SERVICE MANUAL
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
With 3.2 Ω loads, both channels driven from 150 – 10,000 Hz; rated 2W per
channel-minimum RMS power, with no more than 10 % total harmonic
distortion in AC operation.
CD player section
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wavelength:780 nm
Emission duration : Continuous
Laser output : Less than 44.6 µW
(This output is the value measured at a distance
of about 200 mm from the objective lens surface
on the optical pick-up block with 7 mm
aperture.)
Spindle speed
200 r/min (rpm) to 500 r/min (rpm) (CLV)
Number of channels
2
Frequency response
20 – 20,000 Hz + 1/-2 dB
Wow and flutter
Below measurable limit
Radio section
Frequency range
FM : 87.6 – 108 MHz
AM : 530 – 1,710 kHz
Aerials
FM : Telescopic aerial
AM : Built-in ferrite bar aerial
MICROFILM
CFD-V25/V35
Photo: CFD-V35
Model Name Using
Similar Mechanism
Optical Pick-up Type
Tape Transport Mechanism Type
SPECIFICATIONS
Cassette-corder section
Recording system
Fast winding time
Frequency response
General
Speakers
Outputs
Power output (excluding US model)
Power requirements
Power consumption
CD RADIO CASSETTE-CORDER
US Model
Canadian Model
CFD-V25/V35
E Model
CFD-V25
CD Section
NEW
Tape Section
KSM-213CDM/C2NP
MF-V10-117
4 -track 2 channel stereo
Approx. 120 s (sec.) with Sony cassette
C-60
TYPE1 (normal) : 70 – 10,000 Hz
Full range : 10 cm dia., 3.2 Ω, cone type
(2)
Headphones jack (stereo minijack)
For 16 – 64 Ω impedance headphones
2.3 W + 2.3 W (at 3.2 Ω, 10 % harmonic
distortion)
For CD radio cassette-corder :
120V AC, 60 Hz
9V DC, 6 size D (R 20) batteries
For memory controller :
3V DC, 2 size AA (R 6) batteries
AC 20W
— Continued on next page —

Advertisement

Table of Contents
loading

Summary of Contents for Sony CFD-V25

  • Page 1 4 -track 2 channel stereo With 3.2 Ω loads, both channels driven from 150 – 10,000 Hz; rated 2W per Fast winding time Approx. 120 s (sec.) with Sony cassette channel-minimum RMS power, with no more than 10 % total harmonic C-60 distortion in AC operation.
  • Page 2: Table Of Contents

    AC power cord (1) CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE Remote controller (1) REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY Design and specifications are subject to change without notice. DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU Optional accessories DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.
  • Page 3: Service Notes

    SECTION 1 SERVICE NOTES Laser component in this product is capable NOTES ON HANDLING THE OPTICAL PICK-UP of emitting radiation exceeding the limit for BLOCK OR BASE UNIT Class 1. The laser diode in the optical pick-up block may suffer electrostatic breakdown because of the potential difference generated by the charged electrostatic load, etc., on clothing and the human body.
  • Page 4: General

    SECTION 2 This section is extracted from instruction manual. GENERAL LOCATION OF CONTROLS !ª !• !¶ !§ !∞ !¢ !£ !™ !¡ !º !¡ POWER button CD operating !™ Tape operating buttons TONE (L) button (V25 only) !£ FUNCTION buttons !¢...
  • Page 5 — 5 —...
  • Page 6 — 6 —...
  • Page 7 — 7 —...
  • Page 8 — 8 —...
  • Page 9: Disassembly

    SECTION 3 DISASSEMBLY • The equipment can be removed using the following procedure. FRONT CABINET CONTROL (1) BOARD TUNING KNOB CONTROL (2) BOARD HEADPHONES BOARD UPPER CABINET OPTICAL PICK-UP SECTION MAIN BOARD POWER BOARD MECHANISM DECK REC SW BOARD BATT BOARD PRIMARY BOARD Note : Follow the disassembly procedure in the numerical order given.
  • Page 10: Optical Pick-Up

    3-3. OPTICAL PICK-UP 4 Remove solder CD Motor board Optical pick-up section 3 Wire (Flat type) (16 core) to MAIN board (CNP701) 2 CNP702 (6pin) 3-4. MECHANISM DECK, REC SW BOARD, MAIN BOARD, POWER BOARD, PRIMARY BOARD, BATT BOARD 1 Screws +BVTP 3 × 10 Mechanism deck 3 Screws +BVTP 3 ×...
  • Page 11: Adjustments

    SECTION 4 ADJUSTMENTS 1dB = 0.775V 4-1. MECHANICAL ADJUSTMENT 4-2. ELECTRICAL ADJUSTMENT PRECAUTION TAPE RECODER SECTION Clean the following parts with a denatured-alchool-moistened swab: Standard output level record/playback head pinch roller Output Pin HP OUT erase head rubber belts 32 Ω capstans Load impedance Demagnetize the record/playback head with a head...
  • Page 12: Tuner Section

    4-3. TUNER SECTION • Repeat the procedures in each adjustment several times for the 0 dB = 1 µV • Switch Location maximum level meter indication. • The frequency coverage and tracking adjustments should be VOLUME : MAX finally done by the trimmer capacitors. MEGA BASS : OFF PRESET SOUND MODE : OFF...
  • Page 13 FM VCO Adjustment Procedure : FM RF SSG 10.70MHz color BLUE 10.67MHz mark 0.01 µ F ORANGE 10.73MHz to ANT IN terminal BLACK 10.64MHz WHITE 10.76MHz Carrier frequency : 98MHz IF frequency : According to the color of CF1. Modulation : no modulation Output level : 0.1V (100dB) 1.
  • Page 14 E-F Balance Check CD SECTION Adjustment Location : MAIN board (See page 23) Notes on Check This check is to be done when the optical pick-up block is replaced. Perform the traverse check in the CD test mode. After check, be sure to exit the test mode. Check Procedure: Perform check in the order given.
  • Page 15: Reference

    Focus Bias Check 4-4. REFERENCE Adjustment Location : MAIN board (Component side) Focus/Tracking Gain Check (See page 23) Adjustment Location : MAIN board (Component side) (See page 23) This check is to be done when the optical block replaced. A frequency response analyzer is necessary in order to perform this Check Procedure: check exactly.
  • Page 16 • Good Example • Incorrect Examples (Fundamental wave appears) VOLT/DIV : 100mV VOLT/DIV : 1V TIME/DIV : 1ms TIME/DIV : 2ms 100mV low tracking gain • Incorrent Examples (DC level changes more than on adjusted VOLT/DIV : 1V waveform) TIME/DIV : 2ms VOLT/DIV : 100mV TIME/DIV : 2ms 200mV...
  • Page 17: Diagrams

    SECTION 5 DIAGRAMS 5-1. CIRCUIT BOARDS LOCATION REC SW board BATT board PRIMARY board CONTROL (1) board RMC board LAMP board (V35) CD MOTOR board JUCK RETAINER board MAIN board HEADPHONE board CONTROL (2) board POWER board LED board — 17 —...
  • Page 18: Ic Pin Function

    5-2. IC PIN FUNCTION IC501 CXP83416 Pin No. Pin Name Description C-SCOR SCOR input to CD Remote control signal input C-XRST Reset output to CD system B-MUTE CD block mute ON/OFF ROCK Input from ROCK key Input from POP key C-SQCK Clock for reading CD SUBQ C-SQSO...
  • Page 19: Block Diagram

    CFD-V25/V35 5-3. BLOCK DIAGRAM ANT1 IC302 TELESCOPIC SOUND/VOLUME ANTENNA Pin No. Pin Name Description COM3 LCD common output port IC301 FM/AM PRE AMP SEG0  FM RF FE OUT 4 5 6 FM IF  FRONT END SEG1  L-OUT...
  • Page 20: Printed Wiring Board

    CFD-V25/V35 5-4. PRINTED WIRING BOARD • Semiconductor Location Ref. No. Location J-22 J-23 D351 D501 H-14 D502 H-14 D503 H-15 D504 G-15 D506 E-17 D507 E-17 D508 E-17 D509 D-17 D511 G-17 D512 G-14 D513 G-14 D602 D603 D604 D605...
  • Page 21: Schematic Diagram - Tuner/System Section

    CFD-V25/V35 5-5. SCHEMATIC DIAGRAM — TUNER/SYSTEM SECTION — • Waveform 1.0V/div IC501 #¡ 0.1µsec/div 4.0Vp-p 4.0MHz 1.0V/div IC501 &¢ 1.0µsec/div 500kHz 4.5Vp-p Note: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums.
  • Page 22: Schematic Diagram - Power Section

    CFD-V25/V35 5-6. SCHEMATIC DIAGRAM — POWER SECTION — • Waveform 10V/div T301 REC 10µsec/div 52.75kHz 40Vp-p Note: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums.
  • Page 23: Schematic Diagram - Cd Section

    CFD-V25/V35 5-7. SCHEMATIC DIAGRAM — CD SECTION — 5-8. IC BLOCK DIAGRAMS CXA12138S 28 27 26 25 24 23 22 21 FM FRONT-END AM FRONT-END FM IF/ MPX REG. DISCRI IF/DET COUNTER TUNING COUNTER AUTOBLEND INDICATOR MONO/ST MUTING SELECT BAND PASS...
  • Page 24: Front Cabinet Section

    CFD-V25/V35 SECTION 6 EXPLODED VIEWS NOTE: 6-2. UPPER CABINET SECTION 6-3. REAR CABINET SECTION 6-4. MECHANISM DECK SECTION (1) • -XX, -X mean standardized parts, so they may • The mechanical parts with no reference number When indicating parts by reference number, (MF-V10-117) have some differences from the original one.
  • Page 25: Mechanism Deck Setion (1) (Mf-V10-117)

    6-5. MECHANISM DECK SECTION (2) (MF-V10-117) S801 S802 M301 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 3-933-029-01 LEVER, ERASING PREVENTION X-3372-924-1 FLYWHEEL ASSY 3-933-182-01 SPRING, CASSETTE 3-932-993-01 CHASSIS, OUTSERT 3-932-995-01 GEAR (MID) 3-343-358-01 RING, RETAINING X-3371-667-1 CLUTCH ASSY 3-933-005-01 SPRING (CAM), COMPRESSION 3-932-997-01 GEAR (CAM)
  • Page 26: Optical Pick-Up Section (Ksm-213Cdm/C2Np)

    6-6. OPTICAL PICK-UP SECTION (KSM-213CDM/C2NP) not supplied M702 M701 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 2-626-908-01 SHAFT, SLED 8-848-483-05 KSS-213C/Q-RP 2-627-003-02 GEAR (B) (RP) X-2626-202-1 CHASSIS ASSY (MB) (RP), MOTOR 2-626-907-01 GEAR (A) (INCLUDING M702) (SPINDLE) M701 X-2625-769-1 GEAR ASSY (MB) (RP), MOTOR (SLED) —...
  • Page 27: Electrical Parts List

    BATT CD MOTOR SECTION 7 CONTROL (1) CONTROL (2) ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in the • RESISTORS When indicating parts by reference number, parts list may be different from the parts All resistors are in ohms. please include the board name.
  • Page 28 CONTROL (2) HEADPHONE LAMP MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R621 1-249-431-11 CARBON 1/4W 1-668-348-11 LAMP BOARD (V35) (V25) *********** R622 1-249-431-11 CARBON 1/4W (V35) < CABLE HOLDER > R623 1-249-431-11 CARBON 1/4W (V35) * KH306 1-573-287-11 HOLDER, CABLE 2P (V35)
  • Page 29 MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C104 1-162-302-11 CERAMIC 0.0022uF 20% C549 1-162-294-31 CERAMIC 0.001uF C105 1-162-215-31 CERAMIC 47PF C550 1-162-294-31 CERAMIC 0.001uF C106 1-124-902-00 ELECT 0.47uF C551 1-162-294-31 CERAMIC 0.001uF C107 1-162-282-31 CERAMIC 100PF C552 1-162-306-11 CERAMIC...
  • Page 30 MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C751 1-162-306-11 CERAMIC 0.01uF < DIODE > C752 1-136-165-00 FILM 0.1uF C753 1-124-443-00 ELECT 100uF 8-719-991-33 DIODE 1SS133T-77 C754 1-162-306-11 CERAMIC 0.01uF 8-719-991-33 DIODE 1SS133T-77 C755 1-164-159-21 CERAMIC 0.1uF D501 8-719-991-33 DIODE 1SS133T-77...
  • Page 31 MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < RESISTOR > R515 1-249-417-11 CARBON 1/4W F R516 1-249-417-11 CARBON 1/4W F 1-247-815-91 CARBON 1/4W R517 1-249-417-11 CARBON 1/4W F 1-249-421-11 CARBON 2.2K 1/4W F R518 1-249-417-11 CARBON 1/4W F 1-249-441-11 CARBON...
  • Page 32 MAIN POWER Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R587 1-249-441-11 CARBON 100K 1/4W R766 1-249-429-11 CARBON 1/4W R588 1-249-429-11 CARBON 1/4W R768 1-247-903-00 CARBON 1/4W R589 1-249-421-11 CARBON 2.2K 1/4W F R771 1-249-429-11 CARBON 1/4W R590 1-249-417-11 CARBON...
  • Page 33 POWER Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C186 1-162-282-31 CERAMIC 100PF < DIODE > C241 1-124-907-11 ELECT 10uF C242 1-162-294-31 CERAMIC 0.001uF D351 8-719-991-33 DIODE 1SS133T-77 C243 1-124-907-11 ELECT 10uF D352 8-719-991-33 DIODE 1SS133T-77 C244 1-162-848-11 CERAMIC 0.056uF...
  • Page 34 POWER PRIMARY REC SW Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R283 1-247-807-31 CARBON 1/4W < RESISTOR > R338 1-249-427-11 CARBON 6.8K 1/4W F R339 1-249-427-11 CARBON 6.8K 1/4W F R901 1-247-807-31 CARBON 1/4W R340 1-249-427-11 CARBON 6.8K 1/4W F...
  • Page 35 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks ACCESSORIES & PACKING MATERIALS ******************************** 1-557-287-11 CORD, POWER (E) 1-590-147-11 CORD, POWER (US, CND) 3-861-412-11 MANUAL, INSTRUCTION (V25: E, CND) (ENGLISH) 3-861-412-21 MANUAL, INSTRUCTION (V25: CND) (FRENCH) 3-861-413-11 MANUAL, INSTRUCTION (V25: E) (SPANISH) 3-861-414-11 MANUAL, INSTRUCTION (V35) (ENGLISH) 3-861-414-21 MANUAL, INSTRUCTION (V35: CND) (FRENCH) 4-991-047-01 COVER, BATTERY...
  • Page 36 CFD-V25/V35 Sony Corporation 98B167042-1 Printed in Singapore © 1998.2 Personal A&V Products Company 9-923-315-11 Published by Quality Engineering Dept. — 54 — (Shibaura)
