Front View And Controls - Currys Essentials C16LDVB11 Instruction Manual

Front.View.and.Controls
Item
1 POWER.LED
2 IR.(Infrared.Receiver)
3.
4.
5. Disc.Slot
6. INPUT.
7 MENU
8. CH.+./.–.
9. VOL.+./.–
10
C16LDVB11_IB_110404_Annie.indd 7
1 2
Description
Illuminates green when the TV is turned on. Illuminates red when the TV is in standby
mode. The LED will flash green and red when the timer programming has started in
the standby mode.
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
Press to eject disc. (DVD mode)
Press to start playback or pause. (DVD mode)
Insert the disc with the label side facing backwards to you (12 cm discs only. Don't
insert 8 cm discs)
Press to select among different input signal sources:
DTV / ATV / SCART / YPbPr / PC / HDMI1 / HDMI2 / AV / DVD / DMP.
Confirmed the selection on OSD menu.
Displays the OSD (on screen display) menu.
Press to select a channel or select a sub-menu from the OSD menu.
Adjusts the volume.
Press to select and adjust a setting in the OSD menu.
Switches the TV on from standby mode.
Switches the TV back to standby mode.
6
3
7
4
8
5
9
10
7
GB
11年4月4日 下午6:04
