- Page 2 Copyright© by Edimax Technology Co, LTD. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the...
- Page 3 Č ý Českého průvodce rychlou instalací naleznete na Č ý přiloženém CD s ovladači. Auf der beiliegend Treiber CD finden Sie deutsche Anleitung zur Schnellinstallation. ñ Incluido en el CD el G.R.I. en Español. ñ ç Veuillez trouver l’français G.I.R ci-joint dans le CD. ç...
-
Page 4: Product Introduction
Product Introduction Thank you for purchasing an Edimax product. This router is a high speed wireless 11N ADSL2/2+ modem router. You can surf the Internet and share the connection through the Edimax router without investing in other devices. You can configure the router by running the Setup Wizard in the CD-ROM provided in the package. -
Page 5: Minimum Requirements
1. Minimum Requirements The following devices are required to configure the ADSL2+ Router: A PC with an Ethernet Adapter and a Web-Browser (Internet Explorer 4.0 or higher) ADSL Line RJ-45 Ethernet cable and RJ-11 Phone Line 2. Product Package This package contains the following components: One ADSL2+ Router (Annex A or B) 3dBi Antenna x 2 pcs 12V Power Adapter... - Page 6 3) WPS Press the WPS button 2~4 seconds to activate the wireless protection. 4) Power Jack Please plug-in the supplied power adapter to the ADSL Router’s power jack. The power adapter is 12V. 5) Local Area Network (LAN) The router’s 4 LAN ports are where you connect your LAN’s PCs, printer servers, hubs and switches etc.
- Page 7 3 Install ADSL Router Step 1. Connect the ADSL Line Use the supplied RJ-11 telephone cable, connect the router from the ADSL port to your telephone socket with an ADSL micro filter plugged in. Step 2. Connect the router to your LAN network Connect the router to your PC, hub or switch by attached the Ethernet cable to the LAN port of the router.
- Page 8 Click “Start” in the task bar then select the “Control Panel” . Click “Switch to Classic View” on the left top to see more setting icons. Find an icon “Network Connection” then Double-Click to open the network connection setting.
- Page 9 You will see an icon “Local Area Connection”, select the icon then Right-Click the mouse to open the sub-menu and select the “Properties” Select the “Internet Protocol (TCP/IP)” then click the “Properties” Ensure the parameter marked in blue are checked in “Obtain an IP address automatically”...
-
Page 10: Internet Connection
4 Internet Connection If you lost your CD-ROM, you can configure this ADSL modem router via the following procedures. The procedures will guide you to login to your modem router using the Internet Explorer, so that you can set up the Internet connection and configure all others function. - Page 11 Lithuania, Malta, Poland, Romania, Slovakia, Slovenia, the Netherlands, Portugal, Spain, Sweden, and the United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland. EU Countries not intended for use None A declaration of conformity is available on www.edimax.com N20379...
