CITROEN Berlingo Owner's Handbook Manual page 153

4. Foglamps
Type C , H1 - 55W
- Remove the three clips and the
screw securing the wheelarch liner,
located below the bumper.
- Move the wheelarch liner upwards.
- Remove the foglamp by removing
the screw, which can be accessed
via the hole provided for this
purpose in the bumper, using a
Torx 30 screwdriver.
©
- Unclip the foglamp by squeezing
the clip to release it.
- Remove the foglamp from the outside.
- Turn the yellow cover a 1/4 turn to open.
- Separate the clips which secure
the base of bulb on each side to
release the bulb.
- Remove the bulb by pulling,
keeping it straight.
- Insert the new bulb, reposition the
clips around the base of the bulb
and carry out the operations in
reverse order to put the lamp unit
and the bumper back in position.
Downloaded from www.Manualslib.com
SIDE REPEATER
Type A , WY5W - 5W (amber)
- Push the repeater towards the rear
and disengage it by pulling the
front.
- Contact a CITROËN dealer to
obtain a new repeater which is a
sealed component.
- To refi t, engage the repeater
towards the rear and bring it
towards the front.
manuals search engine
Changing a bulb
COURTESY LAMPS
Type A , 12V5W - 5W
- Unclip the lens by sliding a
screwdriver in the slots on each
side of the courtesy lamp.
- Pull the bulb out and change it.
- Clip the lens in its housing and
ensure that it is secured correctly.
Front/Rear
7
