SERVICE MANUAL
SERVICE MANUAL
CD-Receiver
MODEL
Black and Silver models
S MPP, B MPP
B MDC, B MDD, S MDT
S MGQ, S MGT, S MGR
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
CR-325
230V AC, 50Hz
120V AC, 60Hz
220-230V AC, 50/60Hz
ON THE
CR-325
Ref. No. 4044
042008
RC-660S

Advertisement

loading

Related Manuals for Onkyo CR-325

Summary of Contents for Onkyo CR-325

  • Page 1 COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL. MAKE LEAKAGE-CURRENT OR RESISTANCE...
  • Page 2 CR-325/UKD EXPLODED VIEWS - 1 Refer to EXPLODED VIEWS - 2 A217 A221 A303 A009 x 9 pcs. P281 A038 A004 x 2 pcs. x 8 pcs. A003 x 2 pcs. U011 A004 A003 x 2 pcs. x 4 pcs.
  • Page 3 CR-325/UKD EXPLODED VIEWS - 2 Mechanism and Front panel A224 A214 x 3 P101 A003 Z005 (Loading unit only) A003 x 4 pcs. x 8 pcs. P106 P105 E001 A001 A215 A211 A301 A190 Z010 Z006 x4 pcs. Z009 Z007 A205 x 4 pcs.
  • Page 4 AVS4 GNDA 220K GNDA_CD +9VCD AVSS 10/50 VREFR C151 2.7K CD_MUT RCH_Q112 AOUT2 C154 AOUT2 R179 47/25 R177 R168 CR-325 ONLY USE C141 1.2K AVD5 Q113 IOVDD3 RN1441 CD_R IOVSS3 Q108:A R163 C139 C239 J201 223K 47/25 -9VCD C168 NJM4580M-D...
  • Page 5 R101 C106 R112 Heatsink C114 C117 NER PACK NCFC7-130512 TO NAPS-9580 C115 C128 MODEL 2047130512 TO POWER SECTION 3300/16(VX) 3.3-1W CR-325 MPP 3300/16(VX) 3.3-1W CR-325 UKD P281A 3300/16(VX) 3.3-1W JL902B JL903B NSCT-13P2106 CR-325 MDC NPLG-9P592 25055630 NSCT-3P95 25050267 SN 25052209 3300/16(VX) 3.3-1W...
  • Page 6 CPU DAB USB SECTION MODEL BAND TO NAAR-9575(1/2) R687 R787 R789 R689 R629 R671 R772 R672 R771 TO AFCEL SECTION MODEL CR-325 MPP 4.7K 2.7K 2.7K 2.7K CR-325 MPB 4.7K 4.7K CR-325 MDC CR-325 MGQ 4.7K DAB BLOCK CR-325 MGT 4.7K CR-325 MDT 4.7K...
  • Page 7 CR-325/525 NAAR-9575(2/2) U01 MAIN CIRCUIT PC BOARD 2SA1015 -41.8V(10%UP) -26.2V(10%UP) R106 Q101 S1_1 22(1/4W) D101 RL1N4003 TO NAAR-9575(1/2) S1_2 GNDD TO TUNER PS SECTION GNDD FL_AC2 GNDD FL_AC1 SUBRST SUBCLK 2045171012 NCFC5-171012 STBYLED Q707 COM5V SUBSI S-24CS16A0I-J8V1G 2SA1162 EV5V Q706 R668 3.3K...
  • Page 8 CR-325/525 SCHEMATIC DIAGRAMS - 3 AMPLIFIER SECTION NAAF-9579 21.7 R541 U03 AMPLIFIER CIRCUIT 22(1/2W) Q583 P501 Q553 PC BOARD 2SC3421-O/Y 2SA1015 CR-325: Silver 20.8 L571 CR-525: Gold Q557 S-1.3C 2SC3851-O Q515 20.8 Q509 10(1/2W) SP TERM 2SC1622A 2SA1015GR 2SA1015GR R571...
  • Page 9 CR-325/525 SCHEMATIC DIAGRAMS - 4 DISPLAY SECTION NADIS-9578 U02 DISPLAY FL_CR CIRCUIT PC Q802 BOARD SP_R AMPOUT_R GND_HP AMPOUT_L SP_L P871 EMI_1.8K R893 390(1/2W) L874 L875 R894 390(1/2W) EMI_1.8K D-VP C872 102J L873 EMI_1.8K C871 102J P873 Q804 to CHASIS...
  • Page 10 CR-325/525 SCHEMATIC DIAGRAMS - 5 to Po-Amp PWB POWER SUPPLY CIRCUIT SECTION JL504B NAPS-9580 U04 POWER SUPPLY CIRCUIT PC BOARD S4_2 R905 R906 S4_1 S3_2 1(1W) 1(1W) S3_1 S2_2 P902 S2_CT2 S2_CT1 C903 S2_1 472/250V J903 S1_2 R907 S3_1J RELAY 4.7(1/2W)
  • Page 11 CR-325 PACKING PROCEDURE CR-325(S) MGQ, MGT, MDT, MGR / (B)MDD <Note> CR-325(S) MPP, (B) MPP, MDC ---> Refer to service manual of "CS-325" CR-325UKD(B) MPB ---> Refer to service manual of "CS-325UK" A810 A811 Small side A500 A803 A801 A511...
  • Page 12 CR-325/UKD PRINTED CIRCUIT BOARD VIEWS - 1 Main circuit board (NAAR-9575-1A/B/C/D) Bottom side view Top side view (Side B) (Side A) P112 P401 C413 R410 R351 13 RDS_CL 12 RDS_DATA Q355 R396 R393 Q354 P351 R391 C410 C326 1 RCH_OUT...
  • Page 13 CR-325/UKD PRINTED CIRCUIT BOARD VIEWS - 2 Display circuit board (NADIS-9578-1A/B) Top side view (Side A) Q802 J850 C821 D821 J865 VOLUME J854 ON/STANDBY J852 S821 J853 Q802 X801 D811 U801 STANDBY J811 S801 J856 J857 C801 J860 J859 J861...
  • Page 14 CR-325/UKD PRINTED CIRCUIT BOARD VIEWA - 3 Amplifier circuit board (NAAF-9579-1A/B) P503 JL503A NCAF-9579 25139579 J561 J562 J566 C491 J563 C541 E001 R541 Top side view J501 (Side A) JL505A J559 C506 R522 R520 J541 J552 Q510 R519 R521 R572...
  • Page 15 CR-325/UKD PRINTED CIRCUIT BOARD VIEWS - 4 Power supply circuit board (NAPS-9580-1A/B) Top side view (Side A) AC-H AC-G L901 P903 P902 P901 F901A F901B F901 NCPS-9580 25139580 E003 T500mAL250V T902 T901 C902 J903 JL504B J918 J917 C905 J912 C906...
  • Page 16 CR-325/325UKD IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS Q105 : TC74VHC541FT (Octal Bus Buffer, Non-Inverted, 3-State Outputs)-1/1 The TC74VHC540/TC74VHC541 are advanced high speed CMOS OCTAL BUS BUFFERs fabricated with silicon gate C2MOS technology. They achieve the high speed operation similar to equivalent Bipolar Schottky TTL while maintaining the CMOS low power dissipation.
  • Page 17 CR-325/325UKD IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS Q106 : BA00JC5WT (Variable Rated Voltage, 1.5A Secondary LDO Regulators) Description The BA□□JC5 are low-saturation regulators with an output current of 1.5 A and a voltage accuracy of ±1%. A broad output voltage range is offered, from 1.5V to 12V, and built-in overcurrent protection and thermal shutdown (TSD) circuits prevent damage due to short-circuiting and overloading, respectively.
  • Page 18 CR-325/325UKD IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS Q110 : LA6565 (Five-Channel CD Actuator Driver)-1/4 BLOCK DIAGRAM Signal system ground Thermal shutdown SGND circuit (Load output voltage setting) VCONT MUTE VCCP2 MUTE1 Turns the corresponding channel on/off. High: output on, VLO –...
  • Page 19 CR-325/325UKD IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS Q110 : LA6565 (Five-Channel CD Actuator Driver)-2/4 TERMINAL DESCRIPTION Pin No. Pin Name Pin Descriptions Loading output direction switching (FWD). Loading system logic input. Loading output direction switching (REV). Loading system logic input.
  • Page 20 CR-325/325UKD IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS Q110 : LA6565 (Five-Channel CD Actuator Driver)-3/4 TERMINAL DESCRIPTION (Continued) Pin No. Pin Name Symbol Description Equivalent Circuit VIN1 V IN * VIN1 – VIN1 VCCS VIN2 VIN2 – 300 Ω Inputs (channels 1 to 4 and...
  • Page 21 CR-325/325UKD IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS Q110 : LA6565 (Five-Channel CD Actuator Driver)-4/4 Truth Table (Loading (H bridge) block) – Loading output OFF * Forward Reverse Short-circuit braking * *1. The output goes to the high-impedance state. *2. In braking mode, the sink side transistor is turned on (for short-circuit braking).
  • Page 22 CR-325/325UKD IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS Q112 : CXD3014R (CD Digital Signal Processor with Built-in RF Amplifier and Digital Servo + Digital High & Bass Boost + CODEC)-1/4 BLOCK DIAGRAM XRST TEST1 TRST IREQ XTAO XLAT2 XTACN DATA2 CLOK2...
  • Page 23 CR-325/325UKD IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS Q112 : CXD3014R (CD Digital Signal Processor with Built-in RF Amplifier and Digital Servo + Digital High & Bass Boost + CODEC)-2/4 TERMINAL DESCRIPTION Pin No. Pin name Description LR clock output. LRCK LR clock input.
  • Page 24 CR-325/325UKD IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS Q112 : CXD3014R (CD Digital Signal Processor with Built-in RF Amplifier and Digital Servo + Digital High & Bass Boost + CODEC)-3/4 TERMINAL DESCRIPTION (Continued) Pin No. Pin name Description Tracking drive output.
  • Page 25 CR-325/325UKD IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS Q112 : CXD3014R (CD Digital Signal Processor with Built-in RF Amplifier and Digital Servo + Digital High & Bass Boost + CODEC)-4/4 TERMINAL DESCRIPTION (Continued) Pin No. Pin name Description Test mode set.
  • Page 26 CR-325/325UKD IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS Q401 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-1/3 SYSTEM BLOCK DIAGRAM Multi Multi Rch Tone Lch Tone CLOCK DATA MCU I/F Tone Bass & Volume Volume Treble...
  • Page 27 CR-325/325UKD IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS Q401 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-2/3 BLOCK DIAGRAM AND PIN CONFIGURATION 35 34 37 36 31 30 AVCC DGND AVCC DATA TREL CLOCK BASSL2 AVEE...
  • Page 28 CR-325/325UKD IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS Q401 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-3/3 TERMINAL DESCRIPTION 19,17, FROUT,FLOUT, 14,12, 6-OUT,5-OUT, Output pin of FL/FR/C/SW/SL/SR/SBL/SBR channel 4-OUT, 3-OUT, 9,7, 2-OUT,1-OUT 20,16, FRC,FLC, Connects capacitor for reducing click noise of...
  • Page 29 CR-325 SERVICE PROCEDURE-1 PROTECTION OF EYES FROM LASER BEAM DURING SERVICING Laser Diode Properties This set employs a laser. Therefore, be sure to follow carefully the instructions below when servicing. Material: GaAS/GaALAs WARNING!! Wavelength: 780nm SERVICE WARNING : DO NOT APPROACH THE Laser output: max.
  • Page 30 CR-325 SERVICE PROCEDURE-2 2. Initialize the unit (1) Press STANDBY/ON button while pressing down CD STOP button, then the FLT displays "CLEAR", and turn to STAND-BY. Remove power cord from power line. FL Display Cle ar Standby (2) Disconnect the AC power cord from a wall outlet.
  • Page 31 CR-325/325UKD ADJUSTMENT PROCEDURE CLOCK FREQUENCY ADJUSTMENT [When] 1. Exchange Main circuit PC board (NAAR-9575). 2. Exchange crystal (X702). [Procedure] 1. Connect the frequency counter to the test point 32.724K and GND on Main circuit PC board (NAAR-9575). Refer to <Fig-1>...
  • Page 32 (M3062LFHPFP) IC TERMINAL DESCRIPTION CR-325 / 325UKD / 525 / 525UKD Q701 : MAIN MICROPROCESSOR No. PIN NAME SIGNAL NAME I/O Act. DESCRIPTION 1 P96/ANEX1/SOUT4 CDDATA H Command serial data output port to CD signal microprocessor. 2 P95/ANEX0/CLK4 ~CDCLOK O CLK Command transport serial clock output port to CD signal microprocessor.
  • Page 33 (M3062LFHPFP) 62 VCC2 Vcc2 Vcc2 63 P30/A8(/-/D7) USB_MUSHNG USB tip/chip MUCHNG terminal 64 VSS Power source GND 65 P27/AN27/A7(/D7/D6) USB_BUSY USB tip/chip BUSY terminal 66 P26/AN26/A6(/D6/D5) USB_SCL O CLK USB tip/chip clock terminal 67 P25/AN25/A5(/D5/D4) USB_SDA USB tip/chip data terminal 68 P24/AN24/A4(/D4/D3) E2PROM_SDA H E2PROM serial data terminal...
  • Page 34 NR-XX1/FR-155X (uPD780232GC) IC TERMINAL DESCRIPTION CR-325 / 325UKD / 525 / 525UKD Q801 : MAIN MICROPROCESSOR PIN NO. PIN NAME SIGNAL NAME I/O Act. Description 1 VDD1 Power supply. 2 VSS1 Ground. 3 X1 CLOCK Connect a clock oscillator for main system microprocessor.
  • Page 35 1/23 PAGE PARTS LIST CR-325 : Safety parts <DC> : Canadian model <DD> : U.S.A model <PP> : European model <DT> : Taiwanese model <GQ> : Hong Kong model <GR> : China model <B> : Black color model <S> : Silver color model EXPLODED VI EW PARTS LIST REF.
  • Page 36 SPEC LABEL 325MDT 29365116 <SDT> A303 SPEC LABEL 325MGR 29365117 <SGR> A305 LABEL (COVER) 29364123 A505 LABEL (TWN) CR-325 29390216 <1> <SDT> E001 HOLDER (CRAMP) UA-0 V0 27190608-1 F901 FUSE 0.5A-SE-EAWK 252063GR ! <BPP, SGQ, SGR, SGT, SPP> F901 FUSE 1.25A-T/UL-ST2 252251GR ! <BDD, BDC, SDT>...
  • Page 37 Z007 INSULATOR (CDC-A) 24818058 Z008 SPRING (TP-D) 24820071 Z009 SPRING (TP-E) 24820072 Z010 SCREW 2.6*8*w10 801632 PACKING PARTS LIST CR-325 REF. NO. PART NAME DESCRIPTION PART NO. Q'TY REMARKS A500 TAPE (SEROHAN)NITTO NO.29 29110149 A502 LABEL (APV) 29390190 <SGR> A503a...
  • Page 38 29390537 <1> <BDD> A504 CARTON 325MGQ,MGT,MDT 29054818 <BDD, SDT, SGQ, SGT> A504 CARTON CR-325MGR 29054890 <SGR> A505 29092332D A506 LABEL (TWN) CR-325 29390599 <1> <SDT> A507 LABEL (CHINA) 29390371 <SGR> A508 LABEL (CCC) 29364396 <SGR> A511 POLY BAG w430xd550 29100246...
  • Page 39 5/23 PAGE C109 C-CERA C CK725F1E-104Z1 332161040R1 C110 C-CERA C CK725F1E-104Z1 332161040R1 C111 UTSP C CE04W10V-100M(UTSP) 397531017T C112 C-CERA C CK725F1E-104Z1 332161040R1 C113 C-CERA C CK725F1E-104Z1 332161040R1 C116 UTSP C CE04W50V-10M(UTSP) 397581007T C118 UTSP C CE04W10V-100M(UTSP) 397531017T C119 C-CERA C CK725F1E-104Z1 332161040R1 C120...
  • Page 40 6/23 PAGE C165 C-CERA C CK725F1A-105Z1 332181050R1 C166 C-CERA C CK725B1H-102K1 332101025R1 C167 C-CERA C CC725CH1H-150J1 342101504R1 C168 C-CERA C CK725F1E-104Z1 332161040R1 C169 C-CERA C CK725F1E-104Z1 332161040R1 C172 C-CERA C CK725B1H-102K1 332101025R1 C173 C-CERA C CK725B1H-102K1 332101025R1 C174 C-CERA C CK725F1A-105Z1 332181050R1 C176...
  • Page 41 7/23 PAGE C288 ELECT C CE04W25V-4.7M(MA) 355750479T C289 ELECT C CE04W25V-4.7M(MA) 355750479T C290 C-CERA C CC725CH1H-101J1 342101014R1 C305 C-CERA C CK725B1H-223K1 332102235R1 C316 C-CERA C CK725B1H-223K1 332102235R1 C317 C-CERA C CK725B1H-223K1 332102235R1 C348 C-CERA C CK725B1H-103K1 332101035R1 C370 C-CERA C CK725B1H-223K1 332102235R1 C401...
  • Page 42 8/23 PAGE D101or DIODE GP104003E 22380035T D102 DIODE RL1N4003 22380260T D102or DIODE GP104003E 22380035T D103 ZENER D UDZS13B 224551300R2 D104 ZENER D UDZS13B 224551300R2 D105 DIODE D3SBA20 22380271F D105or DIODE RBV402 22380022F D106 C-DIODE 1SS355 223269R2 D106or C-DIODE 1SS352 223234R2 D107 C-DIODE 1SS355...
  • Page 43 9/23 PAGE P401or PIN JACK NPJ-6PDRW386 25045571 P411 BUS BAR BBL60 27141754 P412 BUS BAR BBL60 27141754 P413 BUS BAR BBL50 27141753 P414 BUS BAR BBL40 27141773 P415 BUS BAR BBL25 27141806 P833A CRIMP AS CRIMP AS 20799178 Q101 2SA1015-GR 2211455T Q102 UPC2905AHF-AZ...
  • Page 44 10/23 PAGE R123 C-CARBON R RN72K1J-220JE 435032204R1 R124 C-CARBON R RN72K1J-470JE 435034704R1 R125 C-CARBON R RN72K1J-470JE 435034704R1 R126 C-CARBON R RN72K1J-470JE 435034704R1 R127 C-CARBON R RN72K1J-470JE 435034704R1 R128 C-CARBON R RN72K1J-470JE 435034704R1 R129 C-CARBON R RN72K1J-470JE 435034704R1 R130 C-CARBON R RN72K1J-561JE 435035614R1 R131...
  • Page 45 11/23 PAGE R172 C-CARBON R RN72K1J-103JE 435031034R1 R173 C-CARBON R RN72K1J-103JE 435031034R1 R174 C-CARBON R RN72K1J-224JE 435032244R1 R175 C-CARBON R RN72K1J-224JE 435032244R1 R176 C-CARBON R RN72K1J-224JE 435032244R1 R177 C-CARBON R RN72K1J-000JE 435030004R1 R178 C-CARBON R RN72K1J-000JE 435030004R1 R179 C-CARBON R RN72K1J-272JE 435032724R1 R180...
  • Page 46 12/23 PAGE R254 C-CARBON R RN72K1J-273JE 435032734R1 R255 C-CARBON R RN72K1J-273JE 435032734R1 R261 C-CARBON R RN72K1J-101JE 435031014R1 R262 C-CARBON R RN72K1J-101JE 435031014R1 R289 C-CARBON R RN72K1J-104JE 435031044R1 R291 C-CARBON R RN72K1J-101JE 435031014R1 R292 C-CARBON R RN72K1J-101JE 435031014R1 R293 C-CARBON R RN72K1J-101JE 435031014R1 R294...
  • Page 47 13/23 PAGE R455 C-CARBON R RN72K1J-393JE 435033934R1 R457 C-CARBON R RN72K1J-103JE 435031034R1 R465 C-CARBON R RN72K1J-392JE 435033924R1 R600 C-CARBON R RN72K1J-470JE 435034704R1 R602 C-CARBON R RN72K1J-223JE 435032234R1 R604 C-CARBON R RN72K1J-223JE 435032234R1 R605 C-CARBON R RN72K1J-221JE 435032214R1 R610 C-CARBON R RN72K1J-472JE 435034724R1 R611...
  • Page 48 14/23 PAGE R703 C-CARBON R RN72K1J-470JE 435034704R1 R704 C-CARBON R RN72K1J-470JE 435034704R1 R705 C-CARBON R RN72K1J-471JE 435034714R1 R706 C-CARBON R RN72K1J-471JE 435034714R1 R707 C-CARBON R RN72K1J-471JE 435034714R1 R709 C-CARBON R RN72K1J-103JE 435031034R1 R711 C-CARBON R RN72K1J-101JE 435031014R1 R712 C-CARBON R RN72K1J-103JE 435031034R1 R717...
  • Page 49 X101 CRYSTAL FCX-03-16.9344MHz 3010428R2 X701 CRYSTAL DT-38 (10ppm) 3010467 X702 CERA LOCK CSTCR6M0055-R0 3010397R2 CR-325 Display circuit pc board NADIS-9578-1A/1B Amplifier circuit pc board NAAF-9579-1A/1B Power supply circuit pc board NAPS-9580-1A/1B CIRCUIT NO. PART NAME DESCRIPTION PART NO. Q'TY REMARKS...
  • Page 50 16/23 PAGE X801 CERA LOCK CSTLS5M00G56-A0 3010406T C491 UTSP C CE04W10V-100M(UTSP) 397531017T C501 UTSP C CE04W25V-47M(UTSP) 397554707T C502 UTSP C CE04W25V-47M(UTSP) 397554707T C503 TF C ECQ-B50V-221K 374722215T C504 TF C ECQ-B50V-221K 374722215T C505 UTSP C CE04W50V-22M(UTSP) 397582207T C506 UTSP C CE04W50V-22M(UTSP) 397582207T C509...
  • Page 51 17/23 PAGE C817 C-CERA C CC725CH1H-330J1 342103304R1 C818 C-CERA C CC725CH1H-330J1 342103304R1 C819 C-CERA C CC725CH1H-330J1 342103304R1 C820 C-CERA C CK725F1H-104Z1 332151040R1 C821 ELECT C CE04W16V-47M 355744709T C823 C-CERA C CC725CH1H-221J1 342102214R1 C824 C-CERA C CC725CH1H-221J1 342102214R1 C871 C-CERA C CC725CH1H-102J1 342101024R1 C872...
  • Page 52 18/23 PAGE D951 DIODE D10XB60H 22380337F F901A FUSE HOL NSCT-1P2031 25052133T F901B FUSE HOL NSCT-1P2031 25052133T F901C FUSE LABEL 1.25A125V 29364667 <BDD, BDC, SDT> J501 BUS BAR BBL60 27141754 JL501 JUMPER LEAD JL3 200 B 3J200606B15 JL501A WIRE HOL NSCT-3P874 25051087 JL501B WIRE HOL...
  • Page 53 19/23 PAGE Q495 2SA1162-GR 2214375R2 Q496 2SC2712-GR 2213145R2 Q501 2SC1622A(D17) 2216153R2 Q501or 2SC2713-BL 2213136R2 Q501or 2SC1622A-T-AZ 2216154R2 Q502 2SC1622A(D17) 2216153R2 Q502or 2SC2713-BL 2213136R2 Q502or 2SC1622A-T-AZ 2216154R2 Q503 2SC1622A(D17) 2216153R2 Q503or 2SC2713-BL 2213136R2 Q503or 2SC1622A-T-AZ 2216154R2 Q504 2SC1622A(D17) 2216153R2 Q504or 2SC2713-BL 2213136R2 Q504or 2SC1622A-T-AZ...
  • Page 54 20/23 PAGE Q583 2SA1015-GR 2211455T Q591 2SC2712-GR 2213145R2 Q592 2SC2712-GR 2213145R2 Q801 UPD780232GC-091-8BT-A 22241989R3 Q802 FL TUBE 14-ST-56GNK 212261 Q802A HOLDER (FL) 27191281 Q802B DF TAPE NITTO#500W6 29110023 Q803 2SC2712-GR 2213145R2 Q804 2SC2712-GR 2213145R2 Q821 RN1407 2216260R2 Q901 DTC123JKA 2216690R2 Q903 S-812C50AUA-C3E 22242240R2...
  • Page 55 21/23 PAGE R527 C-CARBON R RN72K1J-183JE 435031834R1 R528 C-CARBON R RN72K1J-183JE 435031834R1 R533 METAL O R RS1/2WBJ-33 443523304T R534 METAL O R RS1/2WBJ-33 443523304T R535 METAL O R RS1/2WBJ-39 443523904T R536 METAL O R RS1/2WBJ-39 443523904T R537 C-CARBON R RN72K1J-181JE 435031814R1 R538 C-CARBON R...
  • Page 56 22/23 PAGE R585 C-CARBON R RN72K1J-333JE 435033334R1 R586 C-CARBON R RN72K1J-333JE 435033334R1 R587 C-CARBON R RN72K1J-473JE 435034734R1 R588 C-CARBON R RN72K1J-183JE 435031834R1 R589 C-CARBON R RN72K1J-103JE 435031034R1 R591 C-CARBON R RN72K1J-473JE 435034734R1 R592 C-CARBON R RN72K1J-473JE 435034734R1 R593 C-CARBON R RN72K1J-333JE 435033334R1 R594...
  • Page 57 23/23 PAGE R859 C-CARBON R RN72K1J-101JE 435031014R1 R860 C-CARBON R RN72K1J-332JE 435033324R1 R893 METAL O R RS1/2WBJ-390 443523914T R894 METAL O R RS1/2WBJ-390 443523914T R901 C-CARBON R RN72K1J-153JE 435031534R1 R902 C-CARBON R RN72K1J-392JE 435033924R1 R903 C-CARBON R RN72K1J-102JE 435031024R1 R904 METAL O R RS1/2WBJ-47 443524704T...
  • Page 58 Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8124 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/ ONKYO EUROPE ELECTRONICS GmbH Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.com/...
