Summary of Contents for REDCAT GEN9
-
Page 14: Protective Features
ESC GUIDE RCR-2CENR RADIO SYSTEM Specs: Model: WP-1040-BRUSHED-Crawler-V4 Cont./Peak Current: 40A / 180A LIPO/NiMH Cells: 2-3S LIPO / 5-9 Cells NiMH Applications: 1/10th Crawlers 540/550 Size Brushed Motor ≥12T Motor Limit 2S LiPO / 5-6 Cells NiMH: 540/550 Size Brushed Motor ≥17T Motor Limit 3S LiPO / 7-9 Cells NiMH: Built in BEC: 6V @ 3A (Switch-mode) -
Page 15: Operation
RCR-2CENR RADIO SYSTEM OPERATION: Step 1: Connect all components (as shown in wiring diagram) and recheck all connections before moving to the next step. Step 2: Set the Throttle Range. This ESC can automatically recognize the neutral position of the transmitter, but you need to follow the following steps. -
Page 16: Troubleshooting
ON/OFF switch was turned ON. ESC. soldered and firmly connected. 2. The ESC switch may be damaged. 2. Contact Redcat support. The vehicle ran backward when you 1. The radio “Throttle Reverse” switch 1. Switch the radio “Throttle Reverse” pulled the throttle trigger towards you.
