FALCON PREDATOR XL3
Vehicle Security System with Anti-Hijack
TABLE OF CONTENTS
1. SYSTEM FEATURES ..................................................... 2
2. SYSTEM OPERATION ................................................... 3
2.1. System Status Memory ........................................ 3
2.2. Button Function................................................... 3
2.3. Programming New Remote Controls ....................... 3
2.4. To Arm the System .............................................. 3
2.5. Open Circuit Alert ................................................ 4
2.6. To Disarm the System .......................................... 4
2.7. LED Indications ................................................... 4
2.8. Silent Arm and Disarm ......................................... 5
2.9. Trigger and Alarming............................................ 5
2.10. Stop the system when alarming ........................... 6
2.11. Panic Mode ....................................................... 6
2.12. Temporary Sensor Bypass ................................... 6
2.13. Ignition Lock and Unlock ..................................... 6
2.14. Door Open Alerts ............................................... 6
2.15. Boot Release ..................................................... 6
2.16. Valet Mode........................................................ 7
2.17. Car Finder ........................................................ 7
2.18. Interior Light Supervision (if connected)................ 7
2.19. Door Open Alert (if enabled)................................ 7
2.20. Anti-hijacking by Remotes (if enabled). ................. 7
2.21. Anti-hijacking by Ignition+Door (if enabled) .......... 7
2.22. Visual Deterrents ............................................... 8
F A L C O N
WORLD CLASS SE CURITY
Owner's Manual
-
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Falcon Predator XL3
Summary of Contents for Falcon Predator XL3
- Page 1 F A L C O N WORLD CLASS SE CURITY FALCON PREDATOR XL3 Vehicle Security System with Anti-Hijack Owner’s Manual TABLE OF CONTENTS 1. SYSTEM FEATURES ............. 2 2. SYSTEM OPERATION ........... 3 2.1. System Status Memory ........3 2.2. Button Function........... 3 2.3.
-
Page 2: System Features
1. SYSTEM FEATURES - Remote Arming/Disarming - Silent Arming/Disarming - 2 Plug-in Sensor Ports - Temporary Remote Sensor Bypass - Panic Mode - Valet Mode - Optional Coded Emergency Override - Remote Boot Release - Car Finder - Open Circuit Alert - Door Open Alert - Total/Comfort Closure - Auto. -
Page 3: System Operation
2. SYSTEM OPERATION 2.1. System Status Memory The system will enter the same mode after powering on as when it was powered off. 2.2. Button Function Button Armed Disarmed IGN On BTN #1 once Door Lock BTN #2 once Disarm Disarm Door Unlock BTN #1 2 sec. -
Page 4: Open Circuit Alert
* The doors will also lock when the system is armed if optional feature #2 is enabled. * The 30 second countdown will be interrupted if any of the doors, boot or bonnet are opened. Closing the last opened door, boot or bonnet will restart the 30 sec. countdown. C. -
Page 5: Silent Arm And Disarm
B. System trigger memory To warn the user that the system was triggered whilst they were away from the vehicle, after disarming the system the siren will chirp 4 times, the hazard lights flash 3 times and the LED will flash to indicate the triggered zone as follows: 1 flash = Plug in sensor 2 stage trigger. -
Page 6: Stop The System When Alarming
2.10. Stop the system when alarming A. Press button #1 once When the system is triggered, the siren and hazard lights are activated, press button #1 once, the siren and hazard lights will be deactivated but the system will remain in armed mode. B. -
Page 7: Interior Light Supervision (If Connected)
2.16. Valet Mode Valet mode is a convenient feature to use when handing your keys to third parties, eg. for valet parking or vehicle servicing. - Turn the ignition on with the system disarmed. - Within 10 seconds, press and hold the valet switch for 2 seconds. - The system will enter the valet mode and the LED will be on all the time to confirm. -
Page 8: Visual Deterrents
2.22. Visual Deterrents As a visible deterrent in addition to the flashing dashboard LED your vehicle should have been fitted with the following warning stickers. A helpline sticker should also have been fitted to your front windscreen. SIDE WAR NING STICKER HE LPLINE REAR...
