Specifications

Capacities System
12 outside lines via line jacks on
two 206 plus two 400 modules
24 extensions via extension jacks
on four 206 modules
1 loudspeaker paging system
via PAGE jack on processor
module
1 audio source via MUSIC ON
HOLD jack on processor module
(RCA phono plug required)
1 call reporting device via SMDR
jack on processor module (355A/F
adapter required)
2 doorphones via 2 ext. jacks
Dimensions
Processor Module
and Weights
206 module
400 module
(approx.)
Backplane & cover
MLS-34D phone
MLS-18D phone
MLS-12D phone
MLS-12 phone
MLS-6 phone
MLC-6 phone
MLS-CA24 Autodialer 9.7"(D) x 5.3"(H) x 3.4"(W) or 24.6 x 13.5 x 8.6 cm
Switch Fabric
Full digital, nonblocking
Electrical
10 Watts (35 BTUs/hour) per 400 module, normal and maximum power consumption
Specifications
65 Watts (225 BTUs/hour) per 206 module during normal operation
100 Watts (350 BTUs/hour) per 206 module during maximum power consumption
4 Amps maximum current at full system capacity (processor module and four 206 modules)
On a PARTNER Plus 220V System: 2.2 Amps maximum current
4-day memory backup (96 hours)
Processor
68000 microprocessor, 64K RAM, 256K ROM
Module
Specifications
Extension
Ringing voltage: +5VDC, -140 VDC peak to peak; trapezoidal wave shaping
Jack
On a PARTNER Plus 220V System: +5VDC, -150 VDC peak to peak
Specifications
35- to 38-Volt talk battery
Ringing frequency: 20 Hz
PAGE Jack
Draws current on inner wire pair
Specifications
Provides contact closure on outer wire pair
600 Ohm impedance
* The two devices combined on an extension jack can be a system phone with a standard device, or two standard devices; DO NOT
connect two system phones to the same extension jack. If a device lists two RENs, use the higher number when adding up RENs.
20
Specifications
206 Module
2 outside lines
6 extensions
400 Module
4 outside lines
11"(D) x 17"(H) x 1.5"(W) or 27.9 x 43.2 x 3.8 cm
11"(D) x 17"(H) x 1.5"(W) or 27.9 x 43.2 x 3.8 cm
11"(D) x 17"(H) x 1.5"(W) or 27.9 x 43.2 x 3.8 cm
12"(D) x 19"(H) x 11"(W) or 30.5 x 48.3 x 27.9 cm
9.7"(D) x 5.3"(H) x 10"(W) or 24.6 x 13.5 x 25.4 cm
9.5"(D) x 5"(H) x 6.75"(W) or 24.1 x 12.7 x 17.1 cm
9.5"(D) x 5"(H) x 6.75"(W) or 24.1 x 12.7 x 17.1 cm
9.5"(D) x 5"(H) x 6.75"(W) or 24.1 x 12.7 x 17.1 cm
9.5"(D) x 5"(H) x 6.75"(W) or 24.1 x 12.7 x 17.1 cm
9.4"(D) x 3.4"(H) x 7"(W) or 23.9 x 8.6 x 17.8 cm
Extension Jack
Maximum 2 devices per extension
jack, total REN on jack not to
exceed 2.0* (System phone
REN: 0.0 (zero))
No more than one system phone
per jack
For programming, a system display
phone must be connected to
extension 10 or 11.
4.0 lbs or 1.8 kgs
4.5 lbs or 2.0 kgs
4.0 lbs or 1.8 kgs
5.5 lbs or 2.5 kgs
3.1 lbs or 1.4 kgs
2.8 lbs or 1.3 kgs
2.8 lbs or 1.3 kgs
2.7 lbs or 1.2 kgs
2.7 lbs or 1.2 kgs
2.8 lbs or 1.3 kgs
1.3 lbs or 0.6 kgs
