DRILL-DRIVER
Chuck
Motor
Gear Train
No Load Speed
Clutch
Craftsman 114540 - 18V test criteria
380 in.lb. torque
320 #8 x 1.25 in. wood screws in low speed per battery pack charge into pine lumber.
280 3/8 in. diameter holes per battery pack charge into 2 in. nominal pine lumber.
KNOW YOUR DRILL-DRIVER
See Figure 1.
Before attempting to use your drill-driver, familiarize
yourself with all operating features and safety
requirements.
KEYLESS CHUCK
Your drill-driver has a keyless chuck that allows you to hand
tighten or release drill bit in the chuck jaws.
SWITCH
To turn your drill-driver ON, depress the switch trigger.
Release switch trigger to turn your drill-driver OFF.
SWITCH LOCK
The switch trigger can be locked in the OFF position. This
feature helps reduce the possibility of accidental starting
when not in use.
VARIABLE SPEED
This tool has a variable speed switch that delivers higher
speed with increased trigger pressure. Speed is controlled
by the amount of switch trigger depression.
TWO SPEED GEAR TRAIN
Your drill-driver has a two speed gear train designed for
drilling or driving at HI or LO speeds. A slide switch is
located on top of your drill to select either HI or LO speed.

PRODUCT SPECIFICATIONS

315.114540
1/2 in. Keyless
DC Motor 18 Volt
Two Speed
0-350 RPM (Low)
0-1300 RPM (High)
24 Positions
FEATURES
7
Maximum Torque
CHARGER
Rating
Charging Voltage
Charge Rate
BATTERY PACK
(for 114540)
(for 11435 combo)
FORWARD/REVERSE SELECTOR
(DIRECTION OF ROTATION SELECTOR)
Your drill-driver has a forward/reverse selector located
above the switch trigger.
WRIST STRAP
A wrist strap is provided to reduce the chances of
dropping your drill-driver. Place one hand through the wrist
strap when carrying tool.
BIT STORAGE
When not in use, bits provided with your drill-driver can be
placed in the storage area located on the bottom of the
motor housing.
LEVEL
To keep drill bit level during drilling operations, a level is
located on the top and end of the motor housing.
WARNING:
If any parts are missing, do not operate
your drill-driver until the missing parts are replaced.
Failure to do so could result in possible serious
personal injury.
380 in.lb.
Item No. 11041
9
(1425301)
120 V, 60 Hz, AC only
7.2 - 24 Volt
1 Hour
Item No. 11045
9
(1323514)
(1323905)
