Philips HR7633 Service Manual

Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION
HR7633 /J : Cucina ivory version
HR7633 /K : Cucina white version
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- The food processor is equipped with mechanical and
thermal safety switches.
- Motor power consumption : 600 W
- Kneading capacity
- Voltage & frequency
- Cordset
- Speed setting
- Bowl capacity
- Dimensions fancy box
Automatic resetable thermal cut-out
- In order to avoid an hazardous situation due to in
advertent resetting of the thermal cut-out, this appliance
must not be supplied through a timer.
Published by Philips Domestic Appliances and Personal Care
03/04
Cucina white / Cucina ivory
: max. 400 g of flour
max. 680 g of dough
: 220 - 240 V; 50 - 60 Hz
110 - 120 V; 50 - 60 Hz
: 150 cm
: 2 speeds + pulse
: 1,8 l dry ingredients
1,2 l liquids
: 413 x 248 x 339
Printed in the Netherlands

Food processor

- To prevent damage due to overheating, the appliance has
been equipped with an automatic cut-out system.
This system will automatically cut off the power supply
when the appliance overheats.
If the appliance suddenly stops running:
- Unplug the appliance
- Press the button 'pulse / 0'
- Let the appliance cool down for 60 minutes
- Plug the appliance in again
- Switch the appliance on again
Safety lock
- The motor unit as well as the lid have been provided with
marks. The appliance will only function if the arrow on the
motor unit is placed directly opposite the mark on the lid.
Cleaning
- The bowl, lid of the bowl, pusher and accessories can also
be washed in the dishwasher.
- The cover with insert storage is not dishwasher proof.
REPAIR INSTRUCTIONS
- No specific issues
ASSEMBLY & DISASSEMBLY ADVICE
- No specific issues
OPTIONAL (accessories)
- No specific issues
© Copyright reserved
HR7633 /J /K
Subject to modification
