Page 5 Input Connector Select
This page is defined as input connector select . There are two connectors for
selection, one is BNC, the other is DB-15. Both of them are capable of automatically
detecting used connector ( either BNC or DB-15) and show it highlighted on the
window. If the two connectors are connected simultaneously, user can press the "
or "
" and "S" key to select the desired connector.
Press
to locate the page.
Press
or
Press
to select the icon.
Press
to save the setting.
DB-15 Connector
BNC Connector

Timing Setting

By making adjustments of your video card settings, you can set the timing and the
refresh rate to your preferences. The monitor will automatically save the settings.
Your monitor can accept vertical frequency ranging from 50 Hz to 160 Hz and
horizontal frequency from 30 KHz to 95 KHz.. However, due to different video card
and different resolution settings, we recommend that you do not exceed the maximum
refresh rate, 160 Hz for vertical frequency and 95KHz for horizontal frequency to
avoid possible damages to your monitor.
to locate the desired function icon.
Function Icons
7 Adjusting the Monitor
3-
"
