GE HPS15BTHR Technical Service Manual page 11

Specification for 18 Cu Ft Energy Star Refrigerator
DISCONNECT POWER CORD BEFORE SERVICING
IMPORTANT - RECONNECT ALL GROUNDING
DEVICES
All parts of this appliance capable of conducting
electrical current are grounded. If grounding wires,
screws, straps, clips, nuts or washers used to
complete a path to ground are removed for service,
they must be returned to their original position and
properly fastened.
IMPORTANT SAFETY NOTICE
This information is intended for use by individuals
possessing adequate backgrounds of electrical,
electronic and mechanical experience. Any attempt
to repair a major appliance may result in personal
injury and property damage. The manufacturer or
seller cannot be responsible for the interpretation of
this information, nor can it assume any.
ELECTRICAL SPECIFICATIONS
Temperature Control (Colder) 34.6-13.4°F /
Defrost Control @ 115V ~60
Hz
Defrost Thermostat
Electrical Rating: 110V to
127V AC 60Hz 100V AC 50 Hz
Maximum Current Leakage
Maximum Ground Path
Resistance
NO LOAD PERFORMANCE
Control Position
Colder and Ambient
Temperature of
Fresh Food, °F / °C
Frozen Food, °F / °C
Run Time %
(-10.3) - (1.4)°C
Adaptive
Defrost
64-23°F / 17.8 -
(-5.0)°C
6.5 Amp
0.75 mA
0.14 Ohms
70°F / 21°C 90°F /
32°C
33-39 /1-4 33-41 /
2-4
(-4) -2 / (-4) (-20)-(-16)
-4 /(-20)-(-
17)
23-33 37-49
REFRIGERATION SYSTEM
Refrigerant Charge
(R134a)
Compressor @ 115V
~60 Hz
Minimum Vacuum @
2 minutes
Minimum Equalized Pressure
@70°F / 21°C
@90°F / 32°C
INSTALLATION
Clearance must be provided for air circulation
TOP
SIDES
REAR
REPLACEMENT PARTS
Temperature Control
Defrost Thermostat
Defrost Heater
Condenser Fan Motor WR17X21162
Evaporator Fan Motor WR60X10346
Relay
Drier
Harness Jumper Fuse WR55X21096
Electronic Defrost
Control Board (EDC)
Pub. No. 31-51898
– 11 –
Refer to Rating Plate
600 BTU/hr / 176W
19 inches / 48 cm
37.8 PSIG / 362 kPa
(abs)
50.7 PSIG / 451 kPa
(abs)
.1 inch / 25 mm
3/4 inch / 19 mm
2 inch / 51 mm
WR09X21005
WR50X22304
WR09X21107
WR08X22874
WR86X0096
WR55X21623
