- Page 1 INSTRUCTION MANUAL...
-
Page 2: Operator Manual
XTI-601 MP OperatOr Manual ISSue 1... - Page 3 Thank you and congratulations on choosing Parweld. This Owner’s Manual is designed to help you get the most out of your Parweld products. Please take time to read the Safety precautions. They will help you protect yourself against potential hazards in the workplace. With proper maintenance this equipment should provide years of reliable service.
-
Page 4: Table Of Contents
Contents Page 1.0 Safety Precautions 2.0 Product description 3.0 Technical Specifications 4.0 Description of controls 5.0 Installation 5.1 Unpacking the Machine 5.2 Location 5.3 Input and grounding connection 5.4 MIG welding torch setup 5.5 MMA welding torch setup 5.6 TIG welding torch setup 6.0 Operation 6.1 MIG Welding guide 6.2 MMA welding guide... -
Page 5: Safety Precautions
Use protective screens or barriers to protect others Use only well-maintained equipment. Repair or from flash, glare and sparks; warn others not to watch replace damaged parts at once. Maintain unit the arc. according to manual. Wear protective clothing made from durable, flame www.parweld.com... -
Page 6: Product Description
HOT PARTS can cause severe burns. Do not touch hot parts with bare hands. Allow cooling period before working on gun or torch. To handle hot parts, use proper tools and/or wear heavy, insulated welding gloves and clothing to prevent burns. www.parweld.com... -
Page 7: Technical Specifications
18) Burn back control for MIG welding. 16.4V 14.6V 13.6V ON OFF Switch for switching on or off the mains supply to the machine. (mounted on the rear of the machine) Note the output of the machine is permanently on www.parweld.com... -
Page 8: Installation
8. Slide the wire spool all the way onto the shaft and refit the plastic retaining nut. Have a qualified electrician connect the input plug. For long runs over 30m , larger copper wires should www.parweld.com... -
Page 9: Mma Welding Torch Setup
5.4.3 Torch installation Note a special connector is require with a combined gas and power Dinse connector this type of Your Parweld MIG/MAG Welding Torch has been torch is available from Parweld supplied ready to weld. It has been supplied with... -
Page 10: Mig Welding Guide
6.1.1 Optimising weld parameters NOTE These settings are guidelines only. Material and wire type, joint design, fit up, position, shielding gas, etc. affect settings. Produce test welds to be sure they comply to specifications. www.parweld.com... -
Page 11: Tig Welding Guide
1/16” (1.6mm) 60 – 115 3/32” (2.4mm) 100 – 165 Metals being joined & electrode comments Mild steel 6013 ideal electrodes for all general purpose work. Features include outstanding operator appeal, easy arc starting and low spatter. www.parweld.com... -
Page 12: Fault Finding
(c) Allow wider Shielding gas selection (d) Incorrect (d) Use correct sequence build-up Alloy Shielding gas sequence Aluminium & Pure Argon alloys Carbon steel Pure Argon Stainless steel Pure Argon Nickel alloy Pure Argon Copper Pure Argon Titanium Pure Argon www.parweld.com... - Page 13 Electrode Electrode is Connect the (f) Use electrodes melts when connected to the electrode to the designed for arc is struck ‘+’ terminal ‘-‘ terminal position in which welding is done, otherwise proper control of slag is difficult. www.parweld.com...
- Page 14 Refer work piece welding current to basic TIG welding guide. (b) Absence of oxides in the Weld (b) Refer basic pool. TIG welding guide for ways to reduce arc flutter www.parweld.com...
- Page 15 (b) Possible over (b) Check is off, no voltage voltage and output, the if necessary (c) Internal fault fan is not move machine with the machine operating to alternative supply (c) Have a qualified service engineer inspect then repair the welder www.parweld.com...
-
Page 16: Accessories
No employee, agent, or representative of Parweld is authorized to change this warranty in any way or grant any other warranty. Stock Code Description...
