CITROEN Berlingo Owner's Handbook Manual page 73

Removing the bench seat
- If necessary, move the front seats
forward.
- Place the bench seat (1/3 section and/or
2/3 section) in the fully folded position.
Refer to the "fully folded position"
described on the previous page.
Downloaded from www.Manualslib.com
- Tilt the entire seat rearwards by
approximately 45°.
- Lift the bench seat vertically to the
limit of the anchorages.
- Straighten bench seat by tilting it
forwards then lift it.
manuals search engine
Refitting the bench seat
- Offer up the bench seat (1/3 section
and/or 2/3 section) vertically.
- Place the hooks between the
two bars.
- Fold the bench seat rearwards.
To return the bench seat
(1/3 section and/or 2/3 section)
to the "passenger transportation"
position, refer to the "fully folded
position" described on the
previous page.
Seats
3
