- Page 1 Professional Heavy Duty Colour Camera CCTV Kit Installation and Operating Instructions These instructions should be retained in a safe place for future reference.
-
Page 2: Please Read Before You Start
INTRODUCTION Section 1 The Response Professional Heavy Duty Camera is a colour, weatherproof day / night camera. The camera easily connects to your TV / VCR / DVR for the protection of your home or office, etc. The camera is easily mounted on the wall using the supplied mounting bracket and fixings. -
Page 3: Tools Required
NIGHT VISION: The camera has built-in infra-red LEDs to allow you to view at night for 24hrs surveillance. The LEDs will automatically activate at night and the picture viewed will turn to black and white. KIT CONTENTS Section 2 1 x Professional Heavy Duty Colour Camera fitted with a 1m mains power lead terminated with a UK plug 1 x 10m BNC (male plug) to BNC (male plug) extension cable 1 x BNC (female) to RCA (male) adaptor... -
Page 4: Installation
INSTALLATION Section 3 1. Use the camera’s main bracket to mark out the x 3 mounting holes and cable connector’s entry hole on the chosen location of the wall (Fig. 1). Drill 3 x 8mm holes for the mounting bracket’s expandable metal wall plugs. Drill 1 x 15mm or 20mm hole for the camera’s cable(s) to pass through the wall (depending on installation, drill a 15mm hole if passing only the video cable (see Fig. - Page 5 Alternatively another option is to supply the mains power to an IP56 rated weatherproof socket outlet per camera (product reference – MK Masterseal box 56480 GRY (IP56 rated). The fitted power plug on the camera can then simply plug into this box as shown (Fig.
-
Page 6: Connection Summary
5. The camera is supplied fitted with a 1m video cable terminated with a BNC female plug. 6. Connect the male end of the video BNC connector from the extension cable into the camera end. 7. Fit the BNC to RCA adaptor into the other end of the extension cable to allow you to plug directly into the video input of your TV / VCR. -
Page 7: Troubleshooting
TROUBLE SHOOTING Section 4 PROBLEM SOLUTION No picture can be viewed Check the mains supply and all video connections to the camera. The TV / VCR / DVR is not tuned to view the correct channel. Poor picture quality Clean the camera lens. Adjust the contrast/brightness on the TV. -
Page 8: Technical Specification
TECHNICAL SPECIFICATION Section 5 ITEM PROFESSIONAL HEAVY DUTY CAMERA Image sensor 1/3” Sharp CCD Video format PAL / NTSC Pixel resolution PAL: 512 (H) x 582 (V) NTSC: 510 (H) x 492 (V) Horizontal resolution 420 TV lines Viewing angle 53°... - Page 9 ACCESSORIES IN THE RANGE Section 6 There are a range of accessories available in the Response CCTV product range to expand your system: CWK1 Wired Colour Camera CCTV Kit Dummy Professional Heavy Duty Camera Wired Internal Colour Dome Camera CCTV Kit...
-
Page 10: Disposal - Recycling Instructions
DISPOSAL – RECYCLING INSTRUCTIONS Section 7 Directive (2002/96/EC) This product is classified by the Waste Electrical or Electronic Equipment (WEEE) Directive. It should not be disposed of with other household or commercial waste. At the end of its useful life the packaging and product should be disposed of via a suitable recycling centre. -
Page 11: Customer Helpline
