5. Central Locking Wiring

Wiring Diagram - Predator XL3 Door Lock/Unlock - Basic
Follow the diagrams below for wiring basic central locking systems
Diagram #A
Negative or Positive Locking
Two wires resting open circuit one pulses 12V or
ground for lock, one pulses 12V or ground for unlock
Black
Green
Pink
White
Blue
Orange
Original Built-in
To +12V or Ground
Controller
Depending on polarity
of locking system
Diagram #C
Central locking where only a switch
is installed in the drivers door.
An additional door motor is required.
+12V
Black
Green
Pink
White
Blue
Orange
Motor Interrupt Locking
Black
Green
Pink
White
Blue
Orange
(Note: Set door lock/unlock time to 3.6 sec.)
Black
Green
Pink
White
Down
Blue
Orange
Electric Motor
Up
Switch
Diagram #B
eg. CHRYSLER
Two wires resting at ground, one pulses
12V for lock, one pulses 12V for unlock
Up
+12V
Door Lock Switch
On the Front Door
Diagram #D
Vacuum central locking
eg: MERCEDES, AUDI
Polarity Reverses on a single wire
Main Line
Down
Up
-
