- Page 1 ENGLISH (E) FRANÇAIS (F) DEUTSCH (D) Model 32W300Ps 32W301Ps 26W300P LCD Colour Television Televiseur LCD Farbfernsehgerät Operating Instructions Manual de l’utilisateur Bedienungsanleitung 32L0141B_Eng.indd 1 32L0141B_Eng.indd 1 6/7/2007 9:21:11 AM 6/7/2007 9:21:11 AM...
-
Page 2: Features
ESPAÑOL Features ENGLISH • LCD MONITOR Resolution: 1366 x 768 pixels • On-Screen Language Display in 13 languages (English, German, French, Spanish, Italian, Dutch, Portuguese, Swedish, Finnish, Polish, Greek, Russian or Turkish) • NICAM/German A2 STEREO Reception • Auto installation system •... -
Page 3: Table Of Contents
Contents Features ............2 Contents ............3 Safety Precautions ...........4 Installation and important information ....5 Location of controls ..........6 Remote Control ..........7 Antenna connection .........9 Auto setup............10 Guide to using the menu system ....11 Selecting the video input source ....11 On-screen Language Selection .....12 Auto tuning .............13 Changing the order of stored channels ..14 Manual tuning ..........15... -
Page 4: Safety Precautions
Safety Precautions This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken to obtain the best results and for safety to be assured. Please read the points below for your own safety. They are of a general nature, intended to help with all electronic consumer products and some points may not apply to the goods you have just purchased. -
Page 5: Installation And Important Information
Please take note EXCLUSION CLAUSE Toshiba shall under no circumstances be liable for loss and/or damage to the product caused by: fire; earthquake;... -
Page 6: Location Of Controls
Location of controls Front Side Illustration of 32W300Ps Front Side Description of Indicators and Controls 1. Loudspeakers 2. Remote sensor (On/Standby) indicator: The LED indicator lights up red in standby mode, and green in the power ON mode. (Volume) +/– buttons : To set the volume. In Menu: Setting. -
Page 7: Remote Control
Remote Control Function Page Enter standby mode or turn on the power 11 Display program position number Select an input source 11, 30 Select picture format Select channel Select Teletext page 18, 19 Switches between the present channel and the last selected channel Sub Page selection Select between the available broadcast audio... - Page 8 Remote Control Install the batteries Use batteries type UM3 (AA-Size). Do not use old or weak batteries. The remote control may not work properly with a weak voltage from such batteries. Replace exhausted batteries with new ones. Never try to recharge normal batteries - this could cause an explosion.
-
Page 9: Antenna Connection
Connect your antenna as shown below (A). Connections to other equipment is explained further on pages 33-35. If you have problems with reception, consult a specialist of antenna. Back Side Illustration of 32W300Ps (A) Outdoor antenna: If the outdoor antenna already exists, you can also connect to it for analogue TV-program. -
Page 10: Auto Setup
Auto setup Your unit has an Automatic installation which makes installation in your unit easy. When you turn on the unit for the first time, the Automatic installation routine is activated. Using this routine, you can select the on-screen language and automatically search for and store all available channels of suitable signal strength in the correct order. -
Page 11: Guide To Using The Menu System
Guide to using the menu system/Selecting the video input source Make sure the antenna connection Guide to using the menu system and power supply are connected as Press MENU, the menu will ap- per the description on page 9. pear on the screen. AUTO TUNING Preparation: MANUAL TUNING... -
Page 12: On-Screen Language Selection
On-screen Language Selection This TV has 13 different languages Press MENU, the menu will for menu set up which can be appear on the screen. selected through the On-Screen AUTO TUNING Press to select MANUAL TUNING Display: English, German, French, (SETUP) menu. -
Page 13: Auto Tuning
Auto tuning Perform this feature to search for and store new TV programmes after the Automatic installation. (page 10) This TV has 18 different countries for menu set up which can be selected through the On-Screen Display: UK, Germany, France, Spain, Italy, Belgium, Netherlands, Switzerland, Austria, Portugal, Finland, Poland, Czech Republic, Hungary, Slovenia, Greece, Russia, Turkey and Other. -
Page 14: Changing The Order Of Stored Channels
Changing the order of stored channels The Automatic station presetting Press MENU, the menu will stores the stations found in a appear on the screen. specific order. This will normally AUTO TUNING Press to select MANUAL TUNING be the correct order, however if (SETUP) menu. -
Page 15: Manual Tuning
Manual tuning Usually the Auto Tuning stores all available stations in the reception area. If some stations have poor reception, they may not be stored - however, you can store these manually if you wish. Example: Preset the ZDF on program position 2. Preparation: Select program position 2. -
Page 16: Connection To Satellite Receiver
You can not store the same station once again additionally in LCD-Monitor which already stored in satellite receiver. Back Side Satellite Receiver (AV1) Illustration of 32W300Ps Scart-cable (not supplied) 32L0141B_Eng.indd 16 32L0141B_Eng.indd 16 6/7/2007 9:21:16 AM 6/7/2007 9:21:16 AM... -
Page 17: Basic Operation
Basic Operation Channel selection • With the numbered buttons. • Press CH LIST to display CH LIST. Press Example: to select the desired program, then press CH LIST to display the selected program. No. 2: Press 0 and within 2 seconds, press 2. The station stored on CH 2 will appear. -
Page 18: Teletext
Teletext Teletext is sent page by page. This unit is able to automatically store up to 256 pages, but they can only be accessed once they have been stored. This can take a few moments. Fastext/TOPtext The Fastext/TOPtext is teletext with a special directory. On the lower part of the screen there are four different coloured fields (red, green, yellow and blue). - Page 19 Teletext Hold Pages Some pages are divided up into subpages by the channel. Subpages are automatically shown in turn, as they are transmitted. In order to hold the page, press . Press again in order to display the next subpage. Directly Select Subpages You can directly select the subpages if required.
-
Page 20: Stereo Reception With The Built-In Tuner
Stereo reception with the built-in tuner The built-in Tuner can detect and NICAM stereo sound reception: receive NICAM stereo broadcasts automatically. Press MENU, the menu will appear on the screen. NICAM AUTO Press to select BASS (AUDIO) menu. TREBLE BALANCE SURROUND SPEAKERS EXIT : END... - Page 21 Stereo reception with the built-in tuner When 2-channel sound reception Each time you press AUDIO I/II, the sound channel will switch is available, you can select your to the alternative channel available. preferred audio with the AUDIO I/II button. NICAM 2-channel sound reception (not available in Germany) N I C A M / M 2...
-
Page 22: Bass, Treble And Balance
Bass, Treble and Balance Press MENU, the menu will appear on the screen. NICAM AUTO Press to select BASS (AUDIO) menu. TREBLE BALANCE SURROUND SPEAKERS EXIT : END MENU: RETURN Press to select BASS, TREBLE or BALANCE, then NICAM AUTO press ENTER. -
Page 23: Using The Surround Sound Feature
Using the surround sound feature/ Turning off the built-in speakers Using the surround sound feature The SURROUND feature processes the audio signal to expand the listening field wider and deeper to create a ‘pseudo surround-sound’ from the TV’s speakers. The feature works with stereo signals from TV broadcast or AV input. -
Page 24: Selecting The Picture Preference
Selecting the picture preference/ Brightness, Contrast, Colour and Sharpness Selecting the picture preference You can select from four picture preferences ‘Sports, Standard, Movie, and Memory’ as described in the following table: Press MENU, the menu will appear on the screen. PICTURE PREFERENCE Press to select... -
Page 25: Dnr
DNR/Selecting the colour temperature DNR (Digital Noise Reduction) can reduce the roughness of the picture. Press MENU, the menu will appear on the screen. PICTURE PREFERENCE Press to select SPORTS BRIGHTNESS (PICTURE) menu. CONTRAST COLOUR TINT SHARPNESS EXIT : END MENU: RETURN Press to select DNR,... -
Page 26: Blue Back
Blue back/Back light Blue back You can set the TV to automatically change to a blue screen and mute the sound if the signal is weak or absent. Press MENU, the menu will appear on the screen. PICTURE PREFERENCE Press to select SPORTS BRIGHTNESS... -
Page 27: Picture Format
Picture format The broadcaster may transmit a Wide Screen Signalling (WSS) signal which can determine the correct picture width and set it automatically when the AUTO setting is used. If you want to change this setting, you can select from the formats listed below. AUTO Manual format setting Press PICTURE SIZE repeatedly until... -
Page 28: Scrolling The Picture In Cinema Mode
Scrolling the picture in CINEMA mode/Auto 4:3 Default Scrolling the picture in CINEMA mode When the CINEMA mode is selected, you can adjust the vertical picture position. Note: You cannot move the picture vertically in any of the other picture modes. -
Page 29: Adjusting The Av Colour Setting
Adjusting the AV colour setting/Reset the TV Adjusting the AV colour setting The AV colour setting affects the AV inputs only - the TV’s tuner is not affected. Please refer to pages 33 and 34 for more information about connecting other equipment. Press MENU, the menu will appear on the screen. -
Page 30: Pc Connection
PC connection As PCs are sometimes supplied with a ‘conventional’ CRT monitor, you may need to adjust the display settings of your PC’s graphics card, otherwise the pictures may not appear correctly. Switch on your PC (still with your original monitor) - select ‘1360 x 768’ for the screen resolution, and select 60 Hz for the on-screen refresh rate. - Page 31 PC connection Note: Example: Adjust the brightness. The PC mode menu settings are not effective for normal TV mode or During PC mode press MENU. external input mode. The menu appears on the TV- BRIGHTNESS screen. CONTRAST Press to select HOR POSITION VER POSITION (PICTURE) menu.
-
Page 32: Connecting An Hdmi Or A Dvi Device To The Hdmi Input
Connecting an HDMI or a DVI device to the HDMI input The HDMI input receives digital audio and uncompressed video from a HDMI equipped device or uncompressed digital video from a DVI equipped device. When you connect to a DVI device with a HDMI-to-DVI adapter cable, it only transfers the video signal, so it is necessary to use separate analogue cables to transfer the audio signals. -
Page 33: Connection To Other Equipment
Connection to other equipment 1. Connecting other units to your TV TV (Left side view) To ANT (AV2) Antenna Satellite antenna (AV1) Video recorder DVD player Satellite receiver (All illustrated SCART cables and antenna cables are not supplied) DVD player: For superior picture quality, set your DVD player to output an RGB signal (refer to your particular DVD player owner’s manual). - Page 34 Connection to other equipment 3. Connecting an audio system TV (Left side view) Stereo amplifier To VAR (variable) AUDIO OUT Audio input (Audio cable, not supplied) This connection allows you to hear the TV sound through external speakers connected to an audio amplifier. To control the audio through the amplifier, turn on the TV and the amplifier, set the volume of both to a moderate level, and turn off the TV’s built-in speakers (see ‘Turning off the built-in speakers’...
- Page 35 Connection to other equipment 5. Connecting to a DVD player or other AV device with Component Video outputs TV (Left side view) Audio cable (not supplied) Video cable (not supplied) To COMPONENT IN Y Pb Pr Component output Audio output DVD player If your DVD player (or other device) has Component Video output jacks, use a suitable set of cables (RCA/Phono) to connect these to the Component Video inputs on this TV as shown - it can greatly enhance...
-
Page 36: Power Return Feature
Power return feature/Troubleshooting table/Error messages Power return feature If the power is cut off while you are viewing the TV and the power is resupplied, the Power return feature will turn the TV on automatically. If the power is going to be off for a long time or you are going to be away from the TV for a long time, unplug the power cord to prevent the TV from turning on in your absence. -
Page 37: Specifications
Specifications Specifications 26W300P 32W300Ps/32W301Ps System PAL UK, IR, CCIR, FRENCH System, B/G, D/K, I/I, L AV Input receivable: NTSC 3.58, NTSC 4.43/PAL 60 Preset channels 99 channels Frequency Range IreE2~E4, X~Z+2, S1~S10, E5~E12, S11~S41, E21~E69 Power Supply AC 220-240V, 50/60Hz Power Consumption: Operation: approx.
