GE HPS15BTHR Technical Service Manual page 9

Specification for 15, 16 Cu Ft Energy Star
Refrigerator
DISCONNECT POWER CORD BEFORE SERVICING
IMPORTANT - RECONNECT ALL GROUNDING
DEVICES
DISCONNECT POWER CORD BEFORE SERVICING
IMPORTANT - RECONNECT ALL GROUNDING DEVICES
All parts of this appliance capable of conducting
electrical current are grounded. If grounding wires,
screws, straps, clips, nuts or washers used to
complete a path to ground are removed for service,
they must be returned to their original position and
properly fastened.
IMPORTANT SAFETY NOTICE
This information is intended for use by individuals
possessing adequate backgrounds of electrical,
electronic and mechanical experience. Any attempt
to repair a major appliance may result in personal
injury and property damage. The manufacturer or
seller cannot be responsible for the interpretation of
this information, nor can it assume any.
ELECTRICAL SPECIFICATIONS
Cold Control (Position 5)
Defrost Control @ 120
VAC ~60Hz
Defrost Thermostat
Electrical Rating:
Maximum Current
Leakage
Maximum Ground Path
Resistance
NO LOAD PERFORMANCE
Control Position 5/C and Ambient
Temperature of
Fresh Food, °F / °C
Frozen Food, °F / °C
Run Time %
28.0°F
Adaptive Defrost
64-23°F
120 VAC AC 60Hz
0.75 mA
0.14 Ohms
70°F 90°F
33-39 33-41
(-4) -2 (-4) -4)
23-33 37-49
REFRIGERATION SYSTEM
Refrigerant Charge
(R134a)
Compressor @ 120 VAC
~60Hz
Minimum Vacuum @ 2
minutes
Minimum Equalized Pressure
@70°F / 21°C
@90°F / 32°C
INSTALLATION
Clearance must be provided for air circulation
TOP
SIDES
REAR
REPLACEMENT PARTS
Temperature Control
Electronic Defrost
Control Board (EDC)
Defrost Thermostat
Defrost Heater
Condenser Fan Motor
Evaporator Fan Motor
Relay/Overload
Drier
Fuse Harness
Pub. No. 31-51874-5
– 9 –
4.5 oz
615 BTU/hr. /180W
19 inches / 48 cm
37.8 PSIG / 362 kPa
50.7 PSIG / 451 kPa
1 inch / 25 mm
3/4 inch / 19 mm
2 inch / 51 mm
WR09X21006
WR55X21128
WR50X10071
WR09X21107
WR60X20871
WR60X10346
WR07X10133
WR86X0096
WR55X21096
