Code Alarm CA 6150 Installation Manual page 13

6 BLACK/WHITE
Locate the vehicle's neutral safety circuit.
Verification: This wire registers ( - ) voltage when the vehicle's gear selector
is in park or neutral.
Connect the BLACK/WHITE neutral safety input wire to the neutral safety wire of
the vehicle or an optional toggle switch. The remote start feature will not operate
unless this input is supplied with a ground source.
7 BROWN/RED
Locate the vehicle's brake light wire at the brake pedal mounted switch.
Verification: This wire registers positive voltage when the brake pedal is
pressed.
Connect the BROWN/RED wire to the vehicle's brake light wire.
8 PURPLE/WHITE
Locate the vehicle's ignition coil or fuel injector in the engine compartment.
Verification: Test using the following procedure:
1. Set voltmeter to AC VOLTS.
2. Attach positive lead of a volt meter to a constant 12 volt source.
3. Attach negative lead of a volt meter to the wire to be tested.
4. Start the engine.
5. Have someone press on the gas pedal slightly as you monitor the meter. If
connected to the correct wire, the voltage reading will increase as the engine's
RPM increases.
Connect the PURPLE/WHITE wire to the negative side of the vehicle ignition coil
or fuel injector.
2009 Audiovox Electronics Corporation. All rights reserved.
NEUTRAL SAFETY INPUT ( - )
BRAKE INPUT ( + )
TACH INPUT
