Style that revolves around you.
• C
F
O
M
•
EILING
AN
WNER'S
ANUAL
• B
•
IMINI (Indoor)
14/07
WARNING: Read and follow these instructions carefully and be mindful of all warnings shown throughout.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIMINI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Regency BIMINI

Summary of Contents for Regency BIMINI

  • Page 1 Style that revolves around you. • C • EILING WNER'S ANUAL • B • IMINI (Indoor) 14/07 WARNING: Read and follow these instructions carefully and be mindful of all warnings shown throughout.
  • Page 2 & O ENERAL NSTALLATION PERATION NSTRUCTIONS MPORTANT AFEGUARDS: 1. To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly before beginning.

  • Page 3: Important Safety Precautions

    MPORTANT AFETY RECAUTIONS Thank you for choosing a Regency Ceiling Fan. You have chosen the best! Your new ceiling fan has been designed to provide many years of service and enjoyment. Warnings: Warnings: • Disconnect power by removing fuse or turning off circuit breaker before installing the fan and/or optional lighting.

  • Page 4: Unpacking Your Fan

    NPACKING 1. Unpack your fan and check the contents. Do not discard the carton. If warranty replacement or repair is ever necessary, the fan should be returned in original packing. Remove all parts and hardware. Do not lay motor housing on its side, or the decorative housing may shift, be bent or damaged. 2.

  • Page 5: Hanging Bracket

    REPARATION Parts identification on assembled fan Canopy Downrod Collar Cover Motor Housing Blade Arm Blade Detachable Switch Housing PREPARATION: Verify you have all parts before beginning the installation. Check foam insert closely for missing parts. Remove motor from packing. To avoid damage to finish, assemble motor on soft padded surface or use the original foam inset in motor box.
  • Page 6 NSTALLING THE 1. Carefully support fan body (motor) in its styrofoam packing with the mounting collar (where the wires come Hook-up (3) out) facing upward. Wires Ground 2. Loosen the two set screws and remove the downrod pin Wire and cotter pin from the top coupling of the motor assem- Ball bly.
  • Page 7 LECTRICAL ONNECTIONS WARNING: WARNING: To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring. Multiple code choices are included with your fan¡¦s remote control in case: * you have more than one remote control fan and want them to respond only to their own remote control. * you have other radio controlled devices in your home that may interfere with the fan remote control.
  • Page 8 LECTRICAL ONNECTIONS Step 3. (Fig. 3) Receiver to House Supply Wires Electrical Connections: Connect the black (hot) wire from the ceiling Outlet box to the black wire marked "AC in L" from the receiver. Con- nect the white(neutral) wire from the ceiling to the white White (neutral) Black (hot) wire marked "AC in N"...

  • Page 9: Finishing The Installation

    INISHING THE NSTALLATION Step 1. Tuck connections neatly into ceiling outlet box. Ceiling Fan Step 2. Slide the canopy up to mounting bracket and place Outlet Box the key hole on the canopy over the screw on the mounting bracket, turn canopy until it locks in place at the narrow Hanging section of the key holes.

  • Page 10: Switch Housing

    NSTALLATION OF ETACHABLE WITCH OUSING OUNTING 1. Remove one of the three screws on the mounting hub located on the fan motor. 2. Loosen the other two screws. 3. Install detachable switch housing mounting hub to mounting hub. 4. Pass the 2 light wires through the center hole of the detachable switch housing mounting hub. 5.
  • Page 11 3. Attach the switch housing to the switch housing hub. 4. Align the side screws with keyhole slots on edge of switch housing and tighten the side screws. 5. Turn the power on. Your Regency Ceiling Fan is now ready to enjoy! Detachable...

  • Page 12: Operating Your Transmitter

    PERATING RANSMITTER Restore power to ceiling fan and test for proper operation. Install 9 Volt battery (included). To prevent damage to transmitter remove the batteries if not used for long periods of time. (Fig. 1) 1. "LO, MED, HI" buttons: These three buttons are used to set the fan speed as follows: LO= Low speed MED= Medium speed HI= High speed...
  • Page 13 Speed settings for warm or cool weather depend on factors such as the room size, ceiling height, number of fans, etc. The reverse switch is located on top of the motor assembly. Slide the switch to the Left for warm weather operation. Slide the switch to the Right for cool weather operation.

  • Page 14: Troubleshooting

    Make sure these are tight and the ball is completely seated in the bracket. HANK YOU FOR PURCHASING A EGENCY EILING Write to us at: Regency Ceiling Fans P.O. Box 730 Fenton, MO 63026 Visit us on the Web at: www.regencyfans.com 07/14 Regency Ceiling Fans...
