Installation Guide; System Overview - Danfoss TP7001 Range Installation Manual

1.0 Installation Guide

Please Note:
This product should only be installed by a qualifi ed electrician or
competent heating installer and should be in accordance with the
current edition of the IEEE wiring regulations.
GB
GB

2.0 System Overview

Thermostat Features
Power supply
Memory backup
Factory set calendar clock
Switching action of output relay
Switch rating of relay contact
Remote sensor inputs
Rated Impulse Voltage
Dimensions (mm)
Ball Pressure Test
Temperature Range
Design Standard
Control Pollution Situation
Time accuracy
Temperature accuracy
4
TP7001
2 x AA/MN1500/LR6
alkaline batteries
Retained for the life of the product
Automatic summer/winter time change
1 x SPDT, Type 1B
3(1) A, 10-230 Volts
Up to three remote sensors, which can be
set by the installer for remote temperature
sensor, limit sensor, outdoor sensor, window
contact or telephone activated switch
contacts
2.5 kV
140 wide x 91 high x 28 deep
5-30°C
EN 60730-2-7
Degree 2
± 1 minute per month
TP7001M
230V ± 15% 50Hz
75°C
±1°C
TP7001
