NCR EasyPoint 7401
Release 2.4
Site Preparation Guide
19797
B005-0000-1255
Issue C

Advertisement

Table of Contents
loading

Related Manuals for NCR EasyPoint 7401

Summary of Contents for NCR EasyPoint 7401

  • Page 1 NCR EasyPoint 7401 Release 2.4 Site Preparation Guide 19797 B005-0000-1255 Issue C...
  • Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
  • Page 3 You are advised to read it carefully. It is the responsibility of the customer to assure that all installation preparations are complete and in compliance with NCR specifications and requirements and all applicable national, state, or local codes, regulations, and laws.
  • Page 4 The post or wall on which the unit is mounted should be able to withstand four times the weight of the unit, which is approximately 20 lbs. (9 kg). The NCR 7401-45xx is a desk-top unit that ahas an assembled weight of approximately 90 lbs.
  • Page 5 “Related Site Preparation Data” section. This book contains the information necessary for the preparation of a site that conforms to NCR specifications. It is very important that the site complies with the requirements specified in the document because,...
  • Page 6 NCR will not be liable in respect to any comment, suggestion, or advice given by its staff or in respect to any failure to give advice.
  • Page 7 Site Preparation References • NCR EasyPoint 7401 Hardware User’s Guide (B005-0000-1254) • NCR EasyPoint 7401 Hardware Service Guide (B005-0000-1341) • NCR EasyPoint 7401 Interface Guide (B005-0000-1405) • NCR 7401/7454 Retail Terminal Parts Identification Manual (B005-0000-1072)
  • Page 8 Site Preparation...

  • Page 9: Table Of Contents

    Site Preparation Table of Contents Introduction 7401-2xxx and 3xxx Models ..........1 7401-45xx Model.............. 2 Interpreting the Model Number........3 Related Site Preparation Data......... 4 Accessing Information Products ........4 Customer Responsibilities AC Store Wiring Requirements LAN Communications 7401-2xxx and 3xxx System Configuration Diagram 7401-45xx System Configuration Diagram 7401-2xxx and 3xxx Kit Configuration Diagram Physical Considerations...
  • Page 10 7401 with 7949 Pedestal Mount......20 7401 with 2336-K052 Pedestal Mount ....21 7401 2336-K037 Pedestal Mount with Keyboard Shelf................22 NCR 2260 Cash Drawer .......... 23 NCR 2189 Cash Drawer .......... 23 NCR 2113 Cash Drawer .......... 24 7453-K005 Cash Drawer.......... 24 7156 Multifunction Printer ........
  • Page 11 Site Preparation Cable Routing Considerations 7401-2xxx and 3xxx............35 Table-Top Mount ............ 36 7401-45xx................ 37 7401-2xxx and 3xxx Mounting Considerations Viewing Height ............. 38 Terminal with K521 Wall Mount........39 Terminal with K521 Wall Mount and K530 Pole Straps................41 Terminal with Printer and K525 Wall Bracket ....
  • Page 12 Site Preparation System Cables Cable Illustrations ............62 Dual Cash Drawer, Y-cable ........62 Ethernet, 10/100 Base-T.......... 62 USB ................63 External CD-ROM Cable ........63 External Parallel Cable..........64 Power, AC..............64 Environmental Requirements Barometric Pressure ............65 Temperature ..............65 Humidity................
  • Page 13 Site Preparation Revision Record Issue Date Remarks Aug. 00 First issue Oct. 01 Update model and kit changes May 02 Updated to Release 2.4. Add EasyPoint 7401-45xx terminal...
  • Page 14 NCR is not responsible for any radio or television interference caused by unauthorized modification of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by NCR.
  • Page 15 Site Preparation xiii International Radio Frequency Interference Statement Warning: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
  • Page 16 à la lumiè re laser directe. Laser por mucho tiempò. IEC & EN 60825-1 CLASS 1 LASER PRODUCT 17325 Laser Power The NCR EasyPoint 7401 scanner meets the following laser/LED power requirements. • Class IIa CDRH (Center for Devices and Radiological Health) •...

  • Page 17: Declaration Of Conformity

    Model Number 100-120 V/200-240 V, 2.0 A/1.0 A, 50-60 Hz Electrical Ratings (Input) NCR Corporation, 1700 South Patterson Boulevard, Dayton, OH 45459, USA, declares that the equipment specified above conforms to the referenced EU Directives and Harmonized Standards. EU Directive...
  • Page 18 Model Number 100 - 240 V, 5.0 A, 50-60 Hz Electrical Ratings (Input) NCR Corporation, 1700 South Patterson Boulevard, Dayton, OH 45459, USA, declares that the equipment specified above conforms to the referenced EU Directives and Harmonized Standards. EU Directive...

  • Page 19: Introduction

    Introduction This document provides the information necessary to prepare a site to NCR specifications prior to installing a 7401 terminal. The site must be properly prepared before the terminal is installed because site preparation deficiencies may be difficult to detect and correct after installation.

  • Page 20: 7401-45Xx Model

    Site Preparation 7401-45xx Model 19889d...

  • Page 21: Interpreting The Model Number

    Site Preparation Interpreting the Model Number NCR Model 7401 X 1 X 80 Language 01 = International English Power Required 80 = 110 -240 VAC 50/60 Hz Touchscreen Type 2 = Capacitive 8 = Resistive 1 = Self Service Processor/LCD 1 = Pentium 2 = PIII/Celeron 12"...

  • Page 22: Related Site Preparation Data

    Title Order Number NCR 7158 Thermal Receipt/Impact Printer B005-0000-1112 NCR 7166 Thermal Receipt/Impact Printer B005-0000-1002 NCR 7194 Thermal Receipt Printer Owner’s Guide B005-0000-1094 NCR 7196 Thermal Receipt Printer B005-0000-1170 NCR 7401-K580 Self-Service Printer Owner’s Guide B005-0000-1139 NCR 7401-K580 Self-Service Printer Service Guide...

  • Page 23: Customer Responsibilities

    Provide and install floor coverings and environmental systems that limit or control static electricity build-up and discharge In general, keep the NCR equipment area free from dust, smoke, lint, and other particles. Restrict smoking, eating, and drinking around the equipment. Avoid locating the equipment near other machines that generate ink, carbon, and paper dust particles.

  • Page 24: Ac Store Wiring Requirements

    The customer must provide suitable AC power for the 7401 terminals, associated equipment, and devices. A dedicated, unswitched power line to the NCR equipment installation is recommended. Refer to the Workstation and Peripherals AC Wiring Guide (BSTO-2115-53) for store AC wiring requirements. The AC outlet must be installed near the terminal and easily accessible to the operator.

  • Page 25: 7401-2Xxx And 3Xxx System Configuration Diagram

    Site Preparation 7401-2xxx and 3xxx System Configuration Diagram 7161 7156 7193 7194 7196 7158 7166 7401 Keyboard 7837 7890 PS/2 KBD RS232 2336-K008 (RS232/1 Optionally PCMCIA Powered) (Wireless) 2336-K007 Processor Board 7401-K580 Microphone SVideo POS Connector Board Parallel Ethernet Audio Cash Dwr 2nd Cash Drawer 7401-K590...

  • Page 26: 7401-45Xx System Configuration Diagram

    Site Preparation 7401-45xx System Configuration Diagram Power Full Page Supply Printer Speakers Parallel Speaker Power IRDA IRDA Receiver 7401-45xx USB 1 Core Module Swipe 15 inch LCD USB 2 Touch Screen PIII Motherboard S-Video RS-232 Ports (Powered) (Powered) COM1 COM2 COM3 COM4 Motorized...

  • Page 27: 7401-2Xxx And 3Xxx Kit Configuration Diagram

    Site Preparation 7401-2xxx and 3xxx Kit Configuration Diagram 7401 w/K590 7401-2xxx 7401-3xxx 2336-K037 2336-K033 K542 F501 F502 K533 F/K059 F521 F511 F101 F504 F200 K540 F201 K536 K543 K530 K535 K523 K525 F/K590 K534 18318c...

  • Page 28: Physical Considerations

    Site Preparation Physical Considerations This section presents the following 7401 information: • Operating and service clearance requirements • Display mounting considerations • 7401 and component dimensions • Component weights • Airflow requirements • Power requirements...

  • Page 29: Operating And Service Clearance Requirements

    Site Preparation Operating and Service Clearance Requirements Location Component Distance Reason 7194 Printer 228 mm (9 in.) Clearance to raise printer cover Above 7196 Printer 254 mm (10 in) Clearance to raise printer cover 7156 Printer 281 mm (11.1 in.) Clearance to raise printer cover 7158 printer 305 mm (12 in.)

  • Page 30: Component Dimensions

    Site Preparation Component Dimensions 7401-32xx Fixed Angle Mount (12.1-Inch) 400 mm (16 in.) 370 mm 280 mm (14.5 in.) (11 in.) 450 mm 400 mm (17.6 in.) (16 in.) 120 mm (4.75 in.) 16420 7401-32xx Fixed Angle Mount (15-Inch) 426 mm 331 mm (16.75 in.) (13 in.)

  • Page 31: 7401-22Xx Tilt Mount (12.1 Inch)

    Site Preparation 7401-22xx Tilt Mount (12.1 Inch) 400 mm (16 in.) 370 mm (14.5 in.) 380 mm (15.0 in.) 360 mm (14.0 in.) 15970 7401-25xx Tilt Mount (15-Inch) 425 mm (16.75 in.) 394 mm (15.5 in.) 412 mm (16.25 in.) 35 mm (14.0 in.) 18134...

  • Page 32: 7401-22Xx (12-Inch)

    Site Preparation 7401-22xx (12-Inch) 401mm 40.5 mm (15.8 in.) (1.6 in) 370 mm (14.5 in.) 381 mm 312 mm (15.0 in.) (12.3 in.) 53.4 mm (2.1 in) 18200...

  • Page 33: 7401-25Xx (15-Inch)

    Site Preparation 7401-25xx (15-Inch) 426 mm (16.8 in.) 391 mm 14.3 mm (15.5 in.) (0.6 in.) 338 mm (13.3 in.) 392.1 mm (15.4 in.) 53.4 mm (2.1 in.) 78.8 mm (3.1 in.) 18201...

  • Page 34: 7401-45Xx W/Keyboard And Pin Pad

    Site Preparation 7401-45xx w/Keyboard and Pin Pad 450.85 mm 210 mm (17.75 in.) (8.27 in.) 152 mm 393.7 mm (5.98 in.) (15.5 in.) 50 mm (1.97 in.) 521 mm (20.5 in.) 555.75 mm 513 mm 21.88 in.) (20.2 in.) 90 mm (3.54 in.) 620 mm (24.41 in.)

  • Page 35: 7401-K540 (12.1 Inch) W/Keyboard Option

    Site Preparation 7401-K540 (12.1 Inch) w/Keyboard Option 400 mm (16 in.) 550 mm (21.5 in.) 297 mm 400 mm (16 in.) (11.63 in.) 17296 7401-K543 Wall Mount Bracket w/Wide Keyboard Shelf 383 mm 97 mm (15.06 in.) (7.38 in.) 19900...

  • Page 36: 7401-K580/590 W/Self-Service Printer 12.1 Inch

    Site Preparation 7401-K580/590 w/Self-Service Printer 12.1 Inch 400 mm (16 in.) 280 mm 370 mm (11 in.) (14.5 in.) 880 mm (34.5 in.) 530 mm (21 in.) 180 mm 180 mm (7.0 in.) (7.0 in.) 16698...

  • Page 37: 7401-K580/590 W/Self-Service Printer (15-Inch)

    Site Preparation 7401-K580/590 w/Self-Service Printer (15-Inch) 426 mm (16.75 in.) 330 mm 391 mm (13 in.) (15.5 in.) 900 mm (35 in.) 530 mm (21 in.) 180 mm 180 mm (7.0 in.) (7.0 in.) 16698a...

  • Page 38: 7401 With 7949 Pedestal Mount

    Site Preparation 7401 with 7949 Pedestal Mount 400 mm (16 in.) 7401-K580 Spacer 1372 mm (54 in.) 203 mm 203 mm (8 in.) (8 in.) 171 mm (6 3/4 in.) 457 mm 457 mm (18 in.) (18 in.) 19289 7949-K033 7949-K035...

  • Page 39: 7401 With 2336-K052 Pedestal Mount

    Site Preparation 7401 with 2336-K052 Pedestal Mount 7401-K590 Optional Spacer 2336-K051 1321 mm (52 in.) 198 mm 203 mm (7.8 in.) (8 in.) 175 mm (6.9 in.) 597 mm 597 mm (23.5 in.) (23.5 in.) 19319...

  • Page 40: 7401 2336-K037 Pedestal Mount With Keyboard Shelf

    Site Preparation 7401 2336-K037 Pedestal Mount with Keyboard Shelf 7401-K580/K590 1321 mm (52 in.) Optional Spacer 203 mm 2336-K051 (8 in.) 175 mm (6.9 in.) 198 mm (7.8 in.) 597 mm 597 mm (23.5 in.) (23.5 in.) 19320...

  • Page 41: Ncr 2260 Cash Drawer

    Site Preparation NCR 2260 Cash Drawer 457 mm (18 in.) 121 mm (4.75 in.) 457 mm (18 in.) 277 mm (11 in.) Operating and Service Clearance for Drawer 15414 NCR 2189 Cash Drawer 464 mm (18.25 in.) 133 mm (5.25 in.) 527 mm (20.5 in.)

  • Page 42: Ncr 2113 Cash Drawer

    Site Preparation NCR 2113 Cash Drawer 400 mm (15.75 in.) 96 mm (3.75 in.) 450 mm (17.75 in.) 254 mm (10 in.) Operating and Service Clearance for Drawer 17310 7453-K005 Cash Drawer 455.6 mm ( 17.94in.) 108 mm (4.25 in.) 450.9 mm...

  • Page 43: 7156 Multifunction Printer

    Site Preparation 7156 Multifunction Printer 242 mm (9.5 in.) 119 mm (4.7 in.) 165 mm (6.5 in.) 60 mm (2.375 in.) 229 mm 264 mm (9.0 in.) (10.4 in.) 11951a 7194 Thermal Receipt Printer 212 mm 130 mm (8.3 in.) (5.10 in.) 85 mm (3.30 in.)

  • Page 44: 7166 Thermal Receipt/Impact Printer

    Site Preparation 7166 Thermal Receipt/Impact Printer 171 mm (6.75 in.) 280 mm (11.00 in.) 330 mm 248 mm (13.00 in.) (9.75 in.) 17308 7158 Thermal Receipt/Impact Printer 165 mm (6.50 in.) 305 mm (12.00 in.) 229 mm 336 mm (9.00 in) (13.25 in) 17307...

  • Page 45: 7196 Thermal Receipt Printer

    Site Preparation 7196 Thermal Receipt Printer 146 mm 254 mm 108 mm (5.75 in.) (10.00 in.) (4.25 in.) 140 m (5.50 in.) 17306...

  • Page 46: 2336-K007 External Cd-Rom Drive

    218 mm (8.6 in.) 23 mm (0.9 in.) 16951 Note: Allow 75 mm (3 in.) clearance in the back of the NCR 2336-K007 External CD-ROM Drive for connector and cable clearance. 2336-K008 USB RS-232 Port Server 183 mm (7.2 in.)

  • Page 47: Component Weights

    Site Preparation Component Weights The following table shows the component weights for each integrated component. 7401 Components Weight lbs. 7401-45xx with paper roll and all components 40.8 Full width thermal paper roll 2.75 7.38 ATX 38 Thermal Printer 12.86 Motorized Card Reader 1.35 Keyboard with Pin Pad 3.04...

  • Page 48: Ventilation Clearance

    Site Preparation Ventilation Clearance Leave the minimum clearances shown below for proper cooling conditions for the 7401 terminal. NCR 7401 25 mm (1 in.) 76 mm (3 in.) Minimum Horizontal Clearance Minimum Vertical Clearance 16423...

  • Page 49: 7401 Power Requirements

    Site Preparation 7401 Power Requirements The Core Module contains a three-wire, single-phase, selectable 120/240 volt AC, 85 Watt power supply. The supply powers the 7401, scanner, VFD display, keyboard, USB interface, cash drawer, integrated speakers, and PCMCIA cards. The following tables show operating specifications for the power supply.

  • Page 50: Typical Power Requirements (7401-45Xx)

    Site Preparation Typical Power Requirements (7401-45xx) The following table shows power consumption for a 7401-4512 with full-page printer, motorized card reader, and Pin Pad. System 7401-4512 Condition Amps Watts 120 Volt All peripherals powered and 0.12 core module in Soft OFF System Idle at Windows 0.15 Desktop (Power On)

  • Page 51: Power Consumption Matrix

    Site Preparation Power Consumption Matrix The following table is provided as a reference of the power consumption of the peripherals available on the 7401. Note: All power data listed in the table below is rated in amperage. 7401 Power Matrix Item Description 3.3VDC 5.0VDC 12VDC...
  • Page 52 Site Preparation 7401 Power Matrix ( continued Item Description 3.3VDC 5.0VDC 12VDC Requires external power source 7892 Presentation Scanner Powered from Serial Port 0.50 1416-C643-0030 5945 Electronic Payment Device (497-0411818) 0.50 1416-C634-4000 7194, 7158, 7196, Printers (always require brick) 5992 Signature capture device 5945 Electronic Payment Device 7892 Presentation Scanner 2336-K016 CCD Hand Held Scanner...

  • Page 53: Cable Routing Considerations

    Site Preparation Cable Routing Considerations 7401-2xxx and 3xxx External cables can be routed out the back or the bottom of the Pedestal Mount. 16424...

  • Page 54: Table-Top Mount

    Site Preparation Table-Top Mount The internal cable connectors on the terminal are located on the underside of the Core Module under the Cable Cover. Cable Cover Thumb Screw 15968...

  • Page 55: 7401-45Xx

    Site Preparation 7401-45xx External cables can be routed out the back or the bottom of the terminal. A 63.5 mm (2.5 in.) hole that aligns with the hole in the Table Top Mount must be cut in the table top when routing cables out the bottom of the terminal.

  • Page 56: 7401-2Xxx And 3Xxx Mounting Considerations

    Site Preparation 7401-2xxx and 3xxx Mounting Considerations Viewing Height The terminal should be mounted approximately 1.2 m (48 in.) from the floor for proper use. 1.2 m (48 in) Recommended Height from Floor 16445...

  • Page 57: Terminal With K521 Wall Mount

    Site Preparation Terminal with K521 Wall Mount 8.7 in. 7 in. 4 in. K521 7.8 in. 19291...
  • Page 58 Site Preparation Lag Screws (4) Wall Bracket 1.2 m (48 in) Recommended Height from Floor 17715 K521 Wall Mount...

  • Page 59: Terminal With K521 Wall Mount And K530 Pole Straps

    Site Preparation Terminal with K521 Wall Mount and K530 Pole Straps 1.2 m (48 in) Recommended Height from Floor K521 K530 Mounting Strap 19283 Note: K530 also includes pole mount adapter brackets used with K525. (See illustration on next page.)

  • Page 60: Terminal With Printer And K525 Wall Bracket

    Site Preparation Terminal with Printer and K525 Wall Bracket 15.35 in. Mounting Screw 33.70 in. (on both sides) K530 Pole Bracket 15.35 in. 3.75 in. 7.80 in. 19282...
  • Page 61 Site Preparation Lag Screws (6) 1.2 m (48 in) Wall Bracket Recommended Height from Floor 17593 K525 Wall Mount...
  • Page 62 Site Preparation Mounting Screw (on both sides) 17735 K525 with K530 Pole Mount Straps...

  • Page 63: Printer Only Mount (K523 Wall Bracket)

    Site Preparation Printer Only Mount (K523 Wall Bracket) Mounting Screw (on both sides) 14.00 in. 12.00 in. 4 in. K523 7.820 in. 19294...

  • Page 64: Terminal Only (K522 Universal Bracket)

    Site Preparation Terminal Only (K522 Universal Bracket) The terminal can be mounted on a flat surface or pedestal using the Universal Mounting Bracket. Flat Horizontal Surface Mounting Plate K522 Securing Screw 19295...

  • Page 65: Considerations For Enclosed Installations

    Site Preparation Considerations for Enclosed Installations Terminals that are mounted in an enclosure must meet certain thermal and environmental requirements as illustrated and noted in the following pages. Ventilation Clearances Verify that all clearance specifications are met as shown below. 76 mm (3 in.) 38 mm...

  • Page 66: Thermal Test Points

    Thermal Test Points (Both sides of terminal) 17316 Note: For terminal servicing information refer to NCR EasyPoint 7401 Hardware Service Guide (B005-0000-1341). Service Access The enclosure must provide access to certain locations for service purposes. The 7401 can be mounted as a stand-alone unit, with a...

  • Page 67: Inch Lcd No-Cabinet Feature 7401-F752

    Site Preparation 12.1-inch LCD No-Cabinet Feature 7401-F752 The 12.1-inch LCD No-Cabinet Feature (F752) is purchased by customers who design their own enclosures to meet their specific needs. This section provides information that must be considered when designing enclosures. 18577 Front View Motion Sensor 18743 Back View...

  • Page 68: Installation Guidelines

    The end-use product in which this component is used should be certified in accordance with UL 1950, EN60950, IEC950 or other applicable safety standard. Caution: NCR displays are not designed for horizontal or inverted use. NCR displays must be mounted no more than 40 forward or backward from horizontal.

  • Page 69: Mounting Specification Illustrations

    Front surface of display bezel must protrude through enclosure to provide secure and watertight fit. NCR enclosure fronts typically use a dimension of 302.26 mm (11.9 in.) +/-.254 mm (.01 in.) by 221.23 mm (8.71 in.) +/-.254 mm (.01 in.) with 218.44 mm...

  • Page 70: 15-Inch Lcd No-Cabinet Feature 7401-F757

    UL 1950, EN60950, IEC950 or other applicable safety standard. Caution: NCR displays are not designed for horizontal or inverted use. NCR displays must be mounted no more than 40 forward or backward from horizontal.

  • Page 71: Mounting Specification Illustrations

    Site Preparation Mounting Specification Illustrations The following illustration shows the minimum allowable dimensions for the display opening when the optional cosmetic bezel is used. GASKET MUST MEET INSIDE SURFACE OPTIONAL COSMETIC BEZEL OF CUSTOM DISPLAY OPENING. (OPTIONAL COSMETIC GASKET NOT USED IF OPTIONAL BEZEL IS NOT USED).
  • Page 72 Site Preparation The following illustration shows the maximum allowable dimensions for the display opening when the optional cosmetic bezel is not used. 312.5 mm Gasket must meet inside surface of custom 13.7 mm 12.305 in. application's display opening. This is to provide 0.540 in.

  • Page 73: K/F 502 Flush Wall Mount

    Site Preparation K/F 502 Flush Wall Mount The Core Module (without either mount) can be mounted flush against a wall. The following shows mounting configuration and brackets: Flush Mount w/Power Supply Flush Mount w/Power Supply Mounted on the Outside Wall Mounted on the Inside Wall 16683...

  • Page 74: Power Supply

    Site Preparation Power Supply 152 mm 102 mm (6 in.) (4 in.) 57 mm (2.25 in.) 17406 Wall Mount the Terminal Bracket Drill a hole in the wall for the cables if you are mounting the power supply on the opposite side of the wall. Flush Mounting Bracket Wall Plate Cable Routing...

  • Page 75: 7401-45Xx Mounting Considerations

    Site Preparation 7401-45xx Mounting Considerations Viewing Height The terminal should be mounted approximately 88.9 cm (35 in.) from the floor for proper use. This provides for a keyboard height of approximately 94 cm (37 inches) for stand-up use and a viewing height to the center of the screen of 120 cm (48 in.).

  • Page 76: 7401-45Xx Table Top Mount

    Site Preparation 7401-45xx Table Top Mount The terminal can be mounted on a flat surface using the Table Top Mount (497-0424868). Mounting hole center to center measurements are shown in the following illustration. When routing the cables out the bottom of the terminal, a 63.5 mm (2.5 in.) hole must be cut in the table top that aligns with the hole in the Table Top Mount.

  • Page 77: Mounting 7401-45Xx Signage

    Site Preparation Mounting 7401-45xx Signage The Cabinet Back Panel has four (4) holes on each side that may be used to mount signage. Use 8-32 screws to mount the signage display. The length of the screw is determined by the thickness of the signage mount plus 6 mm (0.25 in.).

  • Page 78: System Cables

    Site Preparation System Cables Cable Type Cable Name NCR Part No. Corp. ID No Approximate Cable Lengths Cash Drawer Dual Drawer, Y cable 497-0409394 1416-C372-0006 0.6 m/2 ft Communications Ethernet, 10/100Base-T 497-0008623 1416-C041-0030 3 m/10 ft (Unshielded) RS-232, Integrated 497-0407427...
  • Page 79 Site Preparation Cable Type Cable Name NCR Part No. Corp. ID No Approximate Cable Lengths 497-0405945 1416-C286-0040 4 m/13 ft 7194 Printer 497-0411923...

  • Page 80: Cable Illustrations

    Site Preparation Cable Illustrations Dual Cash Drawer, Y-cable Cash DWR. #1 497-0409394 Cash DWR. #2 16 mm 51 mm Access Hole Diameters (0.625 in.) (2.0 in.) 15808 Ethernet, 10/100 Base-T Modular Modular 8-Pin 8-Pin Plug 497-0008623 Plug 19 mm 19 mm Access Hole Diameters (.75 in.) (.75 in.)

  • Page 81: Usb

    Site Preparation 497-0415949 (1 meter) 498-0415950 (4 meter) Type A Type B Access Hole Diameters 6.4 mm 15 mm (0.25 in.) (0.63 in.) 18433 External CD-ROM Cable 25-pin 28-pin 497-0413011 - 0.6 M D-Shell Sub-Miniture 1416-C464-0006 Receptacle D-Plug To 7454 To CD-ROM Cust.

  • Page 82: External Parallel Cable

    Site Preparation External Parallel Cable 25-pin 28-pin D-Shell 497-0411000-0.6 M Sub-Miniture Receptacle 1416-C472-0006 D-Plug To 7454 To CD-ROM Cust. Display Parallel Port Connector Access Hole Diameters 57 mm 31 mm (2.25 in.) (1.25 in.) 17390 Power, AC 006-1009037 Workstation 45 mm Access Hole Diameter (1.75 in.) 15405...

  • Page 83: Environmental Requirements

    Site Preparation Environmental Requirements Barometric Pressure The 7401 is designed to operate within the following barometric pressure conditions: • Maximum operating altitude: 3000 m (9843 ft) • Operating range of pressure: 105 kPa to 69 kPa (15.2 lb./in. to 10.0 lb./in.) Temperature The 7401 is designed to operate over the temperature ranges shown below.

  • Page 85: Ac Power Line Transient Protection

    The NCR Maintenance Agreement does not cover malfunction and/or component failure as a result of power quality problems. NCR accepts no liability for any such occurrence or for its consequences. When power transient suppression is required, the suppressors used should meet the following minimum requirements: •...

  • Page 86: Data Line Transient Protection

    Be installed in accordance with all applicable local, state, and national electrical codes and regulations. Note: In certain countries, NCR is able to supply both power and data line transient suppressors as well as a comprehensive line of power conditioning equipment. For application data, contact your NCR...
  • Page 87 Index —1— —D— 12.1 Inch LCD No-Cabinet Feature (7401- Dimensions, 12 K752), 49 Dimensions and Weight 15 Inch LCD No-Cabinet Feature (7401- Weight, 29 F757), 52 Dual Cash Drawer, Y-cable, 62 —7— —E— 7156 Thermal Receipt and Impact Slip Enclosed Installations, 47 Printer, 25 Environmental Requirements, 65 7158 Thermal Receipt/Impact Printer, 26...
  • Page 88 NCR 2189 Cash Drawer, 23 —T— NCR 2260 Cash Drawer, 23 NCR 2336-K007 External CD-ROM Drive, Temperature, 65 Thermal Test Points, 48 NCR 2336-K008 USB RS-232 Port Server, —U— —O— Universal Bracket, 46 USB, 63 Operating range of barometric pressure, —V—...
  • Page 90 B005-0000-1255 May 2002 Printed on recycled paper...
