SERVICE MANUAL
Ver 1.1 2004. 09
CD player section
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wave length: 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW
(This output is the value measured at a distance of about 200 mm from
the objective lens surface on the optical pick-up block with 7 mm
aperture.)
Spindle speed
200 r/min (rpm) to 500 r/min (rpm) (CLV)
Number of channels
2
Frequency response
20 - 20 000 Hz +1/–2 dB
Wow and flutter
Below measurable limit
Sony Corporation
9-877-502-02
2004I02-1
Personal Audio Company
Published by Sony Engineering Corporation
© 2004.09
CFD-V8L
Model Name Using
Similar Mechanism
CD Mechanism Type (Former Type/New Type)
Optical Pick-up Type (Former Type/New Type)
Tape Transport Mechanism Type

SPECIFICATIONS

Radio section
Frequency range
FM 87.6 - 107 MHz
LW 153 - 279 kHz
IF
FM: 10.7 MHz
LW: 455 kHz
Aerials
FM: Telescopic aerial
LW: Built-in ferrite bar aerial
Cassette-corder section
Recording system
4-track 2 channel stereo
Fast winding time
Approx. 120 s (sec.) with Sony cassette C-60
Frequency response
TYPE I (normal): 80 - 10 000 Hz
General
Speaker
CD RADIO CASSETTE-CORDER
AEP Model
CD Section
CFD-V8
Tape Section
CFD-V8
KSM-213RDP/KSM-213CDP
KSS-213R/KSS-213C
MF-V5-117
– Continued on next page –
