GE HPS15BTHR Technical Service Manual page 10

Specification for 18 Cu Ft Mechanical Timer
Refrigerator
DISCONNECT POWER CORD BEFORE SERVICING
IMPORTANT - RECONNECT ALL GROUNDING
DEVICES
All parts of this appliance capable of conducting
electrical current are grounded. If grounding wires,
screws, straps, clips, nuts or washers used to
complete a path to ground are removed for service,
they must be returned to their original position and
properly fastened.
IMPORTANT SAFETY NOTICE
This information is intended for use by individuals
possessing adequate backgrounds of electrical,
electronic and mechanical experience. Any attempt
to repair a major appliance may result in personal
injury and property damage. The manufacturer or
seller cannot be responsible for the interpretation of
this information, nor can it assume any.
ELECTRICAL SPECIFICATIONS
Temperature Control (Colder) 23.9-11.1°F /
Defrost Control
Defrost Thermostat
Electrical Rating: 110V to
127V AC 60Hz 100V AC 50 Hz
Maximum Current Leakage
Maximum Ground Path
Resistance
NO LOAD PERFORMANCE
Control Position,
Colder Temperature
of
Fresh Food, °F / °C
Frozen Food, °F / °C
Running Time %
(-4.5) - (-11.6)°C
15 hrs/ 33 min
64-23°F / 17.8 -
(-5.0)°C
6.5 Amp
0.75 mA
0.14 Ohms
70°F / 90°F /
21°C 32°C
34-40 35-39 /
/1.1-4.4 1.7-3.9
-3 / -19.4 -3 / -19.4
20-30 41-53
– 10 –
REFRIGERATION SYSTEM
Refrigerant Charge
(R134a)
Compressor Capacity
(@ 10°F Evap and
105°F Cond)
Minimum Vacuum @ 2
minutes
Minimum Equalized Pressure
@70°F / 21°C
@90°F / 32°C
INSTALLATION
Clearance must be provided for air circulation
TOP
SIDES
REAR
REPLACEMENT PARTS
Temperature Control
Relay
Defrost Control
Defrost Thermostat
Defrost Heater
Condenser Fan Motor WR17X21162
Evaporator Fan Motor WR60X10346
Drier
Harness Jumper Fuse WR55X21096
Pub. No. 31-51904
Refer to Rating Plate
600 BTU/hr / 175.8W
19 inches / 48 cm
26 PSIG / 179 kPa
35 PSIG / 241 kPa
1 inch / 25 mm
3/4 inch / 19 mm
2 inch / 50 mm
WR09X21005
WR08X22874
WR09X10049
WR50X22304
WR09X21107
WR86X0096
