REDCAT Twister XTG Instruction Manual

Please read this manual carefully before assembling and or disassembling your vehicle.
1/10TH SCALE 2WD ELECTRIC POWERED OFF ROAD TRUGGY
- BRUSHED VERSION
- BRUSHLESS VERSION
2.4GHz RADIO SYSTEM
This is a new generation 1-10th scale 2WD off road vehicle. It is
build in RTR version at factory.
It is also made in two versions ( brushed version and brushless
version). The following are the specifications for motors and
speed controllers.
Brushed ESC:100A , ( Max.voltage: 7.4V)
Brushed motor: RC540 (20000rpm)
Brushless ESC: 90A, ( voltage: 7.4V -12V)
compatible for sensor/sensorless brushless motor
Brushless motor: KV 3930
Read carefully and fully understand the instructions before commencing assembly and/or disassembly.
This R/C vehicle is intended for persons over 14 years of age. Children under 14 years of age should only
operate this car under adult supervision.
When assembling this kit, tools including knives are used. Extra care should be taken to avoid personal
injury.
Read and follow the instructions supplied with all tools ( not included in kit).
Keep out of reach of little children. Children must not be allowed to put any parts in their mouth, or pull
vinyl bag over their head.
TECHNICAL DATA & MAIN FEATURES
Brushed Version
Brushless Version

SAFE INFORMATION

INSTRUCTION MANUAL

NOTE:
Battery and charger may not
be supplied in the packaging,
unless specifically given
Length:440mm
Width:325mm
Wheel Width: 58mm
Wheel Dia.: 106mm
Gear Ratio: 1:8.8 (brushed),
1:9.6 (brushless)
Net Weight:1.195kg (battery not included)
Height:160mm
Wheelbase: 285mm
14+
14+
