Page 1: Technical Description And Operating Instructions
Technical Description and Operating Instructions Cinebar ® 2.1 Soundbar... -
Page 2: Table Of Contents
Settings ..................................11 Basic functions ..............................11 Adjust the sound ............................11 Display brightness ............................11 Lip Sync ...............................11 Care and cleaning ...............................12 Protecting the environment ............................12 Batteries and rechargeable batteries .......................12 Disposing the unit ............................12 Troubleshooting ................................13 Technical data ................................13 • Cinebar 21... -
Page 3: General Notes And Information
In case of complaint we will need the following informa- prior notice and in no way constitutes any liability on the tion to process your enquiry: part of Lautsprecher Teufel GmbH. 1. Invoice Number No part of these instructions may be reproduced in any... -
Page 4: Safety Notes
Also take care not to stand vases or other containers plenty of plain water and if necessary see a doctor. of liquid on or near the unit in order to avoid liquid getting into the case. If water or other foreign objects • Cinebar 21... - Page 5 • Only use suitable wall holders to mount the speakers. Verify the carrying capacity of the walls. • Do not place the unit near sources of heat (e.g. heat- ers, ovens, other heat generating equipment such as amplifi ers etc.) • Cinebar 21...
-
Page 6: Overview
Overview Product contents 1 x Cinebar 21 1 x stand for Cinebar 21 1 x remote control 1 x power cord 1 x RCA cable for Cinebar subwoofer connection Check to be sure • Check that all items have been delivered and that noth- ing is damaged. -
Page 7: Setup/Wall Mounting
A location directly under the TV set is ideal. Hang the 2. Use a metal detector to ensure that there are no cables Cinebar 21 either directly to the wall or place it on the or pipes in the areas where you intend to drill. If neces- stand below the TV set. -
Page 8: Control Elements And Connections
Control elements and connections Cinebar 21 – Top and front side Item Name Description Power Switch the device on or to standby Select an input jack (Aux In, Digital In Source Optical, Digital In Coaxial Increase (+) / Vol –/+ reduce (–) volume... -
Page 9: The Battery
Remote control Item Name Description Switch the Cinebar 21 on/to standby Optical Select Digital In Optical (9) as a source Mute the speakers Coaxial Select Digital In Coaxial (8) as a source Reduce subwoofer volume Sub +/– Activate and deactivate surround sound... -
Page 10: Connection Example
• If your TV set does not have separate audio output TV set analogue A u x jacks, you can relay the sound to the Cinebar 21 using DVD player digital O pt i ca l a scart/RCA adapter. -
Page 11: Settings
(22), you can switch decrease the bass and high-range tones individually. your Cinebar 21 on or to standby. The standby indica- 1. Push the button Tone (31) several times if necessary. tor (5) will illuminate in red in standby mode. -
Page 12: Care And Cleaning
Care and cleaning Clean your Cinebar 21 regularly with a soft, damp mi- Attention Risk of damage! crofi bre cloth. When doing so, please be absolutely sure Using the wrong cleaning materials may dam- to observe the following instructions: age the delicate surface of the case. -
Page 13: Troubleshooting
The settings are not correct. Adjust the sound settings as described on page 11. Playback is noisy. Generally speaking, the Cinebar 21 is a Ensure that the source is sending a clean signal to the Cinebar 21. very low-noise system. In most cases, the... - Page 14 • Cinebar 21...
- Page 15 • Cinebar 21...
