- Page 1 Technical Description and Operating Instructions Cinebar 21 2.1 Soundbar with active Subwoofer...
-
Page 2: Table Of Contents
Activating and deactivating ...........................12 Auto Level ..............................12 Subwoofer volume ............................12 Phase switch..............................12 Limiter .................................12 Adjusting the sound ............................13 Display brightness ............................13 Lip Sync ...............................13 Settings ..................................13 Care and cleaning ...............................14 Protecting the environment ............................14 Troubleshooting ................................15 Technical data ................................16 • Cinebar 21... -
Page 3: General Notes And Information
In case of complaint we will need the following informa- prior notice and in no way constitutes any liability on the tion to process your enquiry: part of Lautsprecher Teufel GmbH. 1. Invoice Number No part of these instructions may be reproduced in any... -
Page 4: Safety Notes
Also take care not to stand vases or other containers of liquid on or near the unit in order to avoid liquid getting into the case. If water or other foreign objects • Cinebar 21... - Page 5 (e.g. during a holiday), or if a thunderstorm is forecast, amplifi ers etc.) disconnect it from the mains power supply. Leaked batteries may damage the remote control. • In case of prolonged absence, remove the battery from the remote control. • Cinebar 21...
-
Page 6: Overview
1 x subwoofer US 5106/1 SW 1 x remote control 1 x power cord for subwoofer 1 x power cord for Cinebar 21 1 x RCA cable for Cinebar subwoofer connection Check to be sure • Check that all items have been delivered and that noth- ing is damaged. -
Page 7: Setup/Wall Mounting
A location directly under the TV set is ideal. Hang the 2. Use a metal detector to ensure that there are no cables Cinebar 21 either directly to the wall or place it on the or pipes in the areas where you intend to drill. If neces- stand below the TV set. -
Page 8: Control Elements And Connections
Control elements and connections Cinebar 21 – Top and front side Item Name Description Power Switch the device on or to standby Select an input jack (Aux In, Digital In Source Optical, Digital In Coaxial Increase (+) / Vol –/+ reduce (–) volume... - Page 9 Power Power control LED Auto / On Subwoofer switched on continuously (On) or only switched on when receiv- ing a control signal from the Cinebar 21 (Auto) Phase Switch the subwoofer phase (similar to swapping the speaker cables) Adjust sensitivity of automatic activation...
-
Page 10: Connection Example
• If your TV set does not have separate audio output TV set analogue A u x jacks, you can relay the sound to the Cinebar 21 using DVD player digital O pt i ca l a scart/RCA adapter. -
Page 11: Remote Control
Activating and deactivating • With the Power (1) button or (22), you can switch your Cinebar 21 on or to standby. The standby indica- tor (5) will illuminate in red in standby mode. Selecting a source Also see page 10, table 1. -
Page 12: Subwoofer
The subwoofer will be activated when the Cinebar 21 is activated. Switch position On: The subwoofer remains on even if the Cinebar 21 is switched to standby. Auto Level • You can adjust the activation sensitivity of the sub- woofer using the Auto Level (15) control. -
Page 13: Adjusting The Sound
You can only adjust the sound settings with the remote control only. Selecting sound effects Your Cinebar 21 is equipped with Dolby Virtual Speaker technology. This simulates the audio impression of a 5.1 surround sound system using the soundbar. Two sound effects are possible: –... -
Page 14: Care And Cleaning
Care and cleaning Clean your Cinebar 21 regularly with a soft, damp micro- Attention Risk of damage! fi bre cloth. When doing so, please be absolutely sure to Using the wrong cleaning materials may dam- observe the following instructions: age the delicate surface of the case. -
Page 15: Troubleshooting
Sub + (30) button. The subwoofer hums. The subwoofer is connected to another Connect the subwoofer and Cinebar 21 to the circuit than the rest of the system. same circuit. The buzzing is caused by problems with Buy a line fi... -
Page 16: Technical Data
Technical data Active subwoofer Cinebar 21 US 5106/1 SW Dimensions (WxHxD) 240 x 312 x 330 mm 918 x 115 x 110 mm Weight 6.9 kg 6.2 kg Operating voltage: 230 V~/50 Hz 230 V~/50 Hz Max. power consumption 130 watts...
