OPERATION
3. Connect wand's vacuum hose using hose adapter
supplied with wand (Figure 36).
FIG. 36
4. If machine is equipped with Off--Aisle Wand Pump
option, connect solution hose to quick disconnect
coupler located behind left wheel (Figure 37).
FIG. 37
5. Attach vacuum hose and solution hose to wand
(Figure 38).
FIG. 38
16
6. Turn machine power and wand pump switch on
(Figure 39).
FIG. 39
7. Lower squeegee to turn on vacuum system
(Figure 40).
FIG. 40
8. Squeeze lever on wand and spray solution on
floor. Scrub floor with brush side of wand and
vacuum up solution with squeegee side of wand
(Figure 41).
WARNING: Fire Or Explosion Hazard. Do Not
Pick Up Flammable Materials Or Reactive Metals.
FIG. 41
