Lowrance HOOK-4x Operation Manual page 34

HOOK -7x
General
5.3" H (234 mm) x 9.2" W (136 mm);
Case Size
5.9" H (151 mm) with bracket
(7" diagonal) 16-bit color Full VGA
Display
Solar MAX™ color TFT
Waterproof
IPX7
standard
Backlight
LED (11 levels)
NMEA 0183 Output (Requires optional
Communications
Power/NMEA cable 000-0127-49)
Transmit Power 500 W RMS
Power
12 V
Requirement
Voltage Input
10 to 17 V
Current drain Typical: 1.1 A
Fuse type
3-amp Automotive
Specifications | HOOK X series
Power
Max depth
Available trans-
ducer frequencies
Max speed
Transducer
Transducer cable
34
Sonar
300 ft (91 m) 455/800 kHz
1000 ft (305 m) 83/200 kHz
2500 ft (762 m) 50 kHz
455/800 kHz
50/83/200 kHz
High/Medium/Low CHIRP
70 mph
HDI 50/200 kHz (Low/High CHIRP)
HDI 83/200 kHz (Medium/High CHIRP)
83/200 kHz (Medium/High CHIRP)
20 ft (6 m)
