LOOK
Operating Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LOOK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RIKA LOOK

Summary of Contents for RIKA LOOK

  • Page 1 LOOK Operating Manual...

  • Page 2: Table Of Contents

    Feeding in external combustion air .................................10 5. ASSEMBLY OPTIONS Converting to rear flue pipe connection ..............................11 6. MANUAL OPERATION Combustion air regulation ..................................12 RIKA firelighter .....................................12 Correct heating up ....................................12 7. CLEANING AND MAINTENANCE Basic information ....................................13 Cleaning the combustion chamber .................................13 Empty the ash drawer .....................................13...

  • Page 3: Preface

    1. PREFACE Dimensions Technical data RO-S Technical data Heating power range [kW] 4 - 8 Room heating capacity (depending on house [m³] 90 - 210 insulation) RO-T2 RO-T3 Fuel consumption [kg/h] up to 2,2 Efficiency 10,7 CO-emission on 13% OO [mg/m Dust emission [mg/m...

  • Page 4: Spare Part Overview - Exploded Diagram

    Spare part overview - exploded diagram...

  • Page 6: Spare Part Overview - Article Numbers

    Spare part overview - article numbers Art.Nr.: Description Art.Nr.: Description N111803 Grub screw Z36356 Connecting rod N112219 Hexagonal screw Z36357 Bearing shaft N105049 Flat washer black N103981 Shaft locking clip D5 N102434 Grub screw N108313 Taptite Z14937 Distance Z36358 Vent flap primary air B17722 Door bolt B17637...

  • Page 7: Important Information

    > 80 cm b > 20 cm RIKA stoves should only be installed in rooms with normal humidity (dry areas according to VDE 0100 Part 200). The furnaces are not splash water please observe a minimum distance of 20 cm behind and sideways the stove protected and may not be installed in wet areas.

  • Page 8: Prior To Set Up

    Prior to set up Stoves type 1 (BA 1): Suitable for multiple occupancy. (Note the different country regulations.) Floor bearing capacity Ensure that the substructure is capable of bearing the weight of the stove prior These may only be operated with the combustion chamber door closed. to set-up.

  • Page 9: Brief Information On Combustible Logs

    3. BRIEF INFORMATION ON COMBUSTIBLE LOGS Suitable fuels and fuel amounts Output controlling Your stove is generally suitable for burning dry firewood. You can also burn The output of your stove is regulated manually or via the Rikatronic-control. combustibles such as wood briquettes. Please observe that the output of your stove also depends on the chimney draught and the amount of fuel added.

  • Page 10: Installing The Stove

    The stove can also be pushed on this cardboard or carpet. Feeding in external combustion air We recommend original flue pipes from RIKA for proper connection. only for devices which are able to run in room-air independent operation. Connection to the chimney Combustion air must be fed to the stove from outside via a sealed pipe for operation independent of the room air.

  • Page 11: Assembly Options

    5. ASSEMBLY OPTIONS Screw the washers with the nuts on the pre-assembled thread on the bottom of Note the cover (circled green). Only work on the unit when the stove has cooled down completely. Then insert the supplied top cover. Note During any conversion work, take particular care of your fingers and any panels and stove attachments.

  • Page 12: Manual Operation

    RIKA f irelighter Always ignite the RIKA firelighter on the red tip. One block consists out of 8 ribs which can be divided to the desired size. The amount of RIKA firelighters also depends on the size and humidity of your firewood. Ideally, one rib is enough to light up the fire.

  • Page 13: Cleaning And Maintenance

    7. CLEANING AND MAINTENANCE Basic information Cleaning the door glass The glass can be cleaned best with a moist cloth. Stubborn dirt can be removed Note with a special cleaner (free from corrosive acids and solvents - otherwise there When you vacuum clean around the stove ensure that you do not vacuum into is a risk of damage to the glass surface) available from your stove dealer.

  • Page 14: Problems Possible Solutions

    8. PROBLEMS POSSIBLE SOLUTIONS Problem 1 Problem 2 Fire burns with weak, orange flame, window is sooted up. Stove smells strongly and / or fumes are emitted. Cause(s) Cause(s) Poor chimney draught Burning-in phase (taking into service) Damp wood Stove has accumulated dust and/or dirt Possible solution(s) Incorrect heating up Wait to end of burning-in phase and vent sufficiently...

  • Page 15: Guarantee

    In case of doubt as well as missing or incorrect translations, the German version is the only valid one. For the purpose of timely damage limitation, the warranty claim on the part of the claimant is to be enforced at the RIKA dealer in writing using the invoice and stating the purchase date, model name, serial number and reason for complaint.
  • Page 16 Technical and design changes, as well as typesetting and printing errors reserved © 2016 | RIKA Innovative Ofentechnik GmbH RIKA Innovative Ofentechnik GmbH 4563 Micheldorf / Austria, Müllerviertel 20 Telefon: +43 7582 686 - 41, Fax-DW: 43 E-Mail: verkauf@rika.at RIKA.AT...
