Cleaning the Dust Cup

• Remove the dust cup from the vacuum by
pressing the upper dust cup release button on
top of the dust cup (Fig. 1).
• Turn the dust cup handle to remove the dust
cup cover from the dust cup.
• Rinse the dust cup in warm water. Allow to dry
thoroughly before re-attaching it to the dust
cup cover.
• Replace the dust cup onto the vacuum body
and resume vacuuming.

Removing the Brushroll

• Remove the floor nozzle by pressing the floor
nozzle release button on the back of the
vacuum (Fig. 3).
• Turn the floor nozzle over. Use a screwdriver
or a coin to turn the screw once to the left.
Then lift off the brushroll cover (Fig. 2).
• Remove brushroll from floor nozzle to clean
or replace (Fig. 5).
• Replace brushroll then replace brushroll cover.
Tighten the screw by turing once to the right.
• Re-attach floor nozzle.
MAINTENANCE AND CARE
Fig. 1
11
Fig. 2
Fig. 3
Fig. 4
Fig. 5
