installation instructions

WARNING:
The electrical connection of this oven should be carried out by a qualified electrician,
according to the instructions in this guide and in compliance with the current regulations.
In the event of any damage that occurs as a result of improper connection or installation,
the warranty will not be valid. This appliance must be earthed.
Installing the built-in oven
1 The space cut out into the work surface where the oven will be placed needs to be
at least 60cm wide, 58cm deep and 59.5cm high. A minimum gap of 2.5cm
between the work surface and the control panel, and a distance of 5cm between
the work surface and top of the oven is needed, in order to be able to get to the
back of the oven if necessary and for easy access when sliding the oven out.
(refer to detail A).
23/5/06
A
DETAIL A
17:26 Page 13
Isolation switch
13
