    1. SYSTEM INSTALLATION 1.1. Power On When powered on, the system will remain in the same status it was in when powered off. 1.2. NO & NC Immobiliser Relay Wiring The system offers two ways of wiring the immobiliser as shown below. When wired for Normally Open the immobiliser relay is switched on when the alarm is disarmed (fail secure).

  • Page 3: Interior Light Supervision (Green/White Wire: W3-6)

    1.6. Interior Light Supervision (green/white wire: w3-6) If connected: The interior light will be turned on for 20 sec. when disarming unless the ignition is turned The interior light will be turned on all the time whilst the alarm is sounding. 1.7.

  • Page 4: Feature #20 Override Code (Default=1 Flash)

    1.9. Feature #20 Override Code (default=1 flash) Follow the steps below to program: - Turn the ignition on then off with the system disarmed. - Within 10 sec., press the valet switch 3 times. - The system enters the programming mode and the siren and LED will be on for 2 sec. to confirm.
  • Page 5 *When selecting 0.8 sec. + 15 sec. for cars with total closure the windows will be closed automatically during remote arming without enabling feature #14. When set as 0.8 sec. + 40 sec.: The system will send a 0.8 sec. pulse and then send a 40 sec. pulse when locking the doors. *When selecting 0.8 sec.
  • Page 6 11. Auto. Rearming (default=disable) When set as Enable: The system will arm itself again automatically 30 seconds after disarming the system if no doors are opened. Opening a door after disarming the system will deactivate the auto rearming feature. 12. AED, Auto Engine Disable (default=disable) When as Enable: After parking the car, turning the ignition off and opening and then closing the door the engine disable relay will activate within 10 seconds but the system will still be disarmed.
  • Page 7 boot release. * The remote boot release will still work with the ignition on. 16. Anti-hijacking Countdown (default=30sec.) When set as 30 or 60 sec.: The system will enter the Anti-hijacking mode after 30 or 60 sec. depending on the selection. The siren will chirp 10 times before entering into the anti-hijacking mode as a last warning.

  • Page 8: System Upgrade

    21. Hazard lights Output (default=normal) When set as Normal: Connect the hazard lights output as normal using the Y-splitter lead. If the Normal connection does not work then connect the hazard lights output to the hazard switch as shown below and set feature #21 as Pulse or Continuous depending on the type of hazard switch Hazard Switch...

  • Page 9: Wiring Diagram

    3. Wiring Diagram...

  • Page 10: Wiring Notes

    4. Wiring Notes Wiring Diagrams - Interior Light, Horn & Boot Release Postive Interior Light Negative Interior Light To Positive To Negative Interior Light Interior Light White White W3-6 W3-6 Positive Horn Honk Negative Horn Honk To Positive To Negative Horn Wire Horn Wire Brown...

  • Page 11: Central Locking Wiring

    5. Central Locking Wiring Wiring Diagram - Predator XL3 Door Lock/Unlock - Basic Follow the diagrams below for wiring basic central locking systems Diagram #A Diagram #B Negative or Positive Locking Motor Interrupt Locking eg. CHRYSLER Two wires resting open circuit one pulses 12V or...
  • Page 12 Wiring Diagram - Predator XL3 Two Stage Door Unlock The Predator XL3 has a dedicated unlock-2 output allowing for two stage door unlock operation. Two Stage Negative Trigger (-)LOCK (-)DOOR LOCK WIRE Black (-)DOOR UNLOCK WIRE Green DOOR LOCK Pink...
  • Page 13 Wiring Diagram - Predator XL3 Two Stage Door Unlock Passenger Door Motors Two Stage Adding Actuators +12V Black LOCK Green Pink White UNLOCK Blue +12V Orange (-)Unlock-2...
