Operator's Manual
1/2 in., 18 VOLT CORDLESS DRILL-DRIVER
Variable Speed / Reversible
Model No.
315.114540
Save this manual for
future reference
WARNING:
To reduce the risk of injury, the
user must read and understand the operator's
manual before using this product.
Customer Help Line: 1-800-932-3188
Sears, Roebuck and Co., 3333 Beverly Rd., Hoffman Estates, IL 60179 USA
Visit the Craftsman web page: www.sears.com/craftsman
983000-184
11-03
R

Advertisement

loading

  Also See for Craftsman 315.114540

  Related Manuals for Craftsman 315.114540

  Summary of Contents for Craftsman 315.114540

  • Page 1 To reduce the risk of injury, the user must read and understand the operator's manual before using this product. Customer Help Line: 1-800-932-3188 Sears, Roebuck and Co., 3333 Beverly Rd., Hoffman Estates, IL 60179 USA Visit the Craftsman web page: www.sears.com/craftsman 983000-184 11-03...
  • Page 2: Table Of Contents

    Exploded View and Repair Parts List ........................... 17 Parts Ordering / Service ............................... 18 WARRANTY FULL ONE YEAR WARRANTY ON CRAFTSMAN 1/2 in. CORDLESS DRILL-DRIVER If this 1/2 in. Cordless Drill-Driver fails to give complete satisfaction within one year from the date of pur- chase, RETURN IT TO THE NEAREST SEARS STORE OR SEARS SERVICE CENTER IN THE UNITED STATES, and Sears will repair it, free of charge.
  • Page 3: Introduction

    Use battery only with charger listed. MODEL BATTERY PACK CHARGER 315.114540 Item No. 11045 Item No. 11041 (1323514) (1425301) 315.114350...
  • Page 4: Specific Safety Rules

    GENERAL SAFETY RULES Tool Use and Care Use clamps or other practical way to secure and Maintain tools with care. Keep cutting tools sharp support the workpiece to a stable platform. Holding and clean. Properly maintained tools, with sharp the work by hand or against your body is unstable and cutting edges are less likely to bind and are easier to may lead to loss of control.
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS FOR CHARGER AND SPECIFIC SAFETY RULES Never use a battery that has been dropped or re- Do not operate charger if it has received a sharp ceived a sharp blow. A damaged battery is subject to blow, been dropped, or otherwise damaged in any explosion.
  • Page 6 SYMBOLS Important: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz...
  • Page 7: Product Specifications

    (1323514) (for 11435 combo) (1323905) Craftsman 114540 - 18V test criteria in.lb. torque #8 x 1.25 in. wood screws in low speed per battery pack charge into pine lumber. 3/8 in. diameter holes per battery pack charge into 2 in. nominal pine lumber.
  • Page 8: Features

    FEATURES TWO-SPEED LEVEL GEAR TRAIN (HI-LO) TORQUE ADJUSTMENT KEYLESS RING CHUCK ® LEVEL REAR VIEW DIRECTION OF ROTATION SELECTOR (FORWARD/REVERSE) SWITCH TRIGGER STORAGE SCREWDRIVER BITS BATTERY PACK SHOWN IN TOOL BATTERY PACK SHOWN IN CHARGER 4-1/2 in. WRIST STRAP CHARGER RED LED ON INDICATES FAST CHARGING MODE GREEN LED ON AFTER FAST CHARGING...
  • Page 9: Operation

    OPERATION LED FUNCTIONS OF CHARGER WARNING: Do not allow familiarity with your drill- driver to make you careless. Remember that a LED WILL BE ON TO INDICATE STATUS OF careless fraction of a second is sufficient to inflict CHARGER AND BATTERY PACK: severe injury.
  • Page 10 OPERATION SWITCH TO INSTALL BATTERY PACK See Figure 2. Lock switch trigger on your drill by placing the direction To turn your drill ON, depress the switch trigger. To turn it of rotation selector in center position. See Figure 5. OFF, release the switch trigger.
  • Page 11 OPERATION SWITCH LOCK KEYLESS CHUCK See Figure 5. See Figure 6. The switch trigger can be locked in the OFF position. This Your drill has a keyless chuck. As the name implies, you can feature can be used to prevent the possibility of accidental hand tighten or release drill bits in the chuck jaws.
  • Page 12 OPERATION OPERATION INSTALLING BITS REMOVING BITS See Figure 7. See Figure 7. Lock the switch trigger by placing the direction of Lock the switch trigger by placing the direction of rotation selector in center position. See Figure 5. rotation selector in center position. See Figure 5. Open or close chuck jaws to a point where the open- Loosen the chuck jaws from drill bit.
  • Page 13 OPERATION BIT STORAGE DRILLING See Figure 10. See Figure 12. When not in use, bits provided with your drill can be LEVEL placed in the storage area located on the bottom of your drill as shown in Figure 10. SCREWDRIVER ®...
  • Page 14: Operation

    OPERATION Insert hex key in chuck and tighten chuck jaws se- CHUCK REMOVAL curely. Tap sharply with a mallet in a counterclockwise See Figures 13, 14, and 15. direction. This will loosen chuck on the spindle. It can The chuck must be removed in order to use some now be unscrewed by hand.
  • Page 15: Maintenance

    Do not abuse power tools. Abusive practices can damage tool as well as workpiece. Craftsman replacement parts. Use of any other part may create a hazard or cause product damage. Only the parts shown on parts list, page 17, are intended to be repaired or replaced by the customer.
  • Page 16 NOTES...
  • Page 17: Exploded View And Repair Parts List

    CRAFTSMAN 1/2 in., 18 VOLT CORDLESS DRILL-DRIVER – MODEL NO. 315.114540 The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your 1/2 in., 18 VOLT CORDLESS DRILL-DRIVER or when ordering repair parts.
