KS 3135-90
Refrigerator
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KS 3135-90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gram KS 3135-90

Summary of Contents for Gram KS 3135-90

  • Page 1 KS 3135-90 Refrigerator User Guide...
  • Page 2 Please read this manual first! Dear Customer, We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service. For this, we recommend you to carefully read the entire manual of your product before using it and keep it at hand for future references.

  • Page 3: Table Of Contents

    CONTENTS 4 Preparation 1 Your refrigerator 2 Important Safety 5 Using your refrigerator 14 Warnings Using interior compartments ....14 Defrosting of the appliance ....14 Intended use ........4 Cooling ..........15 General safety ........4 Food storage ........15 HCA Warning ........6 Things to be done for energy saving ..6 6 Maintenance and cleaning 3 Installation...

  • Page 4: Your Refrigerator

    Your refrigerator Movable shelves Vegatable drawer Interior light & Thermostat knob Adjustable front feet Defrost water collection channel - Drain Table-top tube Door shelves Glass shelf Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.

  • Page 5: Important Safety Warnings

    Important Safety Warnings Please review following information. If these are not followed, materials should never be used in personal injury or material damage cleaning and defrosting processes of may occur. Otherwise, all warranty and your refrigerator. In such cases, the reliability commitments will become vapor might get in contact with the invalid.
  • Page 6 contain flammable gases (e.g. spray) passed to the next owner of the as well as the explosive materials refrigerator if the owner changes. should never be kept in the appliance. sure that you do not damage the or other means to accelerate the power cord.

  • Page 7: Hca Warning

    HCA Warning temperature conditions such as Your product is equipped with vaccine, temperature sensitive a cooling system that contains medicines, scientific materials etc R600a: should not be kept in refrigerator. This gas is flammable. Therefore, pay attention to not damaging the an extended period of time it should cooling system and piping during be unplugged.

  • Page 8: Installation

    Installation 2. You can install the 2 spacers as Please remember that the illustrated in the figure. Spacers will manufacturer shall not be held liable if provide the required distance between the information given in the user guide your refrigerator and the wall in is not observed.

  • Page 9: Disposing Of The Packaging

    Placing and Installation Electric connection 1. Install your refrigerator in a place Connect your product to a grounded that allows ease of use. socket which is being protected by a fuse with the appropriate capacity. 2. There must be appropriate air Important: ventilation around your refrigerator in order to achieve an efficient operation.
  • Page 10 Replacing the interior light bulb Should the light fail to work switch off at the socket outlet and pull out the mains plug. Follow the below instructions to check if the light bulb has worked itself loose. If the light still fails to work obtain a replacement E14 screw cap type 15 Watt (Max) bulb from your local electrical store and then fit it as follows:...

  • Page 11: Adjusting The Legs

    Adjusting the legs Installation (Under the counter) You can balance your refrigerator by turning the front legs of it as illustrated in the figure. The corner where the leg be 820mm. exists is lowered when you turn in the (!) Cookers or other heat sources must direction of black arrow and raised not be placed above the counter where when you turn in the opposite direction.
  • Page 12 595 mm 55 mm...
  • Page 13 Reversing the doors Proceed in numerical order 60° 60°...

  • Page 14: Preparation

    Preparation Your refrigerator should be installed at least 30 cm away from heat sources such as hobs, ovens, central heater and stoves and at least 5 cm away from electrical ovens and should not be located under direct sunlight. The ambient temperature of the room where you install your refrigerator should at least be 10°C.

  • Page 15: Using Your Refrigerator

    Using your refrigerator The interior temperature also depends on ambient temperature, the frequency with which the door is opened and the amount of food kept inside. Frequently opening the door causes the interior temperature to rise. For this reason, it is recommended to close the door again as soon as possible after use.

  • Page 16: Cooling

    Cooling Food storage The fridge compartment is for the short-term storage of fresh food and drinks. Store milk products in the intended compartment in the refrigerator. holder or in the bottle shelf of the door. bag in the compartment at the very bottom of the refrigerator.

  • Page 17: Maintenance And Cleaning

    Maintenance and cleaning A Never use gasoline, benzene or similar substances for cleaning purposes. Protection of plastic B We recommend that you unplug the surfaces freezer before cleaning. meals in your freezer in unsealed instrument, soap, household cleaner, containers as they may damage the detergent and wax polish for cleaning.

  • Page 18: Recommended Solutions For The Problems

    Recommended solutions for the problems money. This list includes frequent complaints that are not arising from defective workmanship or material usage. Some of the features described here may not exist in your product. The freezer does not operate. Condensation on the side wall of the freezer. humid ambient conditions.
  • Page 19 The freezer is running frequently or for a long time. Large freezers operate for a longer period of time. with food. Cooling down of the freezer completely may last for a couple of hours longer. causes longer running of the freezer until it reaches the safe storage temperature. warm air that has entered into the freezer causes the freezer to run for longer periods of time.
  • Page 20 There are noises coming from the refrigerator like liquid spilling or spraying. refrigerator. It is normal and not a fault. There is a noise like wind blowing. Condensation on the inner walls of the refrigerator. fault. less frequently. Humidity occurs on the outside of the refrigerator the humidity is less, condensation will disappear.
