OWNER'S MANUAL
Instructions for the installation, operation
This Traulsen unit is built to our highest quality standards. We build our refrigerators, freezers and heat-
ed cabinets this way as a matter of pride. This philosophy has made Traulsen the leader in commercial
refrigeration since 1938. We thank you for your choice and confidence in Traulsen equipment and we know
you will receive many years of utility from this equipment.
All Traulsen units are placed on a permanent record file with the service department. In the event of any future
questions you may have, please refer to the model and serial number found on the name tag affixed to the unit.
Should you need service, however, call us on our toll free number, 800-825-8220 between 7:30 am and 4:30 pm
CST, Monday-Friday. It is our pleasure to help and assist you in every possible way.
COMPLETE THE FOLLOWING INFORMATION PRIOR TO UNIT INSTALLATION
INITIAL START DATE:
MODEL TYPE:
COMPANY/INDIVIDUAL NAME:
INSTALLER:
FORM NUMBER TR35743 (REV. 09-03-15)
Quality Refrigeration
and maintenance of all Traulsen:
R & A Series Reach-In & Roll-In Refrigerators*
R & A Series Pass-Thru & Roll-Thru Refrigerators*
R & A Series Reach-In & Roll-In Freezers*
R & A Series Reach-In Refrigerator/Freezers*
R & A Series Reach-In & Roll-In Hot Food Cabinets*
R & A Series Pass-Thru & Roll-Thru Hot Food Cabinets*
* Please Note: This manual is intended for use with the above referenced equipment manufactured
after January 01, 2013. To obtain a copy of the correct Owner's Manual to support the same
products manufactured prior to this date, please contact Traulsen Service at (800) 825-8220.
INSTALLER
SERIAL NO.
P/N 375-60176-00

Advertisement

Table of Contents
loading

Related Manuals for Traulsen R & ASeries

Summary of Contents for Traulsen R & ASeries

  • Page 1 All Traulsen units are placed on a permanent record file with the service department. In the event of any future questions you may have, please refer to the model and serial number found on the name tag affixed to the unit.

  • Page 2: Table Of Contents

    I. THE SERIAL TAG The serial tag is a permanently affixed sticker on which is re- corded vital electrical and refrigeration data about your Traulsen product, as well as the model and serial number. This tag is located in the upper right interior compartment on all reach-in/ pass-thru and roll-in/roll-thru refrigerator, freezer and dual-temp models.

  • Page 3: Receipt Inspection

    III. INSTALLATION III. a - LOCATION: Select a proper location for your Traulsen unit, away from extreme heat or cold. Allow enough clearance be- tween the unit and the side wall in order to make use of the door stay open feature at 120° (self-closing feature operates up to 90°).

  • Page 4: D-Shelf Pins

    After installing the ramp(s), it too should be sealed to the floor. Please note that Traulsen units are not designed to be moved while on legs. If the unit requires moving, a Bumper strips are secured to the back of Roll-In mod- pallet jack or forklift should be used to prevent damage.

  • Page 5: H-Remote Installation

    In order to assure optimum performance, the Failure to use this component may allow cold air to condensing unit of your Traulsen unit MUST have an migrate down the drain line, resulting in condensation adequate supply of air for cooling purposes. Therefore, on the rear of the cabinet.

  • Page 6: Operation

    The most important thing you can do to insure a long, is fully defrosted and the compressor operation is resumed, reliable service life for your Traulsen is to regularly clean defrost heaters are automatically turned off. The coil fans are the condenser coil.

  • Page 7: B-Hinge Replacement

    V. CARE & MAINTENANCE (cont’d) V. a - CLEANING THE CONDENSER: V. c - REPLACING THE GASKETS: Once the screws are removed, the panel can be pivoted After the corners are properly inserted, work your way upwards allowing full access to the front facing towards the center from both ends by gently hitting with condenser (see figure 9).

  • Page 8: G-Replacing The Light Bulb

    VI. OTHER V. g - REPLACING THE LIGHT BULB: VI. a - SERVICE INFORMATION: All Traulsen R & A Series models are supplied with Before calling for service, please check the following: incandecent lighting unless optional fluorescent lighting was ordered (except for sliding glass door...

  • Page 9: A-Control Features

    VII. The INTELA-TRAUL Control System ® Your new Traulsen Refrigerator, Freezer or Hot Food cabinet is equipped with a state-of-the- art electronic microprocessor INTELA-TRAUL control, which precisely regulates opera- ® tion and provides alarms when problems occur. It is supplied from the factory completely ready for use and requires no adjustment (except Hot Food units which are set in the “OFF”...

  • Page 10: Intela-Traul

    VII. INTELA-TRAUL (continued) ® VII. a - ALARM EXPLANATIONS: *NOTE: Explanation of alarms assume the audible alarm style is set at a 3-second burst or a continuous audible alarm. References to the audible alarm do not apply if the audible alarm style is set to OFF (Refer to page 18 for setting the audible alarm style).

  • Page 11: C-Control Panel

    VII. INTELA-TRAUL (continued) ® VII. c - CONTROL PANEL: LED FOR ° INTELA-TRAUL °F 3-DIGIT (RED) LED DISPLAY DOOR OPEN ICON W / LED ALARM CANCEL BUTTON DEFROST ICON FREEZER W / LED VII. d - NOTES TO THE USER: You only have 20-30 seconds between button pushes.

  • Page 12: F-Customer Service Parameters

    VII. INTELA-TRAUL (continued) ® VII. f - CUSTOMER SERVICE PARAMETERS: Listed below are the available parameters in the order they appear, using the down arrow key on the controller. You can use either the up or down arrow keys to scroll through the options. Thermostat Set Point Defrost Lockout 2 Set Point Differential...

  • Page 13: H-Adjusting Thermostat Set Point Low

    VII. INTELA-TRAUL (continued) ® VII. h - ADJUSTING THE THERMOSTAT SET POINT Differential: This parameter sets the set point differential of the desired cabinet temperature range. Typically, freezers and refrigerators will range from 2° F to 5° F for this parameter setting. This parameter is preset at the factory and does not have to be adjusted unless the customer chooses to do so.

  • Page 14: J-Setting The 24-Hour Clock

    VII. INTELA-TRAUL (continued) ® VII. j - SETTING THE 24-HOUR CLOCK: The internal timeclock must be set in order for the data storage memory to correctly log events and to allow any defrost lockout to occur at the correct time of day. If the clock is not set, the control assumes the time is 12 a.m.

  • Page 15: K-Setting The Date

    VII. INTELA-TRAUL (continued) ® VII. k - SETTING THE DATE: The date must be set in order for the data storage memory to correctly log events. Follow the instruc- tions to enter the customer access code on page 10. When the control displays Thermostat Set Point, press the down arrow key until the control display reads...

  • Page 16: M-Starting A Manual Defrost

    FREEZER DEFROST ICON NOTE: Traulsen refrigerator units also have an off-cycle defrost once an hour, at which time the control will read . This defrost is time terminated and can last 10 minutes (dEF will be displayed for 22-27 minutes).

  • Page 17: N-Setting Defrost Lockouts

    VII. INTELA-TRAUL (continued) ® VII. n - SETTING THE DEFROST LOCKOUTS: The defrost lockout parameters allow the customer to prevent the unit from going into a defrost cycle for two hours during a set timeframe. Customers can set up to four defrost lockout parameters. They are all programmed the same way.

  • Page 18: O-Adjusting The Room Temperature Offset

    VII. INTELA-TRAUL (continued) ® VII. o - ADJUSTING THE ROOM TEMPERATURE OFFSET: The room temperature offset parameter allows a service technician or end user the ability to have the display show a temperature that is within three degrees of the actual temperature being read by the cabinet air sensor.

  • Page 19: Q-Viewing Sensor Temperatures

    VII. INTELA-TRAUL (continued) ® VII. q - VIEWING SENSOR TEMPERATURES: These parameters allow a service technician or customer to view the temperature of all sensors within the unit. The temperatures cannot be adjusted. Follow the instructions to enter the customer access code on page 10. When the control displays Thermostat Set Point , press the DOWN arrow key unit the display reads...

  • Page 20: T - Hot Food Units, Turning The Unit Off/On

    VII. INTELA-TRAUL (continued) ® VII. t - HOT FOOD UNITS, TURNING THE UNIT OFF/ON: After the temperature has been set, the customer can continuously turn the unit OFF and then back ON to the same temperature. To turn the unit ON /OFF press the alarm cancel button , (please note that this feature is not available on versions of the control manufactured prior to September 2000), or if an alarm warning condition is present, use the alternative ON/OFF activation method.

  • Page 21: Trouble Shooting Guide

    VIII. TROUBLE SHOOTING GUIDE FIND YOUR PROBLEM HERE REMEDY 1. Condensing unit fails to start. Check if cord & plug has been disconnected. Check INTELA-TRAUL temperature setting. ® 2. Condensing unit operates for Are doors closing properly? prolonged periods or continuously. Dirty condenser or filter.

  • Page 22: Spare Parts List

    XI. SPARE PARTS LIST PART PART # DESCRIPTION Bulb, Fluorescent 337-27690-00 Replacement bulb for fluorescent light models Bulb, Incandescent 378-29776-00 Replacement bulb for incandescent light models Bulb Cover 337-30858-00 Replacement bulb cover for incandescent light models Caster, 6” High 344-13140-01 Optional caster for all reach-in models Caster, 4”...

  • Page 23: Stainless Steel Overview

    300 series stainless steel (anodized aluminum is and corrosion. used for A-Series). The stainless steel finish on Traulsen R & A Series should XIII. CARE OF STAINLESS STEEL retain its appearance throughout the products usable lifetime. However, some care is required to maintain XIII.

  • Page 24: Care Of Stainless Steel

    XIII. c - CLEANING SUMMARY - DO’S & DONT’S: DEALING WITH RUST AFTER THE FACT (cont’d): STEP THREE - Apply a preservative polish, such as To summarize the proper cleaning of Traulsen “Sheila Shine,” to the affected area (see section II. e). refrigeration products, always follow the below guidelines.

  • Page 25: Warranty Information

    “Defective Part Return” – All claimed defective r e p l a c e m e n t part(s) must be returned to TRAULSEN for i n s p e c t i o n within 30 days from the date of the repair.
  • Page 26 HOURS OF OPERATION: Monday thru Friday 7:30 am - 4:30 pm CST Traulsen 4401 Blue Mound Road Fort Worth, TX 76106 Phone: (800) 825-8220 Fax-Svce: (817) 740-6757 Website: www.traulsen.com Quality Refrigeration © 2015 Traulsen - All Rights Reserved...
