Sealed System Brazed Joints - GE HPS15BTHR Technical Service Manual

Joint Connecting Tubing
4 (Replacement) Dryer
12 (Replacement) Dryer
21 HGL Jumper (I.D.)
21A HGL Jumper (I.D.)
33 Compressor Discharge port (I.D.)
122 EVAP
123 EVAP
124 Tube Jumper Suc (I.D.)
125 Tube Jumper cap (I.D.)
289 Suction Jumper (I.D.)
290 Compressor Process port (I.D.)
291 Compressor suction port (I.D.)

Sealed System Brazed Joints

Joint Size
0.251
0.251
0.170
0.194
0.194
0.321
0.321
0.317
0.082
0.319
0.256
0.319
– 59 –
Connecting Tubing
HGL (O.D.)
Cap Tube (O.D.)
HGL (O.D.)
Condenser (O.D.)
Condenser (O.D.)
Tube jumper cap (O.D.)
Tube jumper Suc (O.D.)
Suction tube (O.D.)
Tube cap (O.D.)
Suction tube (O.D.)
Process tube (O.D.)
Suction Jumper
Joint Size Material
0.156 Copper/Copper
0.076 Copper/Copper
0.156 Copper/Copper
0.188 Copper/Copper
0.188 Copper/Steele
0.312 Copper/Copper
0.312 Copper/Copper
0.312 Copper/Copper
0.076 Copper/Copper
0.312 Copper/Copper
0.250 Copper/Copper
0.312 Copper/Copper
