Part List - REDCAT RockSlide S10 XT Owner's Manual

RCT-H001
Aluminum Side Plate (left/right)
RCT-H005
2P
Wheel Shaft (front/rear)
RCT-H010
2P
Aluminum Side Plate Post
RCT-H016
8P
Front/Rear Upper Linkage Ball
Stud.(Dia.: 5.8mm)

PART LIST-1

RCT-H111
Upper Link Mounts + Screws
4pcs(Round Head Self Tapping
Screw 2.6*8mm) + Screws 2pcs
(Round Head Screw 2.5*17mm)
+ Washers 2pcs (2.5*5.5*0.5)
RCT-H007
2P
Motor Pinion Gear(8T)+
Set Screw 2.5*2.5mm
RCT-H012
2P
Gear Pin-1 (Dia.: 5mm,
Length 41mm)
RCT-H017
8P
Front/Rear Lower Linkage Ball
Stud.(Dia.: 5.8mm)
RCT-H112
Radio Tray+ Stick Battery Plate
+ Battery Strap+Screws 4pcs
(Round Head Screw 2.5*6) +
Nuts 4pcs (M2.5)
RCT-H008
Wheel Frame(metal)+Cap Head
Screw 2*8mm(12pcs)
RCT-H013
4P
Gear Pin-1 (Dia.:4mm,
Length 21.6mm)
RCT-H018
6P
Front/Rear Spur Gear Mount
Pin 2*12mm
RCT-H004
2P
Drive Shaft (front/rear)
L=62.5mm
RCT-H009
4P
Aluminum Wheel Hex.+ Wheel
Pin 2*10mm+Set Screw 3*3mm
RCT-H015
8P
Shock Set Bush
RCT-H019
8P
Steering Hub Bush
10
