03

Connecting other audio components

This receiver has both digital and analog inputs, allowing you to connect audio components for playback.
When you set up the receiver you'll need to tell the receiver which input you connected the component to (see
also The Input Setup menu on page 52 ).
Turntable
LAN (10/100)
DC OUTPUT
HDMI OUT 1 OUT 2 IN 1 BD IN IN 2 IN 3 IN 4 IN 6 IN 7 MHL for WIRELESS LAN
(CONTROL) (DVD) (SAT/CBL) (DVR/BDR) (OUTPUT 5 V
ASSIGNABLE 0.9 A MAX)
1 - 7
(OUTPUT 5 V
COAXIAL ASSIGNABLE OPTICAL ASSIGNABLE 0.6 A MAX)
IN IN IN IN OUT
1 2 1 2
(DVD) (SAT/CBL) (TV) (DVR/BDR)
IN 1 PHONO
(CD) IN SIGNAL
GND
L
AUDIO
R
ASSIGN-
ABLE
IN 1 BD IN
HDMI OUT 1 OUT 2
(CONTROL) ( DVD )
ASSIGNABLE
1 - 7
IN 1
( CD )
ASSIGN-
ABLE
! If your turntable has line-level outputs (i.e., it has a built-in phono pre-amp), connect it to the ANALOG IN 1
(CD) inputs instead.
! You can't hear HDMI audio through this receiver's digital out jack.
CD player, MD, DAT, etc.
Select one
AUDIO OUT DIGITAL OUT DIGITAL IN
R ANALOG L COAXIAL OPTICAL OPTICAL
LAN
(10/100)
IN 2 IN 3 IN 4 IN 6 IN 7 MHL
( SAT/CBL ) ( DVR/BDR ) ( OUTPUT 5 V
0.9 A MAX )
COAXIAL OPTICAL
ASSIGNABLE ASSIGNABLE
IN 1 IN 2 IN 1 IN 2
( DVD ) ( SAT/CBL ) ( TV ) ( DVR/BDR )
PHONO
IN
SIGNAL
GND
L
AUDIO
R

Connecting additional amplifiers

This receiver has more than enough power for any home use, but it's possible to add additional amplifiers to every
channel of your system using the pre-outs. Make the connections shown below to add amplifiers to power your
speakers.
PRE OUT
SUBWOOFER FRONT CENTER SURROUND SURR BACK T.MIDDLE F WIDE
1 (Single)
L
R
2
PRE OUT
SUBWOOFER FRONT CENTER SURROUND SURR BACK T.MIDDLE
1
DC OUTPUT
for WIRELESS LAN
( OUTPUT 5 V
0.6 A MAX )
2
OUT
! If you're not using a subwoofer, change the front speaker setting (see
LARGE.
! You can use the additional amplifier on the surround back channel pre-outs for a single speaker as well. In this
case plug the amplifier into the left (SURROUND BACK L (Single)) terminal only.
! The sound from the surround back terminals will depend on how you have configured the
ting on page 106 .
! If you have two subwoofers, the second subwoofer can be connected to the SUBWOOFER 2 terminal.
Connecting two subwoofers increases the bass sound to achieve more powerful sound reproduction.
! To hear sound only from the pre-outs, switch the speaker terminals to SP: OFF
nect any speakers that are connected directly to the receiver.
It is also possible to hear sound only from the pre-outs by switching the AMP setting to OFF and setting the
pre-amp mode to turn the power amplifiers for all channels off (see
39
Connecting your equipment
ANALOG
INPUT
L
Front channel
R
amplifier
ANALOG
INPUT
Center channel
amplifier (mono)
ANALOG
INPUT
L
Surround
R
channel amplifier
ANALOG
INPUT
L
Top middle
R
F WIDE channel amplifier
(Single)
L
ANALOG
INPUT
R
L
Front wide
R
channel amplifier
ANALOG
INPUT
L
Surround back
R
channel amplifier
ANALOG
INPUT
ANALOG
INPUT
Speaker Setting
(page 85
Setting the Audio options
Powered
subwoofer 1
Powered
subwoofer 2
on page 103 ) to
Speaker system set-
) or simply discon-
on page 81 ).
