Summary of Contents for Wilo ECS19-15.25
- Page 1 Wilo SP Series Submersible Sump Pumps ECS ECS19-15.25 ECS22-15.33 ECS24-15.50 Installation and operating instructions...
-
Page 2: Specifications
1. DESCRIPTION This Wilo submersible sump pump is designed for home sump applications. The pump is built with overload thermal protections and auto reset. The pump is equipped with a 10’ 3-prong grounding-type power cord, and assembled with vertical float switch. -
Page 3: General Safety Information
5. GENERAL SAFETY INFORMATION This pump is made of high-strength, corrosion-resistant materials. It will provide trouble-free service for a long time when properly installed, maintained, and used. However, inadequate electrical power to the pump, dirt, or debris may cause the pump to fail, eventually bringing about additional water damage. To minimize the potential for water damage due to pump failure. -
Page 4: Installation
this pump with a 2-prong wall outlet. Replace the 2-prong outlet with a properly grounded 3-prong receptacle (a GFCI outlet) installed in accordance with the National Electrical Code and local codes and ordinances. All wiring should be performed by a qualified electrician. 16. -
Page 5: Operation
1. Install the pump in sump pit with minimum diameter of 18" (46cm).Sump pit depth should be 30" (76cm). Construct sump pit of tile, concrete, steel, or plastic. Check local codes for approved materials and for proper installation. 2. Clean sump pit of small stones, gravel, or mud. Secure the pump on a level, solid base. Do not suspend the pump by the discharge pipe, hose, or power cord. -
Page 6: Troubleshooting
8. TROUBLESHOOTING Do not disassemble the motor housing. This pump has NO repairable internal parts, and disassembly may cause an oil leak or dangerous electrical wiring conditions. Description Qty. Vertical float switch Float bracket Screw Screw Shaft Adaptor Impeller Pump body Picture 2 Table 2: Troubleshooting Common Pump Problems Problem... - Page 7 WIL-IO-SP-ECS001-11...
- Page 8 Wilo USA LLC Wilo Canada Inc. Wilo Mexico 1290 N 25th Ave Bay 7-2915 10th Ave NE Managua No 978, Colonia Lindavista Melrose Park, IL 60160 Calgary, AB T2A 5L4 07300 México, D.F., México Tel: 866-945-6872 Tel: 866-945-6236 Tel: + 52 55 5586 3209...
