Intersil ISL6227EVAL1 Setup Procedure

®
This document describes the setup procedure for the
ISL6227 Evaluation Board DDR implementation. For
information about the dual switcher application, please refer
to the ISL6227EVAL2 Evaluation Board Setup Procedure.
General Description
The ISL6227 can control two output voltages adjustable from
0.9V to 5.5V. The ISL6227 combines two synchronous PWM
voltage regulators into a single IC. When the DDR pin is set
to high, it transforms the IC into a complete DDR application.
Channel 1 can be set at a fixed 300kHz forced PWM mode or
an automatic mode with hysteretic diode-emulation at light
load and constant-frequency PWM synchronous rectification
at heavy load, assure high efficiency over a wide range of
conditions. Channel 2 is set at fixed 300kHz forced PWM
mode with synchronous rectification because of sinking
current requirement for DDR applications. Both channels use
the lower MOSFET r
DS(ON)
high efficiency operations. It is preferred that the input of the
second channel connects to the output of the first channel in
DDR applications.
Voltage-feed-forward ramp modulation, current mode control,
and internal feedback compensation provide fast response to
input voltage and output load transients.
ISL6227 monitors the output voltage of CH1 only by the
voltage on VSEN1 pin. PGOOD1 (power good) signal is
asserted after its soft-start sequence has completed, and the
output voltage within -11%/+15% of the set point. PGOOD2
pin is used to bring the VDDQ/2 into the chip as the
reference voltage of the second channel error amplifier.
Built-in overvoltage protection prevents the output from
going above 115% of the set point by holding the lower
MOSFET on and the upper MOSFET off. When the output
voltage decays below the overvoltage threshold, normal
operation automatically resumes. Once the soft-start
sequence has completed, undervoltage protection will latch
the channel off if the output drops below 75% of its set point
value. There is no overvoltage protection for Channel 2 in
DDR application.
Adjustable overcurrent protection (OCP) monitors the
voltage drop across the r
DS(ON)
more precise current-sensing is required, an external current
sense resistor may be used. The OCP threshold can be
adjusted by the resistor on OCSET pin and the current
sensing gain can be adjusted by the resistor from ISEN pin
to the phase node of the converter. Any overcurrent on the
second channel will be reflected to the first channel. There is
no OCP for the second channel.
In order to alleviate the interaction between the two channels
caused by the switching noise, a phase shift has been
implemented on the controller. If the input voltage is above
5V, the VIN pin should connect the input voltage. This would
provide the input voltage feed forward function and
command the second channel 90 degree lagging the first
channel. If the input voltage is at 3.3V, the VIN pin should
connect to ground. This would result in a fixed ramp for the
PWM comparator and command an in-phase operation of
the two channels.
ISL6227EVAL1 DDR Evaluation Board Setup
Application Note
as the current sense element for
of the lower MOSFET. If
1
June 2004
Features
• Provides regulated output voltage in the range of 0.9V–5.5V
- High efficiency over wide load range
- Synchronous buck converter with hysteretic operation at
light load
- Selection of hysteretic/CCM mode on channel 1. Forced
CCM on channel 2 for DDR application
• Uses MOSFET r
current-sense resistor for precision overcurrent protection
• Overvoltage, undervoltage and overcurrent protection
• Undervoltage lock-out on VCC pin
• Dual input voltage mode operation
- Operates directly from battery 5V to 24V input
- Operates from 3.3V or 5V system rail
• Excellent dynamic response
- Combined voltage feed-forward and current mode
control
• Power-good signal for channel 1 in DDR application
Ordering Information
PART #
ISL6227CA
ISL6227CAZ
(Note)
ISL6227CA-T
ISL6227CAZ-T
(Note)
NOTE: Intersil Lead-Free products employ special lead-free material
sets; molding compounds/die attach materials and 100% matte tin
plate termination finish, which is compatible with both SnPb and lead-
free soldering operations. Intersil Lead-Free products are MSL
classified at lead-free peak reflow temperatures that meet or exceed
the lead-free requirements of IPC/JEDEC J Std-020B.
Pinout
LGATE1
PHASE1
UGATE1
OCSET1
|
1-888-INTERSIL or 321-724-7143 Intersil (and design) is a registered trademark of Intersil Americas Inc.
All other trademarks mentioned are the property of their respective owners.
Procedure
for current sensing or uses
DS(ON)
TEMP. (°C) PACKAGE
-10 to 100 28 Ld SSOP
-10 to 100 28 Ld SSOP (Lead-Free)
-10 to 100 28 Ld SSOP Tape and Reel M28.15
-10 to 100 28 Ld SSOP Tape and Reel
(Lead-Free)
ISL6227 (28 LD SSOP) TOP VIEW
1 28
GND VCC
2 27
LGATE2
3 26
PGND1 PGND2
4 25
PHASE2
5 24
UGATE2
BOOT1 6 23 BOOT2
ISEN1 7 22 ISEN2
EN1 8 21 EN2
VOUT1 9 20 VOUT2
VSEN1 10 19 VSEN2
11 18 OCSET2
SOFT1 12 17 SOFT2
DDR 13 16 PG2/REF
VIN 14 15 PG1
Copyright Intersil Americas Inc. 2004. All Rights Reserved
AN1067
PKG
DWG #
M28.15
M28.15
M28.15
