Sony KLV-HG26M1 Service Manual

SERVICE MANUAL

Display Unit:
(KLV-HG26M1)
P ower Requirement:
220–240 V AC, 50 Hz
Screen Size: 26 inches
Approx. 58.7 cm measured diagonally
Display Resolution:
1,280 dots (horizontal)
Power Consumption:
110 W
Standby Power Consumption:
0.8 W or less
Dimensions (w h d):
x x
Approx. 79.0
(with stand)
Approx. 79.0
Weight: Approx. 18.4 kg (with stand and rear cover)
Approx. 15.2 kg (without stand and rear cover)
(KLV-SG21M1)
P ower Requirement:
220–240 V AC, 50 Hz
Screen Size: 21 inches
Approx. 53.7 cm measured diagonally
Display Resolution:
1,024 dots (horizontal)
Power Consumption:
95 W
Standby Power Consumption:
0.8 W or less
Dimensions (w x h x d):
Approx. 63.0
(with stand)
Approx. 63.0
Weight: Approx. 11.3 kg (with stand and rear cover)
Approx. 8.6 kg (without stand and rear cover)
KLV-HG26M1/SG21M1
SPECIFICATIONS
768 lines (vertical)
x
x x
49.0 24.0 cm
x x
43.0 13.8 cm (without stand)
x 768 lines (vertical)
x x
46.0 24.2 cm
x x
40.4 12.7 cm (without stand)
Chinese Model
Panel System:
LCD (Liquid Crystal Display) Panel
TV System:
Depending on your country/region selection:
D/K, L, I
Colour System:
PAL, SECAM
NTSC 3.58, 4.43 (only Video In)
Aerial:
75 ohm external terminal for VHF/UHF
Channel Coverage:
VHF: E2 –E12
UHF: E 21–E69
CATV: S1–S20
HYPER: S21–S41
D/K: R1–R12, R21–R69
I: UH F B21–B69
LCD Colour TV
