Maintenance - Dimplex DF3033ST User Manual

LIGHT DIMMER
1. Press the Flame/Heat button
2. Repeatedly press the "Light Dimmer Up" or "Light Dimmer Down" button to decrease or
increase the brightness of the upper lights.
CHILD LOCK (FIGURE 8)
1. Depress tab on the battery cover on the back of the remote transmitter and remove the battery
cover.
2. Move "Child Lock" tab to the right to lock the remote transmitter.
3. Move "Child Lock" tab back to the left to unlock the remote transmitter.
4. Replace the battery cover.
NOTE
To temporarily unlock the remote transmitter press (in order) "Temperature Down" then "Temperature
Up" then "Dimmer Down".
When the remote transmitter's backlight is illuminated the "Child Lock" is bypassed. When the backlight
is off the "Child Lock" is re-activated.
FIGURE 8
SLEEP TIMER
The Sleep Timer automatically shuts off the fi replace after a preset time (from 30 minutes to 8 hours).
1. Press the "Flame & Heat On/Off" button to turn the fi replace ON.
2. To set the sleep timer press the "Sleep Timer Up" button.
3. Set the timer from 30 minutes through 8 hours.
4. The fi replace will automatically turn OFF when the sleep timer reaches 0 minutes.
5. The sleep timer can be cancelled at any time by pressing the "Sleep Timer Down" button
repeatedly until the sleep timer displays "0".
WARNING
Disconnect power before attempting any maintenance or cleaning to reduce the risk of fi re, electric shock
or damage to persons.

MAINTENANCE

LIGHT BULB REPLACEMENT
Allow at least 5 minutes for light bulbs to cool before touching bulbs to avoid accidental burning of skin.
Light bulbs need to be replaced when you notice a dark section of the fl ame or when the clarity and detail
of the log ember bed exterior disappears. There are four bulbs under the log set, which generate the
fl ames and embers, and two bulbs above the log that illuminate the log exterior.
LOWER LIGHT BULB REQUIREMENTS
Quantity of 3 clear chandelier or candelabra bulbs with an E-12 (small) socket base, 60 watt rating.
Example: GE 60BC or Philips 60 CTC.
DO NOT EXCEED 60 WATTS PER BULB
HELPFUL HINTS
It is a good idea to replace all light bulbs at one time if they are close to the end of their rated life. Group
replacement will reduce the number of times you need to open the unit to replace light bulbs. Care
must be taken when removing the logset as the logset contains LED's and wires.
to turn the Flame/Heat ON.
Unlocked Locked
Child Lock Switch
8
