1.0 Appliance TypeThere are four build types and four outputs within the ProCon range.
Please ensure you have the correct unit for the application and where required located correctly
within the cascade prior to beginning the installation.
ProCon 16H & 16HS, ProCon 27H, 27S & 27HS, ProCon 47H & 47S, ProCon 75&77H & 75&77HM
1.1 The ProCon H range of appliances is designed to be applied to systems requiring direct on
boiler weather compensated heating and priority hot water production via a separate high
recovery calorifier/cylinder.
1.2 The ProCon S range of appliances is designed to be applied to systems requiring direct on
boiler weather compensated heating and priority on demand hot water production via an internal
late heat exchanger.
1.3 The ProCon HS range of appliances are designed to be applied to systems requiring direct on
boiler weather compensated heating and priority hot water production via a separate high
recovery Calorifier/Cylinder, where the diverter valve controlling the production of hot water is
within the boiler case.
1.4 The ProCon HS+ can be supplied complete with an integrated high recovery calorifier for
simplified and attractive installation housed within and extended case. The high recovery calorifer
can be located beneath of adjacent to the boilers. (Further information available via the website
www.mhgheating.co.uk)
1.5 The ProCon HM appliance is supplied complete with and integral RVS43 Cascade Manager
capable of controlling an additional 11 ProCon boilers. Each subsequent boiler must be fitted with
an OCI420 Communication Clip.
The product codes for the entire range are:
MHG Heating Ltd Unit 4 Epsom Downs Metro Centre, Waterfield, Tadworth, Surrey KT20 5LR
Telephone 08456 448802 Fax 08456 448803 Email
© MHG Heating Ltd
Product Name
ProCon 16 H
ProCon 16 HS
ProCon 27 H
ProCon 27 S
ProCon 27 HS
ProCon 47 H
ProCon 47S
ProCon 75 H
ProCon 75 HM
ProCon 77 H
ProCon 77 HM
info@mhgheating.co.uk
010114
Product Code
96.30000-7192
96.30000-7193
96.30000-7194
96.30000-7195
96.30000-7196
96.30000-7197
96.30000-7198
96.30000-7188
96.30000-7189
96.30000-7190
96.30000-7191
Web www.mhgheating.co.uk
