Machine Components - Tennant 5280 Operator And Parts Manual

OPERATION

MACHINE COMPONENTS

K
E
D
C
A. Solution Tank
B. Recovery Tank
C. Scrub Head
D. Scrub Head Access Cover
E. Solution Tank Fill Opening
F. Batteries
G. Recovery Tank Cover
H. Solution Tank Drain Hose
6
G
B
A
F
C
I. Recovery Tank Drain Hose
J. Control Console Panel
K. Recovery Tank Support Stand
L. Squeegee
M. Scrub Head Lift Pedal
N. Scrub Head Release Pedal
O. Squeegee Leveling Knob
H
L
Tennant 5280 (10- -04)
J
I
N
M
O
