Direct Vent Gas Fireplace
Installation and Operating Manual
Viewpoint Series
MODEL: VP-48TP Campfire Style Log Set
D O N O T D I S C A R D
Installer:
Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
IMPORTANT: This appliance is only for use with
the type(s) of gas indicated on the rating plate.
An LP conversion kit is available when using Liquid
Propane gas; order separately.
This appliance may be installed in an aftermarket
permanently
located,
home, where not prohibited by local codes. A
manufactured home (USA only) or mobile home OEM
installation must conform with the Manufactured
Home Construction and Safety Standard, Title 24
CFR, Part 3280, or when such a standard is not
applicable, the Standard for Manufactured Home
Installations, ANSI/NCSBCS A225.1, or Standard
for Gas Equipped Recreational Vehicles and Mobile
Housing, CSA Z240.4
manufactured
(mobile)
WARNING: If the information in these instructions
are not followed exactly, a fire or explosion may
result causing property damage, personal injury
or loss of life.
Do not store or use gasoline or other
—
flammable vapors and liquids in the vicinity
of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do
not use any phone in your building.
•
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
•
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
These products have been tested and listed for use in
the USA and Canada by:
Underwriters Laboratories,
Northbrook, IL
File #MH48906
Page 1
