CD Player
C-1VL
Instruction Manual
Thank you for purchasing an Onkyo CD Player. Please
read this manual thoroughly before making connec-
tions and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new CD Player.
Please retain this manual for future reference.
Contents
Introduction .................................... 2
Connections ................................. 10
Operation...................................... 12
Troubleshooting........................... 17
Specifications .............................. 18
E
n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-1VL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Onkyo C-1VL

Summary of Contents for Onkyo C-1VL

  • Page 1 CD Player C-1VL Instruction Manual Thank you for purchasing an Onkyo CD Player. Please read this manual thoroughly before making connec- tions and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new CD Player.

  • Page 2: Important Safety Instructions

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING QUALIFIED PERSONNEL.

  • Page 3: Precautions

    2. AC Fuse The AC fuse inside the C-1VL is not user serviceable. If you cannot turn on the C-1VL, contact your Onkyo dealer. 3. Care Occasionally you should dust the C-1VL all over with a soft cloth.

  • Page 4: About Cds

    We, ONKYO EUROPE ELECTRONICS GmbH LIEGNITZERSTRASSE 6, 82194 GROEBENZELL, GERMANY declare in own responsibility, that the ONKYO product described in this instruction manual is in compliance with the corresponding technical standards such as EN60065, EN55013, EN55020 and EN61000-3-2, -3-3. GROEBENZELL, GERMANY...

  • Page 5: Table Of Contents

    Making Analog Connections to Amplifier and Recorder... 11 Making Digital Connections to Amplifier and Recorder ... 11 Operation Turning On the C-1VL ... 12 Connecting the Supplied Power Cord ... 12 Turning On the C-1VL ... 12 Enabling the Digital Signal Output ... 12 Playing CDs...

  • Page 6: Features

    Remote Controller (RC-544C) & Two batteries (AA/R6) Audio Cable [1] In catalogs and on packaging, the letter added to the end of the product name indicates the color of the C-1VL. Speci- fications and operation are the same regardless of color.

  • Page 7: Front & Rear Panels

    Press to select the previous or next track. Press and hold to fast reverse and fast forward when playing CDs. DIGITAL OUTPUT button Press to turn on/off the digital output on the C-1VL. Play/Pause indicators Illuminate in play or pause mode. TOTAL/REMAIN indicator Illuminates when the remaining time is shown.

  • Page 8: Remote Controller

    MEMORY CLEAR PLAY The RC-573A remote controller, which is supplied with the Onkyo’s Integrated Stereo Amplifier A-1VL, can be used to operate the C-1VL. PLAY [ Stop [ Pause [ ] button Number buttons Use these buttons to enter a track number.

  • Page 9: Inserting The Batteries

    Remote Controller—Continued Inserting the Batteries Detach the battery cover. Insert the two R6 (size AA) batteries. Be sure to match the + and – ends of the batter- ies to the diagram inside the battery compart- ment. Attach the battery cover.

  • Page 10: Cables And Connectors

    The audio quality is same as for coaxial. You can connect a DAT or CD recorder with a digital input to the C-1VL for digital dubbing. The audio quality is same as for optical. You can connect a DAT or CD recorder with a digital input to the C-1VL for digital dubbing.

  • Page 11: Connections

    Connections The C-1VL is equipped with three types of output terminals: AUDIO OUTPUT ANALOG, AUDIO OUTPUT DIGI- TAL (OPTICAL), and AUDIO OUTPUT DIGITAL (COAXIAL). Make appropriate connections according to your audio devices such as amplifier and recorder. Making Analog Connections to Amplifier and Recorder...

  • Page 12: Turning On The C-1Vl

    Connecting the Supplied Power Cord Plug the supplied power cord into this AC INLET. • Before you plug in the C-1VL, confirm that all con- nections have been made properly. • Turning on the power may cause a momentary power surge, which might interfere with other electrical equipment on the same circuit, such as computers.

  • Page 13: Playing Cds

    [ ] button to fast forward, or the [ to fast reverse. Using the buttons on the C-1VL: During playback or while playback is paused, press and hold the [ ] button to fast forward, or the [ to fast reverse.

  • Page 14: Selecting Tracks By Number

    [2]. Displaying the Remaining Time POWER DISPLAY DISPLAY During playback, press the [DIS- PLAY] button on the C-1VL repeat- edly to display the informations. Elapsed track time: Remaining track time: Remaining disc time: If you’re using the Memory function to...

  • Page 15: Random Playback

    Playing CDs—Continued Random Playback With the Random function you can play tracks in ran- dom order. Press the [RANDOM] button. The RANDOM indicator appears on the display and random playback starts. To cancel random playback, stop playback, or press the [RAN- DOM] button so that the RAN- DOM indicator disappears.

  • Page 16: Memory Playback

    Playing CDs—Continued Memory Playback With the Memory function you can make a custom pro- gram of your favorite tracks. Number buttons While stopped, press the [MEMORY] button. The MEMORY indicator appears on the display. To add a track to your program, use the number buttons.

  • Page 17: Troubleshooting

    Troubleshooting If you have any trouble using your C-1VL, check the following table for possible causes and remedies. If you still can’t resolve the issue yourself, please contact your Onkyo dealer. Trouble No power. The power cord is not connected properly.

  • Page 18: Specifications

    Specifications Power Supply Power Consumption Dimensions (W × H × D) Weight Operation Condition Temperature/Humidity Frequency Response SN Ratio Audio Dynamic Range THD (Total Harmonic Distortion) Audio Output Digital Optical Digital Coaxial Analog Specifications and external appearance are subject to change without notice as a result of product improvement. AC 230-240 V, 50 Hz 435 W ×...
  • Page 19 Memo...
